Page 1 Mail: Sales.IA.RU@deltaww.com TEL: +7 495 644 3240 Delta Electronics ( Americas ) Ltd. USA: Delta Greentech Elektronik San. Ltd. Sti. ( Turkey ) 5101 Davis Drive, Research Triangle Park, NC 27709, U.S.A. Turkey: TEL: +1-919-767-3813 / FAX: +1-919-767-3969 Şerifali Mah. Hendem Cad. Kule Sok. No:16-A 34775 Ümraniye –...
Page 2 All information contained in this user manual is the exclusive property of Delta Electronics Inc. (hereinafter referred to as "Delta ") and is protected by copyright law and all other laws. Delta retains the exclusive rights of this user manual in accordance with the copyright law and all other laws. No parts in this manual may be reproduced, transmitted, transcribed, translated or used in any other ways without the prior consent of Delta.
Page 3 Thank you for using Delta's compact built-in CAN communication drive VFD-EL-C series. The VFD-EL-C series is manufactured using high-quality components, materials and incorporating the latest embedded control technology. This product description provides users with precautions related to installation, parameter setting, abnormal diagnosis, troubleshooting and daily maintenance of the drive.
Page 4 When the wiring between the drive and the motor is too long, the interlayer  insulation of the motor may be damaged. Please use an AC motor dedicated to the drive, or install a reactor between the drive and the AC motor (refer to Appendix A) to avoid damage to the AC motor due to insulation damage.
Page 5: Table Of Contents
Table of Contents CHAPTER 1 USE AND INSTALLATION .................. 1-1 1-1 Product Profile......................1-3 1-2 Product Installation.....................1-8 1-3 Product Dimensions....................1-11 CHAPTER 2 WIRING ....................... 4-1 2-1 Wiring Instructions……....................2-3 2-2 System Wiring Diagram....................2-7 2-3 Main circuit terminal description..................2-8 2-4 Control circuit terminal description................2-11 2-5 NPN and PNP modes....................2-13 CHAPTER 3 OPERATION PANEL DESCRIPTION AND TEST RUN ........
Page 6 05 Motor Parameters………………………………………………………………...6-2-051 06 Protection Parameters (1) …………………………………………………..6-2-061 07 Special Parameters…………………………………………………………..6-2-071 09 Communication Parameters………………………………………………..6-2-091 10 Speed Feedback Control Parameters……………………………………..6-2-101 12 System control and CANopen function Parameters……………………..6-2-121 13 Control Mode Parameter Macro Function……………………………………6-2-131 CHAPTER 7 WARNING CODES ....................7-1 CHAPTER 8 FAULT CODES ....................8-1 APPENDIX A.
Page 7 [This page intentionally left blank]...
Page 8: Chapter 1 Use And Installation
Chapter 1 Use and InstallationEL-C Chapter 1 Use and Installation 1-1 Product Profile 1-2 Product Installation 1-3 Product Dimensions...
Page 9 Chapter 1 Use and InstallationEL-C The product should be in the box when customers received. If the machine is not used temporarily, for the safety of the maintenance during the warranty period of our company, be sure to pay attention to the following points when storing the machine: The machine must be placed in a ventilated, dust-free and dry location.
Page 10: Product Profile
Chapter 1 Use and InstallationEL-C 1-1 Product Profile Each VFD-EL-C is subject to strict quality control and enhanced anti-collision packaging before shipment. After the customer unpacks the drive, please carry out the following inspection steps immediately. Check whether the drive has been damaged during transportation. ...
Page 11 Chapter 1 Use and InstallationEL-C Appearance Frame A1 A: Digital keypad Input terminals B: Control terminals (R/L1, S/L2, T/L3) C: CAN Connect 1 (RJ45) D: CAN Connect 2 (RJ45) Digital keypad Control board cover Output terminals (U/T1, V/T2, W/T3) Ground terminals Frame A2 A: Digital keypad Input terminals...
Page 12 Chapter 1 Use and InstallationEL-C Frame B A: Digital keypad Input terminals B: Control terminals (R/L1, S/L2, T/L3) C: CAN Connect 1 (RJ45) D: CAN Connect 2 (RJ45) Digital keypad Case Control board cover Output terminals (U/T1, V/T2, W/T3) Ground terminals Frame Capacity Model...
