- Page 1 PRT-TS50 Protege LCD Touchscreen Keypad Installation Manual...
- Page 2 The specifications and descriptions of products and services contained in this document were correct at the time of printing. Integrated Control Technology Limited reserves the right to change specifications or withdraw products without notice. No part of this document may be reproduced, photocopied, or transmitted in any form or by any means (electronic or mechanical), for any purpose, without the express written permission of Integrated Control Technology Limited.
-
Page 3: Table Of Contents
Contents Introduction Installation Requirements Mounting Mounting Instructions Technical Diagram Wiring Diagram Communication Connections End of Line Termination (EOL) Inputs Trouble Inputs Outputs Configuration Language Keypad Address Theme Backlight Brightness Setting Screen Timeout Setting Default Configuration Keypad Information Keypad Functions Orientation Status Indicators Error Messages Technical Specifications... -
Page 4: Introduction
Introduction The Protege LCD Touchscreen Keypad provides a sleek, user friendly human interface to the Protege System, an advanced technology security product providing seamless and powerful integration of access control, security and building automation. The current features of the keypad include: ⦁... -
Page 5: Installation Requirements
Installation Requirements This equipment is to be installed in accordance with: The product installation instructions ⦁ AS/NZS 2201.1 Intruder Alarm Systems ⦁ The Local Authority Having Jurisdiction (AHJ) ⦁ PRT-TS50 | LCD Touchscreen Keypad | Installation Manual... -
Page 6: Mounting
Mounting The keypad should be mounted on a wall with adequate air flow around and through it. The LCD Touchscreen Keypad can operate in either portrait or landscape orientation and can be changed by loading the appropriate firmware version. For more information, see Orientation (page 16). -
Page 7: Technical Diagram
Technical Diagram The dimensions shown below outline the essential details needed to help ensure the correct installation of the LCD Touchscreen Keypad. PRT-TS50 | LCD Touchscreen Keypad | Installation Manual... -
Page 8: Wiring Diagram
Wiring Diagram Reader shield is not terminated Shield wires connected inside the reader at the splice SHIELD PURPLE SB YELLOW SA BLUE Output BROWN Input 2 ORANGE Input 1 WHITE NB EOL ON EOL OFF GREEN NA BLACK 0V End of Line Termination The end of line (EOL) RED +12V jumper should be ON... -
Page 9: Communication
Communication The Protege system incorporates encrypted RS-485 communications technology for its module network. Each system controller supports up to 250 keypads. PRT-TS50 | LCD Touchscreen Keypad | Installation Manual... -
Page 10: Connections
Connections End of Line Termination (EOL) The EOL (End of Line) jumper should be placed in the ON position when the keypad is inserted as the first or last module on the RS-485 network. EOL Jumper OFF EOL Jumper ON PRT-TS50 | LCD Touchscreen Keypad | Installation Manual... -
Page 11: Inputs
Inputs The keypad is capable of connecting to 4 inputs, each of which can be programmed to perform the required function in the Protege system. The following diagrams show examples of the input wiring configuration settings that can be programmed under the input options within the Protege software. -
Page 12: Trouble Inputs
Trouble Inputs Each keypad can monitor up to 8 trouble inputs. Trouble inputs are used to monitor the module status and in most cases are not physically connected to an external input. The following table details the trouble inputs that are configured in the system and the trouble type and group that they activate. -
Page 13: Outputs
Outputs The keypad has 5 programmable outputs. These outputs are used to control the system status indicators, system beeper and the open collector output. The outputs can be activated and deactivated based on specific events or functions within the Protege System. Output Function KPXXX:01... -
Page 14: Configuration
Configuration Before the keypad will communicate with the Protege system it must be assigned an address. To program an address using the system configuration menu, apply power to the keypad, and while the screen displays Initializing press the [CLEAR] key, then the [ENTER] key. The configuration screen is displayed. Set the available options as required. -
Page 15: Keypad Functions
Keypad Functions Function The primary function of the numeric keys is to enter user codes. When controlling devices the [1] key turns the device on, the [2] turns the device off, and in the on state the [3] key latches the device. -
Page 16: Orientation
The required portrait or landscape version will need to be specified when downloading the keypad firmware or requesting firmware from ICT Technical Support. Update Keypad Firmware... -
Page 17: Status Indicators
Status Indicators The keypad features two status indicators showing the condition of the Protege system. Armed / Alarm Indicator When the armed/alarm indicator is flashing the system is in alarm and you need to enter your user code to silence the alarm. -
Page 18: Error Messages
Error Messages When the keypad attempts to register or communicate with the system controller after powering up, errors can be generated indicating access to the Protege system has been denied or was unsuccessful. This is a normal part of the Protege system. Keypad Version Error The version of the keypad is incorrect for the system controller. -
Page 19: Technical Specifications
Integrated Control Technology continually strives to increase the performance of its products. As a result these specifications may change without notice. We recommend consulting our website (www.ict.co) for the latest documentation and product information. -
Page 20: New Zealand And Australia
New Zealand and Australia General Product Statement The RCM compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. PRT-TS50 | LCD Touchscreen Keypad | Installation Manual... -
Page 21: European Standards
European Standards CE Statement Conforms where applicable to European Union (EU) Low Voltage Directive (LVD) 2014/35/EU, Electromagnetic Compatibility (EMC) Directive 2014/30/EU, Radio Equipment Directive (RED)2014/53/EU and RoHS Recast (RoHS2) Directive: 2011/65/EU + Amendment Directive (EU) 2015/863. This equipment complies with the rules, of the Official Journal of the European Union, for governing the Self Declaration of the CE Marking for the European Union as specified in the above directive(s). - Page 22 Ensure for Grade 3 or 4 compliant systems, the minimum PIN length is set for 6 digits. ⦁ To comply with EN 50131-1 Engineer access must first be authorized by a user, therefore Installer codes will ⦁ only be accepted when the system is unset. If additional restriction is required then Engineer access may be time limited to the first 30 seconds after the system is unset.
-
Page 23: Fcc Compliance Statements
FCC Compliance Statements FCC Rules and Regulations CFR 47, Part 15, Subpart A This equipment complies with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. -
Page 24: Industry Canada Statement
Industry Canada Statement ICES-003 This is a Class A digital device that meets all requirements of the Canadian Interference Causing Equipment Regulations. CAN ICES-3 (A)/NMB-3 (A) PRT-TS50 | LCD Touchscreen Keypad | Installation Manual... -
Page 25: Disclaimer And Warranty
Integrated Control Technology Ltd nor its employees shall be liable under any circumstances to any party in respect of decisions or actions they may make as a result of using this information. In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice. - Page 26 In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice.
