WIRELESS REMOTE CONTROL
USERꞌS MANUAL
This air-conditioner complies with following directive.
Machinery 2006/42/EC
Low Voltage 2014/35/EU
EMC 2014/30/EU
Pressure Equipment 2014/68/EU
RoHS 2011/65/EU
Ecodesign 2009/125/EC
CE marking is applicable to the area of 50 Hz power supply.
Ce climatiseur est conforme aux directives suivantes.
Machines 2006/42/CE
Basse tension 2014/35/UE
CEM 2014/30/UE
Équipements sous pression 2014/68/UE
RoHS 2011/65/UE
Écoconception 2009/125/CE
La marque CE s'applique aux régions alimentées en courant de 50 Hz.
Diese Klimaanlage erfüllt die folgende Richtlinie.
Maschinen 2006/42/EC
Niederspannung 2014/35/EU
EMV 2014/30/EU
Druckgeräte 2014/68/EU
RoHS 2011/65/EU
Ökodesign 2009/125/EC
Die CE-Marke gilt für Bereiche mit einer Netzstromversorgung von 50 Hz.
Questo condizionatore d'aria è conforme alla seguente direttiva.
Macchinario 2006/42/CE
Bassa tensione 2014/35/UE
EMC 2014/30/UE
Apparecchiature a pressione 2014/68/UE
RoHS 2011/65/UE
Ecodesign 2009/125/CE
Il marchio CE è applicabile alla fascia di alimentazione 50 Hz.
MANUEL DE L'UTILISATEUR
ANWENDERHANDBUCH
ISTRUZIONI PER L'USO
MANUAL DEL PROPIETARIO
GEBRUIKERSHANDLEIDING
MANUAL DO UTILIZADOR
РУКОВОДСТВО ПО ЗКСПЛУАТАЦИИ
Este aire acondicionado cumple con la siguiente directiva.
Máquinas 2006/42/CE
Baja tensión 2014/35/UE
EMC 2014/30/UE
Equipos a presión 2014/68/UE
RoHS 2011/65/UE
Ecodiseño 2009/125/CE
La indicación CE sólo corresponde al área de suministro eléctrico de 50 Hz.
Deze airconditioner voldoet aan de volgende richtlijn.
Machine 2006/42/EC
Laagspanning 2014/35/EU
EMC 2014/30/EU
Drukapparatuur 2014/68/EU
RoHS 2011/65/EU
Ecodesign 2009/125/EC
CE-markering is van toepassing op het gebied met een netstroom van 50 Hz.
Este ar condicionado está em conformidade com as seguintes directivas.
Máquinas 2006/42/CE
Baixa tensão 2014/35/UE
EMC 2014/30/UE
Equipamentos sob pressão 2014/68/UE
RoHS 2011/65/UE
Concessão ecológica 2009/125/CE
A marca CE aplica-se à zona de fornecimento de energia a 50 Hz.
Το συγκεκριμένο κλιματιστικό συμμορφώνεται προς καθεμιά από
τις οδηγίες που ακολουθούν.
2006/42/ΕΚ περί μηχανημάτων
2014/35/ΕΕ περί χαμηλής τάσης
2014/30/ΕΕ περί ηλεκτρομαγνητικής συμβατότητας (EMC)
2014/68/ΕΕ περί εξοπλισμού υπό πίεση
2011/65/ΕΕ RoHS
2009/125/ΕΚ περί οικολογικού σχεδιασμού
Tο σήμα CE ισχύει μόνον σε περιοχές όπου η τροφοδοσία είναι 50 Hz
ORIGINAL INSTRUCTIONS
RCN-E2,RCN-EK2
USER'S MANUAL
ОΔНГІЕΣ ХРНΣНΣ
KULLANIM KILAVUZU
PJZ012A128B
ENGLISH
FRANÇAIS
DEUTSCH
ITALIANO
ESPAÑOL
NEDERLANDS
PORTUGUÊS
ЕΛΛΗNIKA
РУССКИЙ
TÜRKÇE
D
201808
Advertisement
Table of Contents
Related Manuals for Mitsubishi RCN-EK2
Summary of Contents for Mitsubishi RCN-EK2
- Page 1 ORIGINAL INSTRUCTIONS WIRELESS REMOTE CONTROL RCN-E2,RCN-EK2 USERꞌS MANUAL USER’S MANUAL ENGLISH MANUEL DE L’UTILISATEUR FRANÇAIS ANWENDERHANDBUCH DEUTSCH ISTRUZIONI PER L’USO ITALIANO MANUAL DEL PROPIETARIO ESPAÑOL GEBRUIKERSHANDLEIDING NEDERLANDS MANUAL DO UTILIZADOR PORTUGUÊS ОΔНГІЕΣ ХРНΣНΣ ЕΛΛΗNIKA РУКОВОДСТВО ПО ЗКСПЛУАТАЦИИ РУССКИЙ KULLANIM KILAVUZU TÜRKÇE...