Page 13 Chapter 1 Use and InstallationEL-C RFI Jumper RFI Jumper: (1) The drive contains Varistors / MOVs that are connected from phase to phase and from phase to ground to prevent the drive from unexpected stop or damage caused by mains surges or voltage spikes.
Page 14 Chapter 1 Use and InstallationEL-C Remove step Remove the control terminal slide Remove the fan Press the control board terminal slide cover lightly as Frame B shown in Figure A first, and then slide it down as shown Press the buckles on the left and right sides of in Figure B to remove it easily.
Page 15: Product Installation
Chapter 1 Use and InstallationEL-C 1-2 Product Installation Please install the drive in the following environmental conditions to ensure the safety of the product: Ambient -10°C–+50°C NOTE 1 temperature Rated < 90%, no frosting Humidity Operating Air Pressure 86–106 kPa Environmental Conditions Altitude...
Page 16 Chapter 1 Use and InstallationEL-C Mounting Clearance Inflow Outflow Distance Single drive Side-by-side horizontal installation Zero stack installation installation Minimum distance (mm) Ambient temperature (ºC) Installation Model Max. Max. Method NOTE 1 (Without derating) (derating) Single drive installation VFD002EL21C Side-by-side VFD004EL21C horizontal installation...
Page 17 Chapter 1 Use and InstallationEL-C When the model VFD007EL21C is equipped with a fan accessory, the upper limit of the ambient operating temperature is as shown in the table above; when there is no fan accessory, the upper limit of the corresponding ambient operating temperature is 10ºC lower than the temperature value in the table (refer to Appendix B-3-3 for the installation of fan accessories).
Page 18: Product Dimensions
Chapter 1 Use and InstallationEL-C 1-3 Product Dimensions Frame A1 VFD002EL21C, VFD004EL21C, VFD004EL43C, VFD007EL21C, VFD007EL43C See Detail A Detail A (Mounting Hole) Unit: mm [inch] Frame 92.0 82.0 162.0 152.0 128.7 [3.62] [3.23] [6.38] [5.98] [5.07] [0.08] [0.21] Table 1-4 1-11...
Page 19 Chapter 1 Use and InstallationEL-C Frame A2 VFD015EL43C See Detail A Detail A (Mounting Hole) Unit: mm [inch] Frame 92.0 82.0 180.5 162.0 152.0 128.7 [3.62] [3.23] [7.11] [6.38] [5.98] [5.07] [0.08] [0.21] Table 1-5 1-12...
Page 20 Chapter 1 Use and InstallationEL-C Frame B VFD015EL21C, VFD022EL21C, VFD022EL43C, VFD040EL43C, VFD055EL43C See Detail A See Detail B Detail A (Mounting Hole) Detail B (Mounting Hole) Unit: mm [inch] Frame 100.0 89.0 174.0 162.9 136.0 [3.94] [3.50] [6.85] [6.42] [5.35] [0.16] [0.23] [0.21]...
Page 21 Chapter 1 Use and InstallationEL-C [This page intentionally left blank] 1-14...
Page 22: Chapter 2 Wiring
Chapter 2 Wiring | EL-C Chapter 2 Wiring 2-1 Wiring Instructions 2-2 System Wiring Diagram 2-3 Main circuit terminal description 2-4 Control circuit terminal description 2-5 NPN and PNP modes...
Page 23 Chapter 2 Wiring | EL-C After removing the Input/output side terminal slide cover and control board terminal slide cover, verify that the power and control terminals are clearly noted. Read the following precautions before wiring. Turn off the AC motor drive power before doing any wiring. A charge with hazardous ...
Page 24 Chapter 2 Wiring | EL-C 2-1 Wiring Instructions The wiring is divided into the main circuit and the control circuit, the user must connect according to the following wiring circuits. Recommended Wiring Diagram for VFD-EL-C 230V 1-PHASE VFD002EL21C, VFD004EL21C, VFD007EL21C, VFD015EL21C, VFD022EL21C Figure 2-1 *1.
