Tools required for assembly
Phillips
Screwdriver
STEP 1:
Place the COOLER BOX (1) upside down and fit all the LEGS (2+3)
on each corner of the COOLER BOX (1).
Ensure that the LEG with BOTTLE OPENER (3) is on the front side
that has the medallion.
Recessed Hole
Pre-Checked
54QT. COOLER
ITEM # TX 94009 , TX 94012 , TX 93811 , TX 93812
1
COOLER BOX
A
S04-4
SCREW
STEP 2:
There are six SCREWS (A)
for each LEG.
A
STEP 3:
1
2
IMPORTANT: READ CAREFULLY BEFORE BEGINNING
1. Do not tighten bolts until fully assembled.
2. Recessed holes to face outward.
3. Insert bolts with washer and secure with washer and nut.
4. Pre-checked side must always face downward or inward.
PARTS AND HARDWARE LIST
LEG
LEG W/BOTTLE OPENER
X 1PC
X 24PCS
2
X 3PCS
3
X 1PC
Use a screwdriver to
screw all twenty-four
SCREWS (A) in the pre-drilled
holes on the LEGS.
A
Flip over the
Assembled Cooler.
Lastly, ensure that
all the screws are
tightened.
Congratulations
3
on your assembly!
