Installation Instructions
Original Instructions
ASEM 6300 On-Machine Monitors and On-Machine Panel PCs
Catalog Numbers 6300MA, 6300PA
Topic
ATTENTION: Read this document and the documents listed in the
equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring
instructions in addition to requirements of all applicable codes, laws, and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, safety, and maintenance are required to be carried out
by suitably trained personnel in accordance with applicable code of practice. If this equipment is used in a manner not specified by the manufacturer,
the protection provided by the equipment may be impaired.
Compliance
ATTENTION: If a SIL-3 E-stop button is used, familiarize yourself with the Safety section in the ASEM™ On-Machine™ User Manual,
publication 6300-UM002.
UL/cUL Mark Compliance
Equipment with the UL/cUL mark complies with the requirements of UL 61010-1, UL 61010-2-201, CSA C22.2 No. 61010-1, and CSA C22.2 No. 61010-2-201.
A copy of the certificate of compliance is available at rok.auto/certifications.
European Union Directive Compliance
This equipment meets the European Union Directive requirements when installed within the European Union or EEA regions and have the CE marking.
A copy of the declaration of the conformity is available at rok.auto/certifications.
ATTENTION: This equipment is intended to operate in an industrial or control room environment, which uses some form of power isolation from the
public low-voltage mains. Some computer configurations cannot comply with the EN 61000-3-2 Harmonic Emissions standard as specified by the EMC
Directive of the European Union.
All I/O cables must be used only indoors.
Page
1
2
2
2
2
3
3
4
5
6
6
6
6
7
Additional Resources
section about installation, configuration, and operation of this
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Allen-Bradley ASEM 6300
Summary of Contents for Rockwell Automation Allen-Bradley ASEM 6300
-
Page 1: Table Of Contents
Installation Instructions Original Instructions ASEM 6300 On-Machine Monitors and On-Machine Panel PCs Catalog Numbers 6300MA, 6300PA Topic Page Compliance Product Overview Required Tools and Optional Accessories Approximate Dimensions Environmental Requirements Mounting Requirements Prepare for Installation Installation Connect DC Power Attach Peripheral Cables Mount the On-Machine Product Reattach the Cover Complete the Installation... -
Page 2: Product Overview
The inrush current cannot exceed a peak current of 10 A and a pulse width 245.80 (9.68) 282.60 (11.13) 320.20 (12.61) 352.8 (13.89) time of 400 μs. 304.30 (11.98) 341.10 (13.43) 378.70 (14.91) 411.3 (16.19) 58.50 (2.30) 58.50 (2.30) 58.50 (2.30) 58.50 (2.30) Rockwell Automation Publication 6300-IN001A-EN-P - June 2023... -
Page 3: Mounting Requirements
Use a 2.5 mm torque-limiting screwdriver to remove the M3 screws from the cover. Bottom Arm Mount Top Arm Mount VESA Mount Set the screws and cover aside. The ground screw, terminal ports, I/O ports, and slots are now accessible. Rockwell Automation Publication 6300-IN001A-EN-P - June 2023... -
Page 4: Installation
There are several optional accessories available for your On-Machine product: side handles or a perimeter handle and keyboard support tray. For ordering information, see publication 6300V-PC005). Follow the steps in publication 6300-UM002 to attach these optional accessories. Rockwell Automation Publication 6300-IN001A-EN-P - June 2023... -
Page 5: Connect Dc Power
13. Use the plastic screwdriver (supplied) to torque the DC terminal block flange screws to 0.3 N•m (0.22 ft•lb) (see Note No. 5, Table 14. Insert the DC power wires through the mounting area of your On-Machine product cover. Rockwell Automation Publication 6300-IN001A-EN-P - June 2023... -
Page 6: Attach Peripheral Cables
Install the Ground Wire on page 5). Follow all guidelines listed in Power Requirements on page A light emitting diode (LED) status indicator illuminates on the lower left front bezel of your On-Machine product. Rockwell Automation Publication 6300-IN001A-EN-P - June 2023... -
Page 7: Additional Resources