Page 25 Chapter 2 Wiring | EL-C 460V 3-PHASE: VFD004EL43C, VFD007EL43C, VFD015EL43C, VFD022EL43C, VFD040EL43C, VFD055EL43C Figure 2-2 *1. The MI digital input terminal is switch with NPN/PNP mode. In addition to the correct wiring, it needs to be switched with Pr.02-55. The default setting Pr.02-55 is 0: NPN mode. *2.
Page 26 Chapter 2 Wiring | EL-C Separate the main circuit and control circuit wiring to prevent erroneous actions.  Use shielded wire for the control wiring and do not expose the peeled-off shield in front  of the terminal. Use shielded wire or conduit for the power wiring and ground the two ends of the ...
Page 27 Chapter 2 Wiring | EL-C Proper Wiring Method Figue 2-3 Good Figue 2-4 Not allowed Figue 2-5...
Page 28 Chapter 2 Wiring | EL-C 2-2 System Wiring Diagram Power Input Terminal 电源输入端 Power input Please follow the specific power terminal supply requirements in Chapter 4. Breaker There may be an inrush current during 断路器 power-up. Please check the chart in Fuse Appendix A-1 and select the correct Contactor...
Page 29 Chapter 2 Wiring | EL-C 2-3 Main circuit terminal description Main Circuit Diagram 230V 1-PHASE Breaker Contactor Motor Figue 2-7 460V 3-PHASE Breaker Contactor Motor Figue 2-8 Terminals Descriptions R/L1, S/L2, T/L3 Mains input terminals (one / three-phase) U/T1, V/T2, W/T3 Motor drive output terminals for connecting three-phase induction motor Ground connection.
Page 30 If necessary, use an inductive filter only at the motor output terminals U/T1, V/T2,  W/T3 of the AC motor drive. DO NOT use phase-compensation capacitors or L-C (Inductance-Capacitance) or R-C (Resistance-Capacitance), unless approved by Delta. DO NOT connect phase-compensation capacitors or surge absorbers at the output  terminals of AC motor drives.
Page 31 Chapter 2 Wiring | EL-C Main Circuit Terminal Specifications Frame A1 Frame A2 Frame B Figue 2-9 Figue 2-10 Figue 2-11 Main Circuit Terminals R/L1, S/L2, T/L3,U/T1, V/T2, W/T3, Frame Models Screw & Torque Max. Wire Gauge Min. Wire Gauge (±10%) VFD002EL21C 2.5 mm...
Page 32 Chapter 2 Wiring | EL-C 2-4 Control circuit terminal description Control Terminal Location Diagram Figue 2-12 Terminal Function Description Default (NPN mode, Pr.02-55=0) External terminal control: MI1–MI3 supports the two / three- wire start function. Multi-function Output Communication control: MI1–MI6 can be used as multi- (Default: no function) function input options.
Page 33 Chapter 2 Wiring | EL-C Main Circuit Terminal Specifications Frame Model Wire Gauge Double row terminal torque (±10%) VFD002EL21C VFD004EL21C VFD004EL43C VFD007EL21C VFD007EL43C 24–18 AWG VFD015EL43C 2 kg-cm [1.7 lb-in] [0.2 Nm] [0.2–0.8 mm VFD015EL21C VFD022EL21C VFD022EL43C VFD040EL43C VFD055EL43C Table 2-4 2-12...
Page 34 Chapter 2 Wiring | EL-C 2-5 NPN and PNP mode NPN/PNP Internal power supply External power supply NPN/Sink Mode Parameter Parameter Control Control Pr.02-55=0 PNP/Sourse Mode Parameter Parameter Control Control Pr.02-55=1 Table 2-5 Note: 1. In NPN/PNP mode, in addition to the correct wiring according to the above figure, it is also necessary to match the Pr.02-55 setting for internal circuit switching (defaultis 0: NPN mode).
Page 35 Chapter 2 Wiring | EL-C [This page is intentionally left blank] 2-14...
