Cooper Lighting C CIRRUS CAS17MWW3D Specification Sheet

A R E A
C CIRRUS
A R C H I T E C T U R A L A R E A L U M I N A I R E
STREETWORKS ™
S T R U C T U R A L F R A M E O R D E R I N G I N F O R M AT I O N
Heavy-duty, die-cast aluminum frame
S A M P L E N U M B E R
is the main load-bearing structure for
arm, yoke or spider mountings and
PRODUCT
serves as a heat sink for cooler
FAMILY 1
operation and longer ballast life. Each
CAS=Arm Solid Top
optional package seats within the
CSS=Spider Solid Top
frame for precise photometric
CYS=Yoke Solid Top
repeatability. CAP=Arm Luminous Top
CSP=Spider Luminous Top
H O U S I N G
CYP=Yoke Luminous Top
Spun-aluminum top is finished in
polyester powder coat enamel. Round
shape reduces EPA and size of poles
required. ANSI wattage/source label.
O P T I O N S + A C C E S S O R I E S
O P T I C A L S Y S T E M
OPTIONS (add as suffix)
Cirrus offers a broad selection of
1=Single Fused, Internally Mounted (120 or 277)
premium performance segmented
2=Double Fused, Internally Mounted (208, 240, or 480V)
and hydroformed optical systems
4=Photocontrol Receptacle
designed to optimize pole spacings
WH=White
and curtail spill light.
BK=Black
D O O R
AP=Grey
Die-cast aluminum door frame has
DP=Dark Platinum
concealed hinges and is flush with the
B=House Side Shield
bottom of the housing.
P=Button Photocontrol
L E N S
Thermal shock- and impact-resistant
O P T I O N A L C O L O R S
clear tempered glass.
B A L L A S T A S S E M B LY
Long life core-and-coil HID ballast is
WH
hard mounted for cooler
White
operation.
S O C K E T
Porcelain screw-shell socket fits
mogul-base HID lamps.
S H I P P I N G D ATA
NOTE: 1 Small up to 175W. Medium 250 to 400W. Large 1000W. 2 Luminous dome available in 250W maximum and designed to fit 5" poles. Luminous units only available in 120 or 277V. 3 Medium-base lamp. 4 Refer to technical
Approximate Net Weight:
section for lamp/ballast/voltage compatibility. 5 70-150W max. 6 Segmented optics available on solid top designs and small/medium housings only. Max wattage on small segmented optics is Medium Base 175W. Reduce
65 lbs. (30 kgs.)
jacket lamp required on 400W MH. 7 Not available in 1000W. 8 Available for small and medium units only. 9 Not available in 250 HPS.
98 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
NOTE: In solid top configuration only.
IP55 RATED
: C A S 1 7 M W W 3 D
LAMP LAMP TYPE 4
S=High Pressure Sodium
WATTAGE
M=Metal Halide
70=70W
R=SMH
10=100W 3
15=150W
2 17=175W
2 25=250W
40=400W
2
91=1000W
[ M u s t b e l i s t e d i n t h e o r d e r s h o w n a n d s e p a r a t e d b y a d a s h ]
[ S t a n d a r d c o l o r i s b r o n z e , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BK AP
Black Grey
A
Yoke Mount
FIXTURE
SMALL (in.)
S (mm)
MEDIUM (in.)
(mm)
LARGE (in.)
(mm)
BALLAST TYPE 4 VOLTAGE
P=Hi. Reac./HPF 2=120V
W=CWA 0=208V
C=CWI 4=240V
K=10KV CWA 5 7=277V
8=480V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
ACCESSORIES (order separately)
MA1001=Wall Bracket for Solid Top units
MA1003=Wall Bracket for Luminous Top units
DP GM
Dark Platinum Graphite Metallic
MH/HPS/SMH
B
C
Spider Mount / Arm Mount
A B C
20 1/2 10 1/4 11
521 260 279
24 12 1/8 12 5/8
610 308 321
28 14 1/4 16
610 362 406
4 DISTRIBUTION 6
1D=Type I MCO 7
2D=Type II MCO
3D=Type III MCO
4D=Type IV MCO
5D=Type V MCO 7
2S=Type II Segmented
3S=Type III Segmented
4S=Type IV Segmented
5S=Type V Segmented
SL=Spill Light Eliminator
8
9
C o o p e r L i g h t i n g
70-1000W
D
D
6
152
7 /2
191
9
229
OPTIONS +
ACCESSORIES
(See Below)
7
7
7
7
7
