Novus LogBox BLE Instruction Manual page 8

SCREEN
4. Digital Input
Pulse Count:
Accumulator
Displayed for 2 seconds before moving to
digital input
Accumulator.
5. Digital Input
Event Log or Logs
Control
Displayed for 2 seconds before moving to
digital input screen – Event Log or Logs
Control.
6. Log Memory
Displayed for 2 seconds before moving to
Log Memory screen.
NOVUS AUTOMATION
MNEMONIC
This screen is updated by the display update
screen – Pulse Count: interval.
This screen is updated every time an event is
detected in the Digital input.
This screen is only updated by the log
interval.
INFORMATION
When enabled and configured in the "Pulse
Count" mode and then set to "Volume since
Last Reset" (Application parameter / Flow
Rate function) or the option "Accumulated
Count Since Last Reset" (Application
parameter / Count function), displays the
volume or count accumulated since the last
digital channel reset. If it is not configured,
this screen will not be displayed.
Uses the three lines of the display to
display the accumulated volume or count.
When enabled and configured in "Event
Log" or "Logs Control" modes, it displays
the last event detected at the digital input.
Line 1: Edge detected in event: 0 – Falling
edge; 1 – Rising edge.
Line 2: Day. Month of the event (if the 24-
hour format is selected); Month. Day of the
event (if the AM/PM format is selected).
Line 3: Hour: Minute of the event.
Displays the number of logs in the memory
and free memory percentage.
Line 1 and 2: Number of logs recorded in
the memory.
Line 3: Free memory percentage.
DESCRIPTION
Key held down or long touch: No action.
Key held down or long touch: No action.
Key held down or long touch: No action.
Key held down or long touch: No action.
Key held down or long touch: No action.
Key held down or long touch: No action.
8/65
KEYS FUNCTION
Both keys held down: No action.
Both keys held down: No action.
Both keys held down: No action.