Page 36: Chapter 3 Operation Panel Description And Test Run
Chapter 3 Operation panel description and test run | EL-C Chapter 3 Operation panel description and test run 3-1 Panel Description 3-2 Operation mode 3-3 Test run...
Page 37 Chapter 3 Operation panel description and test run | EL-C Please check the wiring again before running. Especially the output terminals U/T1,  V/T2 and W/T3 cannot be connected to the input power supply, and the grounding terminal E is well grounded. Check the motor is not connected to the load mechanism.
Page 38: Panel Description
Chapter 3 Operation panel description and test run | EL-C 3-1 Panel Description VFD-EL-C series operate and display functions through a digital operation panel. VFD-EL-C CRUN CERR MODE selection RUN key 模式选择键运行键 STOP/RESET key 停止/复位键  Status Display Display the drive’s current status: RUN, STOP, FWD, REV, CAN RUN, CAN ERROR ...
Page 39 Chapter 3 Operation panel description and test run | EL-C Descriptions of keypad functions Displayed items Descriptions Displays the present frequency setting for the drive. Displays the actual output frequency to the drive. Displays the user-defined output of a physical quantity (U = F x Pr.00-05). Displays the load current.
Page 40 Chapter 3 Operation panel description and test run | EL-C Keypad Operation Process Setting Mode S TAR T MODE MODE MODE MODE MODE GO START NOTE: In the selection mode, press to set the parameters. MODE Setting parameters Input data error Success to ENTER ENTER...
Page 41: Operation Mode
Chapter 3 Operation panel description and test run | EL-C 3-2 Operation mode To select digital operator, external control terminal, RS-485 communication or CANopen communication by Pr.00-20 and 00-21. A: Digital keypad B: Control terminals C: CAN Connect 1 (RJ45) D: CAN Connect 2 (RJ45)
Page 42 Chapter 3 Operation panel description and test run | EL-C Operation mode Operation Command Digital Keypad Pr.00-20 = 0 Figure 3-1 RUN、STOP / RESET as shown in the figure External control terminal Pr.00-20 = 1 Figure 3-2 The default is NPN mode, MI1-DCM short-circuit is forward / stop, and MI2- DCM short-circuit is reverse / stop (default).
Page 43: Test Run
Chapter 3 Operation panel description and test run | EL-C 3-3 Test run The default of this product is to perform test run on the digital operation panel, as follows: After turning on the power, confirm the digital keypad LED displays the ...
Page 44: Chapter 4 Specification
Chapter 4 Specification | EL-C Chapter 4 Specification 4-1 230V 1φ Models 4-2 460V 3φ Models 4-3 General Specifications 4-4 Environmental Specifications 4-5 Operating ambient temperature and Carrier Derating...
Page 45 Chapter 4 Specification | EL-C VFD-EL-C series includes 230V and 460V models. The 230V model is single-phase model, and the 460V model is three-phase model. Please refer to the following specification table. 4-1 230V 1φ Models □□□ Model EL21C Applicable Motor Output (kW) 0.75...
Page 46 Chapter 4 Specification | EL-C 4-2 460V 3φ Models □□□ Model EL43C Applicable Motor Output (kW) 0.75 Applicable Motor Output (HP) Rated Output Capacity (kVA) 10.4 Rated Output Current (A) Output Max. Output Voltage (V) Three-phase corresponding input voltage Output Frequency (Hz) 0.1–400 Hz Carrier Frequency (kHz) 2–9 kHz (Default: 2 kHz )
Page 47 Chapter 4 Specification | EL-C 4-3 General Specifications Performance Descriptions Control Method Sine wave PWM method / (V/F control) Frequency Setting Resolution 0.01Hz Output Frequency Resolution 0.01Hz Torque compensation and slip compensation, reach 150% of the Torque rated torque at 5.0 Hz Overload Capability 150% of rated output current for 60 seconds Skip Frequency...
Page 48 Chapter 4 Specification | EL-C 4-4 Environment Performance Descriptions Protection Rating IP20 Degree of environmental pollution Location Altitude below 1000 m, indoors (no corrosive gas, liquid, no dust) Operation No condensation and no icing Environment Temperature -10°C–+50°C NOTE 1 Storage -20°C–+60°C Temperature Humidity...
