SOMFY inteo EOLIS sensor RTS Installation Manual page 2

3
Functionning:
The EOLIS sensor RTS is able to protect an awning regarding the WIND by controling the OREA RTS or the ALTUS RTS motors.
The WIND threshold can be adjusted by a potentiometer accommodate wind speed between 10 to 50 Km/h.
WIND function
When the wind
speed exceeds the
threshold set by the
EOLIS sensor RTS,
an UP order is given
to the awning after
2 sec.
DEMO mode
In this mode all delay times are reduced to ease
installation and the wind threshold is 10Km/h.
The mode is selected by turning the wind
potentiometer clockwise to the limit.
As long as the
measured
wind speed is
higher than the
adjusted threshold, any order is inhibited.
after 2 sec.
When the wind
speed falls
below the
threshold
setting, an
order can be given with the RTS control
after 30 sec..
Temporisations
(with OREA and ALTUS)
Normal mode
WIND appearing timing 2 sec.
WIND disappearing timing 30 sec. 12 min.
®
after 30 sec.
Demo mode
2 sec.
15 sec.