-
Page 3: Table Of Contents
Thank you very much for your purchasing the WIRELESS REMOTE CONTROL for our packaged air conditioner. This user's manual describes cautions for safety. Please read this manual carefully before use in order to operate the unit properly. Keep this manual, after reading, at a safe place where you can consult it whenever it is ENGLISH necessary. -
Page 4: Before You Use
❚ 1. BEFORE YOU USE Safety precautions • Please read the precautions written here carefully to operate the unit properly. You are required to observe these fully because every item of these instructions is important for safety. Failure to follow these instructions may result in serious WARNING consequences such as death, severe injury, etc. - Page 5 CAUTION Do not use or let use the unit or remote control as play equipment. Improper operations could cause ill health or health disorder. Never disassemble the remote control. If you touch internal parts accidentally, you could get electric shocks or cause trouble. Do not wash the remote control with water or liquid.
-
Page 6: Names And Functions Of Remote Control Button
❚ 2. NAMES AND FUNCTIONS OF REMOTE CONTROL BUTTON INDICATION BOARD AND BACKUP SWITCH ■ Ceiling suspended (FDE) ■ Ceiling cassette -4 way- (FDT) ■ Ceiling cassette -4 way Compact- (FDTC) ■ Ceiling cassette -1 way- (FDTS) REMOTE CONTROL SIGNAL RECEIVING SECTION Receives a signal from the remote control. - Page 7 Indicates the selected air flow volume. UP/DOWN AIRFLOW Indicates the up/down louver position. display LEFT/RIGHT AIRFLOW Indicates the left/right louver position.(RCN-EK2 only) display Indicates the current time. If the timer is set, the ON Clock display TIMER and OFF TIMER setting times are indicated.
- Page 8 CAUTION CAUTIONS ON SWITCH OPERATIONS WIRELESS REMOTE CONTROL HANDLING PROCEDURE REPLACING THE BATTERIES If the following occurs, the batteries are exhausted. Replace them with new ones. • When the signal is transmitted, the air conditioner does not display reception. • The display fades away or does not show anything. ■...
-
Page 9: How To Operate
FAN..TEMP setting is unnecessary necessary. The conditions which were set previously are indicated on the remote control. Press the 3D AUTO button. (RCN-EK2 only) OPERATION Switch whether or not to enable or disable 3D AUTO mode. Press ON/OFF button. -
Page 10: Current Time Setting Procedure
❚ 4. CURRENT TIME SETTING PROCEDURE The timer is set based on the current [EXAMPLE] 13:00 setting time. Adjust the current time correctly Press TIME SET UP switch. at first of all. Press it with the tip of ballpoint etc. The time display blinks and can be set to the current time. -
Page 11: Sleep Timer Operation
❚ 7. SLEEP TIMER OPERATION The operation stops at the specified [EXAMPLE] If you would like to stop the operation 12 hours later time. Press SLEEP button. The OFF TIMER indicator LED lights up. “1H” is displayed. The timer/check indicator LED lights up on the remote control signal receiver. The display changes as shown below each time the SLEEP button is pressed. -
Page 12: Indoor Function Settings (Available Only With Master Wireless Receiver)
❚ 9. INDOOR FUNCTION SETTINGS (Available only with master wireless receiver) How to set indoor functions This user’s manual describes how to set the indoor unit functions after installation 1 Press the ON/OFF button to stop the unit. (power-on) has been completed. 2 Press the desired one of the buttons shown item while holding down the FUNCTION SETTINGS switch. -
Page 13: Backup Switch Operation
❚ 10. BACKUP SWITCH OPERATION If the batteries are exhausted, or the remote control is malfunctioning or lost, you can use the BACK UP switch on the display section on the body to run or stop the air conditioner as an emergency measure. ■... - Page 14 5 The Square, Stockley Park, Uxbridge, Middlesex, UB11 1ET, United Kingdom Tel : +44-333-207-4072 Fax : +44-333-207-4089 http ://www.mhiae.com MITSUBISHI HEAVY INDUSTRIES AIR - CONDITIONERS AUSTRALIA, PTY. LTD. 9C Commercial Road Kingsgrove NSW 2208 PO BOX 318 Kingsgrove NSW 1480 Tel : +61-2-8571-7977 Fax : +61-2-8571-7992 http ://www.mhiaa.com.au...