Page 49 Chapter 4 Specification | EL-C 4-5 Operating ambient temperature and Carrier Derating Operating Environment Temperature Derating Curve Others Figure 4-1 Model Operating Environment Temperature Limits When operating at rated current, the ambient temperature should be between -10–40°C. The rated current needs to be reduced 2% for every VFD007EL21C 1°C increase when the ambient temperature exceeds 40°C, and the maximum ambient temperature can reach 50°C.
Page 50: Chapter 5 Canopen Overview
Chapter 5 CANopen OverviewEL-C Chapter 5 CANopen Overview 5-1 CANopen Overview 5-2 Wiring for CANopen 5-3 CANopen Communication Interface Descriptions 5-4 CANopen Supported Index 5-5 CANopen Fault Codes 5-6 CANopen LED Function...
Page 51 SOP (Special Object Protocol): Supports default COB-ID in Predefined Master/Slave  Connection Set in DS301 V4.02; Supports SYNC service; Supports Emergency service. NMT (Network Management): Supports NMT module control; Supports NMT Error control;  Supports Boot-up. Delta CANopen does not support this service: Time Stamp service ...
Page 52 Chapter 5 CANopen OverviewEL-C 5-1 CANopen Overview CANopen Protocol CANopen is a CAN-based higher layer protocol, and was designed for motion-oriented machine control networks such as handling systems. CANopen 301 (Version 4.02) is standardized as EN50325-4. The CANopen specifications cover the application layer and communication profile (CiA DS301), as well as a framework for programmable devices (CiA DS302), recommendations for cables and connectors (CiA DS303-1) and SI units and prefix representations (CiA DS303-2).
Page 53 Chapter 5 CANopen OverviewEL-C NMT (Network Management Object) The Network Management (NMT) follows a Master/Slave structure for executing NMT service. A network has only one NMT master, and the other nodes are slaves. All CANopen nodes have a present NMT state, and the NMT master can control the state of the slave nodes. The following shows the state diagram of a node: (1) After power is applied, start in the auto-initialization state A: NMT...
Page 54 Type number 252 indicates the data is updated (but not sent) immediately after receiving SYNC.  Type number 253 indicates the data is updated immediately after receiving RTR.  Type number 254: Delta CANopen does not support this transmission format.  Type number 255 indicates the data is an asynchronous transmission. ...
Page 55 Chapter 5 CANopen OverviewEL-C EMCY (Emergency Object) When errors occur inside the hardware, an emergency object is triggered. An emergency object is only sent when an error occurs. As long as there is nothing wrong with the hardware, there is no emergency object warning of an error message.
Page 56: Wiring For Canopen
Chapter 5 CANopen OverviewEL-C 5-2 Wiring for CANopen CANopen wiring of the EL-C drive does not require a Hub. The connector from the drive adopts the two-way RJ45 with one-in and one-out. You must wire the two farthest ends with 120 Ω terminating resistors as shown in the picture below.
Page 57 There are two control modes for CANopen: the DS402 standard (Pr.09-40=1) is the default, and the Delta’s standard setting (Pr.09-40=0). There are two control modes according to Delta’s standard. One is the old control mode (Pr.09-30=0); this control mode can only control the motor drive under the frequency control.
Page 58 Chapter 5 CANopen OverviewEL-C 5-3-2 DS402 Standard Control Mode 5-3-2-1 Related settings for an AC motor drive (following the DS402 standard) If you want to use the DS402 standard to control the motor drive, follow these steps: Wire the hardware (refer to Section 5-2 Wiring for CANopen). Set the operation source: set Pr.00-21 to 3 for CANopen communication card control.
Page 59 Chapter 5 CANopen OverviewEL-C When the motor drive turns on and finishes the initiation, it remains in Ready to Switch On status. To control the operation of the motor drive, change to Operation Enable status. To do this, set the control word's bit0–bit3 and bit7 of the Index 6040H and pair with Index Status Word (Status Word 0X6041).
