[a] Select Display Resolution
[0] Exit and Continue
Selection:a
4） Select a proper display mode in the following menu according to your
display device;
--------------------------------------------------------------------------------
Select Display Resolution
--------------------------------------------------------------------------------
[1] LCD 480x272 60Hz
[2] DVI 640x480 60Hz
[3] DVI 640x480 72Hz
[4] LCD 800x480 60Hz
[5] DVI 800x600 60Hz
[6] DVI 800x600 56Hz
[7] VGA 1024x768 60Hz
[8] DVI 1280x720 60Hz
[0] Exit and Continue
Selection (actual LCD 480x272 60Hz):4
5） Type 7 and y in the following menu to save settings, and then type number 0
to continue booting system;
Main Menu
--------------------------------------------------------------------------------
[1] Show Current Settings
[2] Select Boot Device
[3] Select KITL (Debug) Device
[4] Network Settings
[5] SDCard Settings
[6] Set Device ID
[7] Save Settings
[8] Flash Management
[9] Enable/Disable OAL Retail Messages
[a] Select Display Resolution
[0] Exit and Continue
Copyright © 2013 Embest Technology
Table 4-3 Select Display Mode
//4.3-inch LCD display, default device
//7-inch LCD display
// LVDS display
// VGA display
Table 4-4 Continue Booting
