Novus LogBox BLE Instruction Manual page 7

SCREEN
1. Analog Inputs
Displayed for 2 seconds before moving to
analog inputs screen.
2. Digital Input
Pulse Count: Flow
Rate
Displayed for 2 seconds before moving to
analog inputs – Pulse Count: Flow Rate
screen.
3. Digital Input
Pulse Count:
Count
Displayed for 2 seconds before moving to
digital input screen – Pulse Count: Count.
NOVUS AUTOMATION
MNEMONIC
This screen is updated by the log interval
and/or by the display update interval.
This screen is updated by the display update
interval.
This screen is updated by the display update
interval.
INFORMATION
Displays the current value of the analog
channels and allows the display of the
maximum and minimum values reached by
each channel.
Line 1: Analog channel 1 value.
Line 2: Analog channel 2 value.
Line 3: Analog channel 3 value.
When enabled and configured in "Pulse
Count" mode and then configured with the
"Average Flow by Acquisition Interval"
option (Application parameter / Flow Rate
function), it displays the average flow
logged within the configured log interval. If it
is not configured, this screen will not be
displayed.
Use the three lines of the display to display
the logged flow rate.
When enabled and configured in the "Pulse
Count" mode and then configured with
"Acquisition
(Application parameter / Count function),
it displays the registered count within the
configured registered acquisition interval. If
it is not configured, this screen will not be
displayed.
Uses the three lines of the display to
display the logged count.
DESCRIPTION
Key held down or long touch: Informs
the maximum value reached in each analog
channel.
Key held down or long touch: Informs
the minimum value reached in each analog
channel.
alarm statuses and the minimum and
maximum values reached by each analog
channel.
Key held down or long touch: Informs
the maximum flow rate.
Key held down or long touch: Informs
the minimum flow rate.
minimum and maximum alarm statuses
reached by each channel.
Key held down or long touch: Informs
the maximum flow rate.
Interval Counting" option
Key held down or long touch: Informs
the minimum flow rate.
minimum and maximum alarm statuses
reached by each channel.
7/65
KEYS FUNCTION
Both keys held down: clears the
Both keys held down: Clears the
Both keys held down: Clears the