Page 60 Chapter 5 CANopen OverviewEL-C Index Definition Default Size Unit Mode Note 0: Disable drive function 1: Slow down on slow down ramp 2: Slow down on quick stop ramp 5: Slow down on slow down ramp and stay in QUICK STOP 605Ah Quick stop option code 6: Slow down on quick stop ramp...
Page 61 Chapter 5 CANopen OverviewEL-C NOTE: Read 6043 to get the current rotation speed (unit: rpm) Read bit 10 of 6041 to check if the rotation speed has reached the targeting value (0: Not reached; 1: Reached). 5-12...
Page 62 5-3-3-1 Related settings for an AC motor drive (following the Delta old standard) If you want to use the Delta old standard to control the motor drive, follow these steps: Wire the hardware (refer to Section 5-2 Wiring for CANopen).
Page 63 5-3-4-1 Related settings for an AC motor drive (following the Delta new standard) If you want to use the Delta old standard to control the motor drive, follow these steps: Wire the hardware (refer to Section 5-2 Wiring for CANopen).
Page 64 Chapter 5 CANopen OverviewEL-C 5-3-5 Control DI/DO by CANopen To control the DO of the motor drive through CANopen, follow these steps: Define the DO to be controlled by CANopen. For example, set Pr.02-13–02-16 = 50 to control MO1–MO4. Control the Index mapped by CANopen. To control DO by setting Index 2026-41 = 1, to control MO1 into ON by setting bit 0 of Index 2026- 41 = 1, then MO1 outputs 1.
Page 65 For example: Pr.10-15 (Encoder Stall and Slip Error Action) Group member 10(0AH) 15(0FH) Index = 2000H + 0AH = 200A Sub-Index = 0FH + 1H = 10H EL-C Supported Control Index: Delta Standard Mode (Old Definition) Index Definition Defa R/W Size Note Number bit 1–0...
Page 66 Chapter 5 CANopen OverviewEL-C Index Definition Defa R/W Size Note Frequency command (XXX.XX Hz) RW U16 bit 0 1: E.F. (External Fault) ON bit 1 1: Reset command Other trigger RW U16 bit 2 1: Base Block (B.B) ON bit153 Reserve 2021H Number...
Page 67 Chapter 5 CANopen OverviewEL-C Index Definition Defa R/W Size Note Display the motor speed estimated by the drive or encoder feedback in Display the positive / negative output torque estimated by the drive (+0.0: positive torque; -0.0: negative torque) Reserve Display the PID feedback value after enabling the PID function in Display the AVI analog input...
Page 68 4 bit 5 bit 6 bit 7 bit 8 bit 9 bit 10 bit 11 bit 12 bit 13 bit 14 bit 15 2026-41 Delta Standard Mode (New Definition) Descriptions Index Size Speed Mode Definition Priority 0: fcmd = 0...
Page 69 Chapter 5 CANopen OverviewEL-C Descriptions Index Size Speed Mode Definition Priority QStop Quick stop Power On Switch ON 15–8 Actual output frequency (XXX.XX Hz) Actual position (absolute) Actual torque DS402 Standard Index Sub Definition Default R/W Size Unit Mode Note 0: No action Abort connection 6007h...
Page 70: Canopen Fault Codes
Chapter 5 CANopen OverviewEL-C 5-5 CANopen fault code Refer to settings for Pr.06-17–Pr.06–22 and Pr.12-70–Pr.12-73  Refer to Chapter 08 Fault Codes for detailed descriptions.  DS302 / 402 CANopen fault Display Fault code Fault Descriptions CANopen Fault register (bit 0–7) Codes Over-current during acceleration 0001H...
Page 71 Chapter 5 CANopen OverviewEL-C DS302 / 402 CANopen fault Display Fault code Fault Descriptions CANopen Fault register (bit 0–7) Codes 0033H External base block (bb) 9000H 0034H Password is locked (Pcod) FF26H 0036H Illegal command (CE1) 7500H 0037H Illegal data address (CE2) 7500H 0038H Illegal data value (CE3)
Page 72: Canopen Led Function
Chapter 5 CANopen OverviewEL-C 5-6 CANopen LED Function There are two CANopen flash signs: CRUN and CERR. VFD-EL-C CRUN CERR MODE selection 模式选择键 RUN key 运行键 STOP/RESET key 停止/复位键  Status Display Display the drive’s current status: RUN, STOP, FWD, REV, CAN RUN, CAN ERROR ...
