Mitsubishi RCN-E2 User Manual
Wireless remote control
Hide thumbs
Also See for RCN-E2:
- User manual (16 pages) ,
- User manual (16 pages) ,
- User manual (14 pages)
Table of Contents
Advertisement
Quick Links
WIRELESS REMOTE CONTROL
USERꞌS MANUAL
This air-conditioner complies with following directive.
Machinery 2006/42/EC
Low Voltage 2014/35/EU
EMC 2014/30/EU
Pressure Equipment 2014/68/EU
RoHS 2011/65/EU
Ecodesign 2009/125/EC
CE marking is applicable to the area of 50 Hz power supply.
Ce climatiseur est conforme aux directives suivantes.
Machines 2006/42/CE
Basse tension 2014/35/UE
CEM 2014/30/UE
Équipements sous pression 2014/68/UE
RoHS 2011/65/UE
Écoconception 2009/125/CE
La marque CE s'applique aux régions alimentées en courant de 50 Hz.
Diese Klimaanlage erfüllt die folgende Richtlinie.
Maschinen 2006/42/EC
Niederspannung 2014/35/EU
EMV 2014/30/EU
Druckgeräte 2014/68/EU
RoHS 2011/65/EU
Ökodesign 2009/125/EC
Die CE-Marke gilt für Bereiche mit einer Netzstromversorgung von 50 Hz.
Questo condizionatore d'aria è conforme alla seguente direttiva.
Macchinario 2006/42/CE
Bassa tensione 2014/35/UE
EMC 2014/30/UE
Apparecchiature a pressione 2014/68/UE
RoHS 2011/65/UE
Ecodesign 2009/125/CE
Il marchio CE è applicabile alla fascia di alimentazione 50 Hz.
MANUEL DE L'UTILISATEUR
ANWENDERHANDBUCH
ISTRUZIONI PER L'USO
MANUAL DEL PROPIETARIO
GEBRUIKERSHANDLEIDING
MANUAL DO UTILIZADOR
РУКОВОДСТВО ПО ЗКСПЛУАТАЦИИ
Este aire acondicionado cumple con la siguiente directiva.
Máquinas 2006/42/CE
Baja tensión 2014/35/UE
EMC 2014/30/UE
Equipos a presión 2014/68/UE
RoHS 2011/65/UE
Ecodiseño 2009/125/CE
La indicación CE sólo corresponde al área de suministro eléctrico de 50 Hz.
Deze airconditioner voldoet aan de volgende richtlijn.
Machine 2006/42/EC
Laagspanning 2014/35/EU
EMC 2014/30/EU
Drukapparatuur 2014/68/EU
RoHS 2011/65/EU
Ecodesign 2009/125/EC
CE-markering is van toepassing op het gebied met een netstroom van 50 Hz.
Este ar condicionado está em conformidade com as seguintes directivas.
Máquinas 2006/42/CE
Baixa tensão 2014/35/UE
EMC 2014/30/UE
Equipamentos sob pressão 2014/68/UE
RoHS 2011/65/UE
Concessão ecológica 2009/125/CE
A marca CE aplica-se à zona de fornecimento de energia a 50 Hz.
Το συγκεκριμένο κλιματιστικό συμμορφώνεται προς καθεμιά από
τις οδηγίες που ακολουθούν.
2006/42/ΕΚ περί μηχανημάτων
2014/35/ΕΕ περί χαμηλής τάσης
2014/30/ΕΕ περί ηλεκτρομαγνητικής συμβατότητας (EMC)
2014/68/ΕΕ περί εξοπλισμού υπό πίεση
2011/65/ΕΕ RoHS
2009/125/ΕΚ περί οικολογικού σχεδιασμού
Tο σήμα CE ισχύει μόνον σε περιοχές όπου η τροφοδοσία είναι 50 Hz
ORIGINAL INSTRUCTIONS
RCN-E2,RCN-EK2
USER'S MANUAL
О∆НГІЕΣ ХРНΣНΣ
KULLANIM KILAVUZU
PJZ012A128
ENGLISH
FRANÇAIS
DEUTSCH
ITALIANO
ESPAÑOL
NEDERLANDS
PORTUGUÊS
ЕΛΛΗNIKA
РУССКИЙ
TÜRKÇE
A
201612
Advertisement
Table of Contents
Related Manuals for Mitsubishi RCN-E2
Summary of Contents for Mitsubishi RCN-E2
- Page 1 ORIGINAL INSTRUCTIONS WIRELESS REMOTE CONTROL RCN-E2,RCN-EK2 USERꞌS MANUAL USER’S MANUAL ENGLISH MANUEL DE L’UTILISATEUR FRANÇAIS ANWENDERHANDBUCH DEUTSCH ISTRUZIONI PER L’USO ITALIANO MANUAL DEL PROPIETARIO ESPAÑOL GEBRUIKERSHANDLEIDING NEDERLANDS MANUAL DO UTILIZADOR PORTUGUÊS О∆НГІЕΣ ХРНΣНΣ ЕΛΛΗNIKA РУКОВОДСТВО ПО ЗКСПЛУАТАЦИИ РУССКИЙ KULLANIM KILAVUZU TÜRKÇE...
