Installation Instructions
4
Connect Exhaust Hose to the
Window Panel
Place the Air Conditioner close to the window ensuring there
is at least 20" of clearance from the wall and any other
obstructions. Extend the hose so that it reaches the Window
Kit. Insert the Exhaust Hose Adapter into the opening in the
Window Kit and slide it into the locking position. Ensure that
the hose runs straight to the window with no excess extension.
Use the small screw to attach the exhaust hose assembly to the
window sealing plate assembly
IMPORTANT: The Air Conditioner must be vented to the
outside. Do not use a longer hose or extend the hose
included with the Air Conditioner or the unit will not cool
properly and will overheat.
50cm 20"
5
Complete Installation
WARNING: Electrical Shock Hazard
□ Plug into a grounded 3 prong outlet.
□ Do not remove the ground prong from the
power cord plug.
□ Do not use an adapter.
□ Do not use an extension cord.
□ Failure to do so can result in death, fire or
electrical shock.
□ Plug the power cord into a grounded 3 prong outlet.
□ Press the Reset button on the plug to ensure the safety
plug is providing power to the air conditioner.
□ Allow 20" of clearance around the air conditioner for
proper air circulation.
□ When removing the air conditioner, be sure to remove the
Window Kit.
