R O A D W AY
OVY LOW-PROFILE DROP PRISMATIC
R O A D W AY L U M I N A I R E
STREETWORKS ™
O R D E R I N G I N F O R M AT I O N
H O U S I N G
Die-cast aluminum housing with
S A M P L E N U M B E R
stainless steel bail latch. Standard
grey polyester powder coat finish.
PRODUCT
Other finish colors available.
FAMILY
Consult your Streetworks
OVY
Representative. Optional NEMA
twistlock photocontrol receptacle
also available.
S O C K E T
Adjustable mogul-base porcelain
socket.
D O O R
Die-cast aluminum door frame with
integral hinges for hands free
O P T I O N S + A C C E S S O R I E S
installation, relamping and
maintenance. ANSI wattage/source
label.
OPTIONS (add as suffix)
1=Single Fuse, Internally Mounted (120 or 277V)
L E N S
2=Double Fuse, Internally Mounted (208, 240, or 480V)
Removable borosilicate glass
4=Photocontrol Receptacle
refractor for use with High Pressure
WH=White
Sodium, Metal Halide and Mercury
BK=Black
lamp sources. Low profile glass
BZ=Bronze
provides 65% less glare than typical
E=150W/100V/HPS Ballast
drop lens reflectors.
H=Plug-in Starter Receptacle
K=Level Indicator
O P T I C A L A S S E M B LY
L=Lamp
The optical system is a
M=MOV Lightning Surge Protector
hydroformed anodized aluminum
T=Swing-down Ballast Bridge
reflector with a Dacron polyester
U=UL/CSA Listed
filter.
B A L L A S T A S S E M B LY
O P T I O N A L C O L O R S
Hard mounted ballast with
encapsulated starter for protection
from environmental abuse.
Standard two position tunnel type
compression terminal block.
WH
Optional swing-down ballast bridge
White
also available (Not available for 3G
applications).
M O U N T I N G
Two-bolt/one bracket slipfitter with
cast-in pipe stop and leveling steps.
Fixed-in-place birdguard seals
around 1 1/4" or 2" mounting arms.
(Birdguard not needed for 2" arm.)
E P A :
Effective Projective Area: .51
S H I P P I N G D ATA
NOTE: 1 150W units are for S55 lamp. 2 400W Metal Halide requires ED28 lamp. 3 Refer to technical section for lamp/ballast/voltage compatibility. 4 Not available in 400W. 5 Other distributions & cutoffs available. Consult your
Approximate Net Weight:
Streetworks Representative. 6 MOV option is not available for any system requiring a three position terminal block (Example—240V with PCR wired 120V). In order for MOV option to function center terminal of three
33 lbs. (15 kgs.) position terminal block must be connected to "Earth" ground.
124 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
NOTE: In select distributions only.
: O V Y 1 5 S W W 2 D 4
LAMP WATTAGE LAMP TYPE 3
15=50W 1 S=High
20=200W Pressure
25=250W Sodium
31=310W V=Mercury 4
40=400W 2 M=Metal Halide
24=250/400
wired 250W 2
42=400/250W
wired 400W 2
[ M u s t b e l i s t e d i n t h e o r d e r s h o w n a n d s e p a r a t e d b y a d a s h ]
6
[ S t a n d a r d c o l o r i s g r e y, o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BK BZ
Black Bronze
BALLAST TYPE 3 VOLTAGE 3
C=CWI 2=120V
M=Mag. Reg. 0=208V
W=CWA 4=240V
R=Reac./NPF 7=277V
P=Hi. Reac./HPF 8=480V
H=Reac./HPF 9=347V
N=Hi. Reac./NPF F=120/240 wired 120V
K=10KV CWA P=240 w/PCR wired 120V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
ACCESSORIES (order separately)
RA1003=Cutoff Visor
OA/RA1013=Photocontrol Shorting Cap
OA/RA1014=120V Photocontrol
OA/RA1016=105V-285V Photocontrol
OA/RA1027=480V Photocontrol
OA1028=Field Installed PCR Kit
OA1215=TufGuard Vandal Shield
MH/HPS/MERCURY
30" [762mm]
9 3/4"
[248mm]
16 15/16" [430mm]
DISTRIBUTION 5
CUTOFF
2=Type II
D=MCO
3=Type III E=MSCO
4=Type IV J=LNCO
C o o p e r L i g h t i n g
150-400W
OPTIONS +
ACCESSORIES
(See Below)