Page 73 Chapter 5 CANopen OverviewEL-C [This page intentionally left blank] 5-24...
Page 74: Chapter 6 Descriptions Of Parameter Settings
Chapter 6 Descriptions of Parameter Settings Chapter 6 Descriptions of Parameter Settings 6-1 Summary of Parameter Settings 6-2 Descriptions of Parameter Settings 6-1-1...
Page 75: Drive Parameters
Chapter 6 Descriptions of Parameter Settings 6-1 Summary of Parameter Settings This chapter provides a summary of parameters (Pr.) setting ranges and defaults You can set, change, and reset parameters through the digital keypad. NOTE: 1. : You can set this parameter during operation. Refer to chapter 06 for the details of parameters. 2.
Page 76 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default 3: Display the drive’s DC bus voltage (v) (Unit: V 4: Display the drive’s U, V, W output voltage (E) (Unit: V 5: Display the drive’s output power angle (n) (Unit: deg) 6: Display the drive’s output power (P) (Unit: kW) 7: Display the motor speed (r) (Unit: rpm)
Page 77 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default 0 (Digital keypad) Operation Command Source 1: External terminals 00-21  (AUTO, REMOTE) 2: RS-485 communication input 3: CANopen communication 0: Ramp to stop 00-22 Stop Method  1: Coast to stop 0: Enable forward / reverse 00-23 Motor Direction Control...
Page 78 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default 00-49 Display Filter Time (Keypad) 0.001–65.535 sec. 0.100  00-50 Software Version (Date) Read only Read only 6-1-5...
Page 79: Basic Parameters
Chapter 6 Descriptions of Parameter Settings 01 Basic Parameters Parameter Name Settings Default Motor 1 Maximum Operation 60.00 / 01-00 0.00–400.00 Hz Frequency 50.00 Minimum Output Frequency 60.00 / 01-01 0.00–400.00 Hz of Motor 1 50.00 Minimum Output Voltage of 230V models: 0.0–255.0 V 220.0 01-02...
Page 80 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default Pr.01-45 = 0: 0.00–600.00 sec. 10.00 01-20 Jog Acceleration Time  Pr.01-45 = 1: 0.0–6000.0 sec. 10.0 Pr.01-45 = 0: 0.00–600.00 sec. 10.00 01-21 Jog Deceleration Time  Pr.01-45 = 1: 0.0–6000.0 sec. 10.0 01-22 Jog Frequency...
Page 81 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default Time Unit for Acceleration 0: Unit 0.01 sec. 01-45 and Deceleration and S-Curve 1: Unit 0.1 sec. Pr.01-45 = 0: 0.00–6000.0 sec. 01-46 Canopen Quick Stop Time 1.00 Pr.01-45 = 1: 0.0–6000.0 sec. 6-1-8...
Page 82: Digital Input / Output Parameters
Chapter 6 Descriptions of Parameter Settings 02 Digital input / Output Parameters Parameter Name Settings Default 0: No Function 1: Two-wire mode 1, power on for operation control (M1: FWD / STOP, M2: REV / STOP) Two-Wire / Three-Wire 02-00 2: Two-wire mode 2, power on for operation control Operation Control (M1: RUN / STOP, M2: REV / FWD)
Page 83 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default 0: UP / DOWN by the accel. / decel. time 1: UP / DOWN constant speed (Pr.02-10) 02-09 Up / Down Key Mode  2: Pulse signal (Pr.02-10) 3: External terminals UP / DOWN key mode Acceleration / Deceleration 02-10 Speed of External Terminal...
Page 84 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default 35: Error output selection 1 (Pr.06-23) 36: Error output selection 2 (Pr.06-24) 37: Error output selection 3 (Pr.06-25) 38: Error output selection 4 (Pr.06-26) 40: Speed reached (including STOP) 43: Actual motor speed detection 44: Low current output (use with Pr.06-71–Pr.06-73) 46: Master dEb output...