-
Page 3: Table Of Contents
Thank you very much for your purchasing the WIRELESS REMOTE CONTROL for our packaged air conditioner. This user's manual describes cautions for safety. Please read this manual carefully before use in order to operate the unit properly. Keep this manual, after reading, at a safe place where you can consult it whenever it is ENGLISH necessary. -
Page 4: Before You Use
❚ 1. BEFORE YOU USE Safety precautions • Please read the precautions written here carefully to operate the unit properly. You are required to observe these fully because every item of these instructions is important for safety. Failure to follow these instructions may result in serious WARNING consequences such as death, severe injury, etc. - Page 5 CAUTION Do not use or let use the unit or remote control as play equipment. Improper operations could cause ill health or health disorder. Never disassemble the remote control. If you touch internal parts accidentally, you could get electric shocks or cause trouble. Do not wash the remote control with water or liquid.
-
Page 6: Names And Functions Of Remote Control Button
❚ 2. NAMES AND FUNCTIONS OF REMOTE CONTROL BUTTON INDICATION BOARD AND BACKUP SWITCH ■ Ceiling suspended (FDE) ■ Ceiling cassette -4 way- (FDT) ■ Ceiling cassette -4 way Compact- (FDTC) ■ Ceiling cassette -1 way- (FDTS) REMOTE CONTROL SIGNAL RECEIVING SECTION Receives a signal from the remote control. - Page 7 ■ Wall mounted (FDK) BACK UP SWITCH When the remote control is missing or defective, this switch can start and stop the air conditioner. RUN LED (GREEN) • Continuous lighting: During operation • Continuous blinking: ”PREPARATION OF HEATING” • Triple blinks: Indicates that a signal has been received from the remote control. •...
-
Page 8: How To Insert Batteries
CAUTION CAUTIONS ON SWITCH OPERATIONS WIRELESS REMOTE CONTROL HANDLING PROCEDURE REPLACING THE BATTERIES If the following occurs, the batteries are exhausted. Replace them with new ones. • When the signal is transmitted, the air conditioner does not display reception. • The display fades away or does not show anything. ■... -
Page 9: How To Operate
❚ 3. HOW TO OPERATE ATTENTION • Turn on the power supply of both indoor/outdoor units for six hours before starting the unit to protect the units. (The crankcase is conducted and the compressor is heated) Do not turn off the power supply. (The crankcase heater is conducted while the compressor is stopped, preventing failure of the compressor due to accumulation of liquid refrigerant by keeping the compressor warm.) •... -
Page 10: Current Time Setting Procedure
❚ 4. CURRENT TIME SETTING PROCEDURE The timer is set based on the current [EXAMPLE] 13:00 setting time. Adjust the current time correctly Press TIME SET UP switch. at first of all. Press it with the tip of ballpoint etc. The time display blinks and can be set to the current time. -
Page 11: Sleep Timer Operation
❚ 7. SLEEP TIMER OPERATION The operation stops at the specified [EXAMPLE] If you would like to stop the operation 12 hours later time. Press SLEEP button. The OFF TIMER indicator LED lights up. “1H” is displayed. The timer/check indicator LED lights up on the remote control signal receiver. The display changes as shown below each time the SLEEP button is pressed. -
Page 12: Indoor Function Settings (Available Only With Master Wireless Receiver)
❚ 9. INDOOR FUNCTION SETTINGS (Available only with master wireless receiver) How to set indoor functions This user’s manual describes how to set the indoor unit functions after installation 1 Press the ON/OFF button to stop the unit. (power-on) has been completed. 2 Press the desired one of the buttons shown item while holding down the FUNCTION SETTINGS switch. -
Page 13: Check Indication
❚ 11. CHECK INDICATION If the following LED blinks or any code appears on the monitor display, it indicates that an error has occurred in the air conditioner. Please contact your dealer and inform them “address No. and check code”, “symptom of the trouble”, “air conditioner type”... -
Page 14: Filter Sign
❚ 12. FILTER SIGN If the FILTER SIGN LED blinks as shown below, clean the filter. ■ Ceiling suspended (FDE) ■ RCN-KIT4-E2 CHECK MODE CHECK TIMER/CHECK LED FILTER RUN/ TIMER CHECK CHECK ■ Ceiling cassette (FDT) ■ Ceiling cassette-4 way Compact (FDTC) FILTER SIGN ■... - Page 16 7 Roundwood Avenue, Stockley Park, Uxbridge, Middlesex, UB11 1AX, United Kingdom Tel : +44-20-7025-2750 Fax : +44-20-7025-2751 http ://www.mhiae.com MITSUBISHI HEAVY INDUSTRIES AIR - CONDITIONERS AUSTRALIA, PTY. LTD. 9C Commercial Road Kingsgrove NSW 2208 PO BOX 318 Kingsgrove NSW 1480 Tel : +61-2-8571-7977 Fax : +61-2-8571-7992 http ://www.mhiaa.com.au...
