- Page 1 Unitecnic 1150 Instruction manual...
-
Page 2: Kit Content
Kit Content UNITECNIC 1150 - INSTRUCTION MANUAL The content ■ External case ■ 1 red tumbler ■ Tweezer for code (With keypad) ■ 1 blue tumbler tumblers ■ External flange ■ 1 Spindle square 7mm ■ Operating manual ■ Latch tubular lock ■... - Page 3 Characteristics UNITECNIC 1150 - INSTRUCTION MANUAL Technical features Applications Indoor or outdoor installation Theoretical Locking Combinations 500000 Combinations From 4 to 6 digits Lock Handing Reversible Material Zamak Handle Functions Free access mode from the keypad Always Free Exit Standard Finish...
- Page 4 Code change and free access UNITECNIC 1150 - INSTRUCTION MANUAL Internal side of the external case 1. Remove carefully the plate. ■ The opening code is determined by (Be careful not to lose any springs) the red tumblers. 2. Code change.
- Page 5 UNITECNIC 1150 - INSTRUCTION MANUAL 4. Number of terms change. released indefinitely. To return to (Be careful not to lose any springs) controlled access mode, press the ■ It is possible to reduce the number of free access key, then “C”.
- Page 6 Handling change UNITECNIC 1150 - INSTRUCTION MANUAL By default, the code lock is configured in the right hand (Seen from outside, the code lock is on the left on the door) External case ■ Remove the internal screw of the ■...
- Page 7 Spindle adaptation UNITECNIC 1150 - INSTRUCTION MANUAL Adapt the length of the special spindle according to the thickness of the door, by breaking off one or both ends. From 50 mm to 55 mm (Leave as is) From 43 mm to 50 mm (Break one side)
- Page 8 Drilling scheme UNITECNIC 1150 - INSTRUCTION MANUAL dge of Edge of Trace and prepare the e door the door housing for the forend and Mark and drill the mortice of the lock the six Ø 10mm holes casing (supplied). Axis of the edge of the door Don’t forget to point the...
- Page 9 Code lock mounting UNITECNIC 1150 - INSTRUCTION MANUAL For the door For the Frame Stainless steel forend Security trigger ■ Put in place then fix the casing and ■ Position and fix the stainless steel stainless steel decorated forend striking plate and its PVC box, so that using the wood screws provided.
- Page 10 Code lock mounting UNITECNIC 1150 - INSTRUCTION MANUAL Interior side Outside side Rubber flange Spindle square For the flap version only ■ Push the button. ■ Slide the flap upwards until it clicks. ■ To hide the keyboard again, slide the...
-
Page 11: Functional Check
Functional check UNITECNIC 1150 - INSTRUCTION MANUAL Open door Check that the interior handle correctly gears the latch. Enter the code in place, then turn the outside handle: the bolt is driven for a single opening. Note: A code always starts with “C”... - Page 12 That is why you to make this happen. Now and in can count on us to help you create the future. Your expert safety advisor: WWW.DOM-SECURITY.COM...
