UM2992
User manual
Getting started with FP-LIT-BLEMESH1 function pack for IoT nodes with
Bluetooth® Low Energy mesh connectivity and lighting mode
Introduction
FP-LIT-BLEMESH1
is an
STM32Cube
function pack, which lets you connect Bluetooth® Low Energy nodes to a smartphone via
®
Bluetooth
Low Energy, through a suitable Android™ or iOS™ application or use the Ambient Light Sensor on
X-
NUCLEO-6283A1
to set the HSL values and send the data to the lighting hardware using the Bluetooth® Low Energy mesh
lighting model.
®
The software lets you easily create your own application for extending Bluetooth
mesh networks (by offering a ready-to-use
mesh core library), a complete set of compatible APIs, and a lighting demo application running on either
X-NUCLEO-IDB05A2
or X-NUCLEO-BNRG2A1,
X-NUCLEO-LED12A1
and
X-NUCLEO-6283A1
expansion boards connected to a
NUCLEO-L476RG
development board.
The software runs on the STM32 microcontroller and includes all the necessary drivers to recognize the devices on the
STM32
Nucleo
development board and the expansion boards.
Related links
Visit the STM32Cube ecosystem web page on www.st.com for further information
UM2992 - Rev 2 - June 2023
www.st.com
For further information contact your local STMicroelectronics sales office.
