DOM Unitecnic 1250 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Unitecnic 1250
Instruction manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Unitecnic 1250 and is the answer not in the manual?

Questions and answers

Related Manuals for DOM Unitecnic 1250

Summary of Contents for DOM Unitecnic 1250

  • Page 1 Unitecnic 1250 Instruction manual...

  • Page 2: Kit Content

    Kit Content UNITECNIC 1250 - INSTRUCTION MANUAL The content ■ External case ■ 1 Spindle square 7mm ■ Tweezer for (With keypad) ■ Internal case code tumblers ■ External flange ■ Internal flange ■ Operating manual ■ 2 columns + 2 rings ■...
  • Page 3 Characteristics UNITECNIC 1250 - INSTRUCTION MANUAL Technical features Applications Indoor or outdoor installation Theoretical Locking Combinations 500000 Combinations From 4 to 6 patterns Lock Handing Reversible Material Zamak Handle fonctions Free access mode from the keypad Always Free Exit Standard Finish...
  • Page 4 Code change and free access UNITECNIC 1250 - INSTRUCTION MANUAL Internal side of the external case 1. Remove carefully the plate. ■ The opening code is determined by (Be careful not to lose any springs) the red tumblers. 2. Code change.
  • Page 5 UNITECNIC 1250 - INSTRUCTION MANUAL 4. Number of terms change. In case of non-operation. (Be careful not to lose any springs) Check that only the red tumblers ■ It is possible to reduce the number of are pushed when entering the code...
  • Page 6 Handling change UNITECNIC 1250 - INSTRUCTION MANUAL By default, the code lock is configured in the right hand (Seen from outside, the code lock is on the left on the door) External case ■ Remove the internal screw of the han- ■...
  • Page 7 Spindle adaptation UNITECNIC 1250 - INSTRUCTION MANUAL Adapt the length of the special spindle ac- cording to the thickness of the door, by breaking off one or both ends. From 50 mm to 55 mm (Leave as is) From 43 mm to 50 mm (Break one side)
  • Page 8 Drilling scheme UNITECNIC 1250 - INSTRUCTION MANUAL Door edge Leave in place the spindle If the door is not already fitted In the case of a door already with one, install a mortice equipped, remove the lock, backset at 50 mm min.
  • Page 9 Code lock mounting UNITECNIC 1250 - INSTRUCTION MANUAL Installation of the spindle in the follower ■ Different layout depending on the door’s handling Keypad side view Assemble the front side If necessary: change the combination and/ or modify the free passage option beforehand.
  • Page 10 Code lock mounting UNITECNIC 1250 - INSTRUCTION MANUAL Interior side Outside side Screws: ■ 50 mm for door from 30 to 40mm ■ 60 mm for door from 40 to 50mm Screw 20mm Cylinder cover Flat head screw: ■ 30 mm for door from 35 to 43mm ■...

  • Page 11: Functional Check

    Functional check UNITECNIC 1250 - INSTRUCTION MANUAL Open door Check that the interior handle correctly gears the latch.Screw the cylinder’s screw, check the action of the key on the latch.Leave the key outside the room. Enter the code in place, then turn the outside handle: the bolt is driven for a single opening.
  • Page 12 That is why you to make this happen. Now and in can count on us to help you create the future. Your expert safety advisor: WWW.DOM-SECURITY.COM...
