SFP Installation
To install the SFP transceivers:
1.
Slide the SFP
into the cage socket until it
2.
Lift
the latch to
lock the SFP
SFP
2
Tx
Rx
To remove the SFP transceivers:
1. Lower the latch to
unlock the SFP
2.
Pull the SFP out
of the cage socket carefully
SFP
16
clicks into place
Cage Socket
1
Cage Socket
1
Latch
2
Setup Options
Set up your device locally. Choose one of the following options to complete
your setup.
GUI
A
An
easy-to-use
GUI, compatible with most web browsers.
To minimize scrolling, the screen resolution should be at least
Local Setup
1280 x 1024 pixels.
FortiExplorer
B
FortiExplorer for iOS is a
configure, manage, and
Smartphone Setup
provisions, deploys, and monitors Security Fabric components
such as
FortiGate,
FortiWiFi, and
Command Line Interface (CLI)
C
An alternate configuration tool from the web-based manager that
uses a
terminal emulation
Local Setup
batches of commands from a text file or
Requires a console cable (available for purchase).
user-friendly iOS application
that helps you
monitor
appliances. FortiExplorer rapidly
FortiAP
devices.
application to
type commands
or upload
configuration
script.
17
