PROLiNK IPS3000P User Manual page 15

Table 6 Invert Mode Specifications
MODEL
Output Voltage Waveform
Rated Output Power
Power Factor
Nominal Output voltage
Minimum Peak Output Voltage at
Rated Power
Output Frequency(Hz)
Output Voltage Regulation
Nominal Efficiency
Over-Load Protection
Surge rating
Capable of starting electric motor
Output Short Circuit Protection
Nominal DC Input Voltage
Min DC start voltage
Low DC Alarm
Low DC Alarm Recovery
Low DC Shut-down
Low DC Shut-down Recovery
High DC Shut-down
High DC Shut-down Recovery
DC component of output
Power Limitation
IPS3000P
Pure Sine Wave
3000VA
0.8
230Vac
>200V
50Hz / 60Hz ± 1Hz (follow first connect to grid)
±10% Vrms
>90% (@Normal DC Input; >60% R load)
fault after 5s@≥150% load,<=200% load
fault after 10s@110%~150% load,
6000VA
1.5HP
Current limit (Fault after 4 cycles max)
24V
20V
21.0 ± 0.6Vdc
21.6 ± 0.6Vdc
20.0 ± 0.6Vdc
22.0 ± 0.6Vdc
30.0 ± 0.6Vdc
29.0 ± 0.6Vdc
<100mV
13
