Summary of Contents for ST FP-ATR-BLE1
- Page 1 Quick Start Guide STM32Cube function pack for asset tracking using BLE connectivity for SensorTile.box wireless multi sensor development kit (FP-ATR-BLE1) Version 1.0 (February 19, 2020)
- Page 2 Quick Start Guide Contents FP-ATR-BLE1: STM32Cube function pack for asset tracking using BLE connectivity for SensorTile.box wireless multi sensor development kit Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...
-
Page 3: Hardware Overview
Hardware Overview Sample implementations available for: STEVAL-MKSBOX1V1 evaluation board Blister Content: • STEVAL-MKSBOX1V1 with 2 different cases, SD-Card and rechargeable battery • JTAG20 to STDC14 adapter • STDC14 cable STEVAL-MKSBOX1V1... - Page 4 The SensorTile.box board fits into a small plastic shroud with a long-life rechargeable battery, and the ST BLE Sensor app on your smartphone connects via Bluetooth to the board and allows you to immediately begin using the wide range of default IoT and wearable sensor applications.
-
Page 5: Software Overview
FP-ATR-BLE1 Software Description Software Overview The FP-ATR-BLE1 is STM32Cube Function Pack for low power asset tracking using BLE connectivity for the SensorTile.box wireless multi sensor development kit (STEVAL-MKS1BOX1). The purpose of this functional pack is to provide one example Overall Software Architecture application that show how to build a custom low power asset tracking using BLE connectivity for STEVAL-MKS1BOX1. - Page 6 Quick Start Guide Contents FP-ATR-BLE1: STM32Cube function pack for asset tracking using BLE connectivity for SensorTile.box wireless multi sensor development kit Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...
- Page 7 1x STEVAL-MKSBOX1V1 evaluation board • Laptop/PC with Windows 7, 8 or 10 Micro USB Cable • 1 x micro USB cable Mini USB • 1x USB type A to Mini-B USB cable ST-Link/V2 • ST-Link/V2 in-circuit debugger/programmer for STM8 and STM32 STEVAL-MKSBOX1V1...
- Page 8 Setup & Demo Examples SW prerequisites • STSW-LINK004 • STM32 ST-LINK Utility (STSW-LINK004) is a full-featured software interface for programming STM32 microcontrollers • FP-ATR-BLE1 • Copy the .zip file content into a folder on your PC. The package will contain source code example (Keil, IAR, STM32Cube IDE) based on STEVAL-MKSBOX1V1 •...
-
Page 9: Setup Overview
FP-ATR-BLE1 Setup Overview www.st.com/stm32ode-fp FP-ATR-BLE1 package structure Docs BSP, HAL and drivers www.st.com BlueNRG-2, FatFs, FreeRTOS Application Download & unpack Select FP-ATR-BLE1 Android™/iOS™ Projects\STM32L4R9ZI-SensorTile.box\Applications\ ATR_BLE\ smartphone and ST asset tracking application Compile/Flash and Run the project... - Page 10 User Button For reducing the power consumption the Bluetooth it’s not enabled when the ST asset tracking application is not connected to it. Each time we want to enable it for controlling the asset tracking log using the ST asset tracking application, press the User Button.
- Page 11 ST asset tracking Mobile App • Switch on the SensorTile.box and enable Bluetooth connectivity • Start the ST asset tracking application and select FP-ATR-BLE1 • Search the board (ATB_100 default name) • Connect to the board and make the pairing (default PIN 123456)
- Page 12 FP-ATR-BLE1 ST asset tracking Mobile App • Select the Interval for reading Environmental Sensors (Pressure/Temperature/Humidity) • Pressing the “+” Button add all the Environmental and Inertial Events that we want to track • • 6D Orientation Environmental Event Event •...
- Page 13 For reading the Events Log on the board, enable again the Bluetooth pressing the “User Button” • Use the ST asset tracking application and connect to SensorTile.box (Secure PIN no more requested) and select “Data” page User Button Environmental Events Page...
- Page 14 Quick Start Guide Contents FP-ATR-BLE1: STM32Cube function pack for asset tracking using BLE connectivity for SensorTile.box wireless multi sensor development kit Hardware and Software overview Setup & Demo Examples Documents & Related Resources STM32 Open Development Environment: Overview...
- Page 15 The STM32 Open Development Environment (STM32 ODE) is an open, flexible, easy and affordable way to develop innovative devices and applications based on the STM32 32-bit microcontroller family combined with other state-of-the-art ST components connected via expansion boards. It enables fast prototyping with leading-edge components that can...
