Cooper Lighting Deep Prismatic Glass OVD15SWW2F4 Specification Sheet

R O A D W AY
OVD DEEP PRISMATIC GLASS
R O A D W AY L U M I N A I R E
STREETWORKS ™
H O U S I N G
O R D E R I N G I N F O R M AT I O N
Die-cast aluminum housing with
S A M P L E N U M B E R
stainless steel bail latch. Standard
grey polyester powder coat finish.
PRODUCT
Other finish colors available.
FAMILY
Consult your Streetworks
OVD
Representative. Optional NEMA
twistlock photocontrol receptacle
also available.
S O C K E T
Adjustable mogul-base porcelain
socket.
D O O R
Die-cast aluminum door frame with
integral hinges for hands free
O P T I O N S + A C C E S S O R I E S
installation, relamping and
maintenance. ANSI wattage/source
OPTIONS (add as suffix)
label.
1=Single Fuse, Internally Mounted (120 or 277V)
L E N S
2=Double Fuse, Internally Mounted (208, 240, or 480V)
Removable borosilicate glass
4=Photocontrol Receptacle
refractor for use with High Pressure
WH=White
Sodium, Metal Halide and Mercury
BK=Black
lamp sources.
BZ=Bronze
E=150W/100V/HPS Ballast
R E F L E C T O R
H=Plug-in Starter Receptacle
The optical system is a
K=Level Indicator
hydroformed anodized aluminum
L=Lamp
reflector with a Dacron polyester
M=MOV Lightning Surge Protector
filter.
P=Polycarbonate Refractor (250W Max.)
T=Swing-down Ballast Bridge
B A L L A S T A S S E M B LY
U=UL/CSA Listed
Hard mounted ballast with
encapsulated starter for protection
from environmental abuse.
O P T I O N A L C O L O R S
Standard two position tunnel type
compression terminal block.
Optional swing-down ballast bridge
also available (Not available for 3G
applications).
WH
White
M O U N T I N G
Two-bolt/one bracket slipfitter with
cast-in pipe stop and leveling steps.
Fixed-in-place birdguard seals
around 1 1/4" or 2" mounting arms.
(Birdguard not needed for 2" arm.)
E P A :
Effective Projective Area: .64
S H I P P I N G D ATA
Approximate Net Weight:
NOTE: 1 150W units are for S55 lamp. 2 Refer to technical section for lamp/ballast/voltage compatibility. 3 Other distributions & cutoffs available. Consult your Streetworks Representative. 4 MOV option is not available for any
35 lbs. (16 kgs.) system requiring a three position terminal block (Example—240V with PCR wired 120V). In order for MOV option to function center terminal of three position terminal block must be connected to "Earth" ground.
120 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
: O V D 1 5 S W W 2 F 4
LAMP WATTAGE LAMP TYPE
15=150W 1 S=High Pressure
20=200W Sodium
25=250W V=Mercury
31=310W M=Metal Halide
40=400W
24=250/400W wired 250W
42=400/250W wired 400W
[ M u s t b e l i s t e d i n t h e o r d e r s h o w n a n d s e p a r a t e d b y a d a s h ]
4
[ S t a n d a r d c o l o r i s g r e y, o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BK BZ
Black Bronze
2 BALLAST TYPE 2 VOLTAGE
C=CWI 2=120V
M=Mag. Reg. 0=208V
W=CWA 4=240V
R=Reac./NPF 7=277V
P=Hi. Reac./HPF 8=480V
H=Reac./HPF 9=347V
N=Hi. Reac./NPF F=120/240 wired 120V
K=10KV CWA P=240 w/PCR wired 120V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
ACCESSORIES (order separately)
RA1003=Cutoff Visor
OA/RA1013=Photocontrol Shorting Cap
OA/RA1014=120V Photocontrol
OA/RA1016=105V-285V Photocontrol
OA/RA1027=480V Photocontrol
OA1028=Field Installed PCR Kit
OA1218=TufGuard Vandal Shield
30" [762mm]
16 15/16" [430mm]
2 DISTRIBUTION 3
CUTOFF
2=Type II
C=SNCO
3=Type III
F=MNCO
150-400W
MH/HPS/MERCURY
12 3/4"
[324mm]
OPTIONS +
ACCESSORIES
(See Below)
C o o p e r L i g h t i n g
