Cooper Lighting CX Series Specification

D I M E N S I O N S
5 1/16" [129mm]
12 5/8" [321mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : C X 7 1 7 0 R S D
CX
Battery
Family
Blank=No
CX=Die Cast
Battery (CX6)
Aluminum
70=Nickel
Exit
Cadmium
Series
Battery (CX7)
6=AC Only, LED
7=Self-Powered,
LED
Face Options
1=Single
2=Double
E n e r g y D a t a — S e l f - P o w e r e d E x i t s
LED Exits -Red Letters
LED Exits -Green Letters
E n e r g y D a t a — A C O n l y E x i t s
LED Exits -Red Letters
LED Exits -Green Letters
COOPER LIGHTING - SURE-LITES
[111mm]
15/16" [24mm]
8 1/4"
(210mm)
[57mm]
S e l f - D i a g n o s t i c s
The self-diagnostic unit will automatically perform all
tests required by UL924 and NFPA 101. The system
indicates the status of the unit at all times using the
LED indicator near the test switch on the side of the
unit. A 90 minute battery power (emergency mode)
simulation test will occur randomly once every six
months.
SD=Self-
Letter Colors Housing
Diagnostic
R=Red Finishes
*(CX7 only)
G=Green Blank=
Brushed
Aluminum
Face with
Black
Housing
W=White
B=Black
Sealed Nickel Cadmium Battery
Input Power: Input Current (Max.):
120V 277V 120V 277V
LED Exits
2.8W 2.9W .03A .02A
3.9W 3.6W .08A .04A
Input Power: Input Current (Max.):
120V 277V 120V 277V
LED Exits
2.4W 2.5W .03A .02A
3.2W 3.0W .08A .03A
D E S C R I P T I O N
The CX Surface Mounted Die
4 3/8"
Cast Aluminum Exit combines
the strength and durability of
die casting with the bright
even illumination of LED lamp
sources. Unlike competitive
units that have a pronounced
dot effect from protruding
diodes, the CX LED offers
unequalled uniform
illumination and brightness.
The CX Self-Powered LED
comes standard with the
Watchguard EMS
self-diagnostic system insuring
fixture reliability and reducing
2 1/4"
maintenance costs.
Options
Accessories (Order Separately)
2C=Two Circuit
CAX18PKBK=18" Pendant Kit,
Operation,
Black
FTBR
CAX18PKWH=18" Pendant Kit,
(CX6 Only)
White
CAX18PKHTBK=18" Hang-True
Pendant Kit, Black
CAX18PKHTWH=18" Hang-True
Pendant Kit, White
VS1=Polycarbonate Vandal Shield
(Wall Mount Only)
VS1WP=Weather Resistant
Polycarbonate Vandal
Shield (Wall Mount Only)
WG10=Wire Guard (Wall Mount
Only)
WGS11=Wire Guard (Ceiling or
End Mount Only)
Power Factor:
120V 277V
> .81 > .77
> .41 > .43
Power Factor:
120V 277V
> .78 > .73
> .33 > .35
CX SERIES
• Dual-voltage Input
120/277 VAC, 60 Hz,
isolation transformer
• Die cast aluminum housing
• Die cast canopy included
• LED Lamping
• Watchguard EMS
Self-Diagnostic System
(CX7 Only)
• Exit can be universally
mounted ceiling, wall
or end
• Universal pattern knock-
outs on rear of single
face housing for direct
mounting to junction box
• NFPA 101 compliant
knockout chevrons allow
quick conversion to
directional signs
• Self-powered Exits feature
line-latching, solid-state
voltage limited charger,
low-voltage disconnect,
brownout circuit, over-
load/short-circuit
protection, test switch/
power indicator light
• Damp Location Listed (AC
Only), UL 924 Listed, CSA
Certified, Life Safety NFPA
101, NEC/OSHA, Energy
Star Listed, AC Only-UL
FTBR when specified with
T.H.D.:
the "2C" option, most state
120V 277V
and local codes, suitable for
floor proximity installation.
< 32% < 46%
< 48% < 49%
T.H.D.:
120V 277V
< 33% < 48%
< 50% < 52%
COOPER LIGHTING
®
D i e C a s t
A C O n l y
S e l f - P o w e r e d
E X I T L I G H T I N G
633
