R O A D W AY
OVH FLAT GLASS
R O A D W AY L U M I N A I R E
STREETWORKS ™
O R D E R I N G I N F O R M AT I O N
H O U S I N G
Die-cast aluminum housing and
S A M P L E N U M B E R
latch. Standard grey polyester
powder coat finish. Other finish
PRODUCT
colors available. Consult your
FAMILY
Streetworks Representative.
OVH
Optional NEMA twistlock
photocontrol receptacle also
available.
S O C K E T
Adjustable mogul-base porcelain
socket.
D O O R
Die-cast aluminum door frame with
integral hinges for toolless
O P T I O N S + A C C E S S O R I E S
relamping and maintenance. ANSI
wattage/source label.
OPTIONS (add as suffix)
L E N S
1=Single Fuse, Internally Mounted (120 or 277V)
Removable tempered flat glass
2=Double Fuse, Internally Mounted (208, 240, or 480V)
for use with High Pressure Sodium,
4=Photocontrol Receptacle
Metal Halide and Mercury lamp
WH=White
sources.
BK=Black
BZ=Bronze
R E F L E C T O R
E=150W/100V/HPS Ballast
The optical system is a
M=MOV Lightning Surge Protector
hydroformed anodized aluminum
H=Plug-in Starter Receptacle
reflector with a Dacron polyester
K=Level Indicator
filter.
U=UL/CSA Listed
B A L L A S T A S S E M B LY
Hard mounted ballast with
O P T I O N A L C O L O R S
encapsulated starter for protection
from environmental abuse.
Standard two position tunnel type
compression terminal block. Three
position available. Consult your
WH
Streetworks Representative.
White
M O U N T I N G
Two-bolt/one bracket slipfitter with
cast-in pipe stop and leveling steps.
Fixed-in-place birdguard seals
around 1 1/4" or 2" mounting arms.
E P A :
Effective Projective Area: .80
S H I P P I N G D ATA
Approximate Net Weight:
NOTE: 1 150W units are for S55 lamp. 2 Refer to technical section for lamp/ballast/voltage compatibility. 3 Available in 120/240V dual voltage or single voltage only for 50-150W. 4 MOV option is not available for any system
28 lbs. (13 kgs.)
requiring a three position terminal block (Example—240V with PCR wired 120V). In order for MOV option to function center terminal of three position terminal block must be connected to "Earth" ground.
116 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
: O V H 5 0 S R 2 2 D 4
LAMP LAMP TYPE 2
WATTAGE S=High Pressure
50=50W Sodium
70=70W V=Mercury
10=100W M=Metal Halide
15=150W 1
17=175W
20=200W
25=250W
[ M u s t b e l i s t e d i n t h e o r d e r s h o w n a n d s e p a r a t e d b y a d a s h ]
4
[ S t a n d a r d c o l o r i s g r e y, o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BK BZ
Black Bronze
BALLAST TYPE 2 VOLTAGE 2
C=CWI 2=120V
H=Reac./HPF 0=208V
K=10KV CWA 3 4=240V
M=Mag. Reg. 7=277V
N=Hi. Reac./NPF 8=480V
P=Hi. Reac./HPF 9=347V
R=Reac./NPF F=120/240 wired 120V
W=CWA P=240 w/PCR wired 120V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
ACCESSORIES (order separately)
OA/RA1013=Photocontrol Shorting Cap
OA/RA1014=120V Photocontrol
OA/RA1016=105V-285V Photocontrol
OA/RA1027=480V Photocontrol
OA1028=Field Installed PCR Kit
OA1213=TufGuard Vandal Shield
MH/HPS/MERCURY
27 3/32" [688mm]
6 17/32"
[166mm]
12 5/8" [321mm]
DISTRIBUTION
CUTOFF
2=Type II
D=MCO
3=Type III
C o o p e r L i g h t i n g
50-250W
OPTIONS +
ACCESSORIES
(See Below)
