Icom IC-F5220D Service Manual page 26

[FRONT UNIT]
REF PARTS
NO. NO.
R784 7030005240 S.RES ERJ2GEJ 473 X (47K)
R785 7030005240 S.RES ERJ2GEJ 473 X (47K)
R786 7030010040 S.RES ERJ2GEJ-JPW
R787 7030005050 S.RES ERJ2GEJ 103 X (10K)
C2 4030017420 S.CER C1005 CH 1H 470J-T
C3 4030017420 S.CER C1005 CH 1H 470J-T
C4 4030017420 S.CER C1005 CH 1H 470J-T
C5 4030017420 S.CER C1005 CH 1H 470J-T
C8 4030017460 S.CER C1005 JB 1H 102K-T
C9 4030017460 S.CER C1005 JB 1H 102K-T
C10 4030017460 S.CER C1005 JB 1H 102K-T
C12 4030017460 S.CER C1005 JB 1H 102K-T
C25 4030016790 S.CER C1005 JB 1E 103K-T
C26 4030016930 S.CER C1005 JB 1A 104K-T
C27 4030018010 S.CER C1005 CH 1H 360J-T
C28 4030016930 S.CER C1005 JB 1A 104K-T
C31 4030016930 S.CER C1005 JB 1A 104K-T
C34 4030017420 S.CER C1005 CH 1H 470J-T
C41 4030017460 S.CER C1005 JB 1H 102K-T
C50 4030017420 S.CER C1005 CH 1H 470J-T
C75 4030016930 S.CER C1005 JB 1A 104K-T
C76 4030016930 S.CER C1005 JB 1A 104K-T
C78 4030017460 S.CER C1005 JB 1H 102K-T
C84 4030017420 S.CER C1005 CH 1H 470J-T
C87 4030016930 S.CER C1005 JB 1A 104K-T
C93 4030017460 S.CER C1005 JB 1H 102K-T
C114 4030017420 S.CER C1005 CH 1H 470J-T
C126 4030017460 S.CER C1005 JB 1H 102K-T
C128 4030016930 S.CER C1005 JB 1A 104K-T
C129 4030017460 S.CER C1005 JB 1H 102K-T
C130 4030017460 S.CER C1005 JB 1H 102K-T
C131 4030017460 S.CER C1005 JB 1H 102K-T
C132 4030017460 S.CER C1005 JB 1H 102K-T
C626 4030017640 S.CER C1005 CH 1H 150J-T
C627 4030017580 S.CER C1005 CH 1H 060C-T
C628 4030017640 S.CER C1005 CH 1H 150J-T
C629 4030016930 S.CER C1005 JB 1A 104K-T
C630 4030016930 S.CER C1005 JB 1A 104K-T
C631 4030016930 S.CER C1005 JB 1A 104K-T
C797 4030016930 S.CER C1005 JB 1A 104K-T
C799 4030016930 S.CER C1005 JB 1A 104K-T
C800 4030016930 S.CER C1005 JB 1A 104K-T
C802 4030016930 S.CER C1005 JB 1A 104K-T
C803 4030019990 S.CER C1005 JB 1C 104K-T
C804 4030017460 S.CER C1005 JB 1H 102K-T
C805 4030018900 S.CER C1005 JB 0J 474K-T
C806 4550008240 S.TAN F930G476MAA
C807 4030016930 S.CER C1005 JB 1A 104K-T
C808 4030016930 S.CER C1005 JB 1A 104K-T
C809 4030016930 S.CER C1005 JB 1A 104K-T
C810 4030016930 S.CER C1005 JB 1A 104K-T
C811 4030017460 S.CER C1005 JB 1H 102K-T
J1 6450002210 CON 3017-8821 <KIN>
J2 6510027960 S.CON 04-6294-040-000-800
DS1 5040003510 S.LED LNJ426W83RA
DS2 5040003510 S.LED LNJ426W83RA
DS3 5040003510 S.LED LNJ426W83RA
DS4 5040003510 S.LED LNJ426W83RA
DS5 5040003510 S.LED LNJ426W83RA
DS6 5040003510 S.LED LNJ426W83RA
DS7 5040003510 S.LED LNJ426W83RA
DS8 5040003510 S.LED LNJ426W83RA
DS9 5040003510 S.LED LNJ426W83RA
DS11 5030003390 LCD TAK-35877 FX-3331<ITAK>
W1 8900010503 CAB OPC-1046B-1(P0.5N40L55)
<TJM>
EP2 8930059170 LCD SRCN-2622-SP-N-W (SHJ)
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B
B
B
B
B
B
B
B
B
T
T
T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
T
T
T
T
T
T
T
T
H/V
26.5/18.8
30.8/19.3
74.6/29.4
84.3/11.0
84.0/7.7
28.5/6.1
47.2/5.0
56.3/4.6
13.7/17.1
11.3/17.1
20.3/13.1
18.3/13.1
26.9/28.9
23.0/26.4
25.0/27.1
30.6/27.1
33.4/4.2
56.3/5.5
25.0/29.0
61.6/8.6
42.3/27.2
28.8/28.9
8.9/17.1
29.9/2.9
30.9/18.0
56.3/7.9
19.7/10.6
25.2/4.2
14.6/19.3
13.7/19.3
85.7/8.6
86.9/21.0
86.2/26.9
81.1/19.6
80.1/17.2
81.0/17.2
79.1/15.0
82.6/12.0
56.1/29.6
75.6/21.5
77.2/22.4
77.2/21.2
69.1/9.7
49.7/24.9
26.6/22.1
65.3/29.3
43.4/6.5
75.4/20.4
78.8/17.1
88.6/15.1
25.0/28.1
31.5/8.0
71.0/5.7
64.8/23.5
58.2/23.5
51.6/23.5
31.8/23.5
38.4/23.5
45.0/23.5
82.6/22.1
65.3/5.0
36.3/5.0
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
7-7
S.=Surface mount
