Accessory Glass Bead Gun
For dispensing glass beads for pavement marking. For professional use only.
Model: 19B119
80 psi (0.55 MPa, 5.5 bar) Maximum Air Working Pressure
40 psi (0.28 MPa, 2.8 bar) Maximum Bead Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual and in the Pressurized Bead
System manual before using the equipment. Be familiar with the controls and the
proper usage of the equipment. Save all instructions.
Related Manual
Pressurized Bead System
332230
3A7285A
EN
Advertisement
Table of Contents
Related Manuals for Graco 19B119
Summary of Contents for Graco 19B119
- Page 1 3A7285A Accessory Glass Bead Gun For dispensing glass beads for pavement marking. For professional use only. Model: 19B119 80 psi (0.55 MPa, 5.5 bar) Maximum Air Working Pressure 40 psi (0.28 MPa, 2.8 bar) Maximum Bead Working Pressure Important Safety Instructions Read all warnings and instructions in this manual and in the Pressurized Bead System manual before using the equipment.
- Page 2 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
- Page 3 Pressure Relief Procedure Pressure Relief Procedure Loosen wing nut (2) until it reaches end of threads. If any remaining pressure is in bead tank, it will be released through seal while wing nut secures lid to hop- per. Confirm pressure is at 0 psi (0 bar, 0 MPa) and open lid.
- Page 4 Installation Installation Perform Pressure Relief Procedure Connect accessory glass bead gun to page 3. bead tank or to “Y” adapter if optional step #3 is used. Disconnect existing bead hose from bead tank. Disconnect existing 1/4 inch air line from air tank.
- Page 5 Installation Accessory Bead Gun Accessory Bead Gun Parts List Ref. Part Description Qty. 19B120 GUN, spray, glass beads 17C065 HOSE, pneumatic 16T829 HOSE, bead, 3/4”, clear 125274 FITTING, garden hose, union M71548 FITTING, connector, “Y” 115287 FITTING, tube, Y 3/4” 3A7285A...
- Page 6 Compliance Compliance California Proposition 65 WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. 3A7285A...
- Page 7 Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts.
- Page 8 For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. All written and visual data contained in this document reflects the latest product information available at the time of publication.