Page 85 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default MI Terminal NPN / PNP Mode 0: NPN (SINK) mode 02-55 Selection 1: PNP (SOURCE) Mode 0: Terminal count value reached, no EF displays EF Activates When the 02-81 (continues to operate) ...
Page 86 Chapter 6 Descriptions of Parameter Settings 03 Reserved 6-1-13...
Page 87: Multi-Stage Speed Parameters
Chapter 6 Descriptions of Parameter Settings 04 Multi-Step Speed Parameters Parameter Name Settings Default 04-00 Step Speed Frequency 0.00–400.00 Hz 0.00  04-01 Step Speed Frequency 0.00–400.00 Hz 0.00  04-02 Step Speed Frequency 0.00–400.00 Hz 0.00  04-03 Step Speed Frequency 0.00–400.00 Hz 0.00 ...
Page 88: Motor Parameters
Chapter 6 Descriptions of Parameter Settings 05 Motor Parameters Parameter Name Settings Default Depending Full-Load Current for induction on the 05-01 10–120% of the drive’s rated current model Motor 1 (A) power Depending Rated Power for induction on the 05-02 0.00–655.35 kW ...
Page 89: Protection Parameters (1)
Chapter 6 Descriptions of Parameter Settings 06 Protection Parameters (1) Parameter Name Settings Default 115V / 230V models: 150.0–220.0 V 180.0 06-00 Low Voltage Level  460V models: 300.0–440.0 V 360.0 0: No Function 06-01 Over-Voltage Stall Prevention 230V models: 0.0–450.0 V 380.0 ...
Page 90 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default 06-19 Fault Record 3 2: Over-current during deceleration (ocd) 06-20 Fault Record 4 3: Over-current during steady operation (ocn) 06-21 Fault Record 5 6: Over-current at stop (ocS) 06-22 Fault Record 6 7: Over-voltage during acceleration (ovA) Fault Record 7 (Pr.14-70) 8: Over-voltage during deceleration (ovd)
Page 91 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default 87: Low frequency overload protection (oL3) 101: CANopen guarding error (CGdE) 102: CANopen heartbeat error (CHbE) 104: CANopen bus off error (CbFE) 105: CANopen index error (CidE) 106: CANopen station address error (CAdE) 107: CANopen index setting exceed limit (CFrE) 111: inrCOM time-out error (ictE) 121: internal communication error (CP20)
Page 92 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default Current Detection Level for 06-47 0.00–100.00 % 1.00  Output Phase Loss DC Brake Time for Output 06-48 0.000–65.535 sec. 0.000  Phase Loss 0: Disabled 06-49 Lvx Auto-Reset  1: Enabled input Phase Loss Detection 0: Warn and ramp to stop...
Page 93: Special Parameters
Chapter 6 Descriptions of Parameter Settings 07 Special Parameters Parameter Name Settings Default 07-01 Dc Brake Current Level 0–100  07-02 DC Brake Time at Start-Up 0.0–60.0 sec.  07-03 DC Brake Time at STOP 0.0–60.0 sec.  07-04 DC Brake Frequency at STOP 0.00–400.00 Hz 0.00 ...
Page 94 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default 0: Fan is always ON 1: Fan is OFF after the AC motor drive stops for one minute. 2: Fan is ON when the AC motor drive runs; fan is Fan Cooling Control OFF when the AC motor drive stops 07-19...
Page 95 Chapter 6 Descriptions of Parameter Settings 08 Reserved 6-1-22...
Page 96: Communication Parameters
Chapter 6 Descriptions of Parameter Settings 09 Communication Parameters Parameter Name Settings Default 09-00 Communication Address 1–254  09-01 Com1 Transmission Speed 4.8–19.2 Kbps  0: Warn and continue operation COM1 Transmission Fault 1: Warn and ramp to stop 09-02 ...
Page 97 0: 1 Mbps 1: 500 Kbps 2: 250 Kbps 09-37 Canopen Speed 3: 125 Kbps 4: 100 Mbps (Delta Only) 5: 50 Kbps bit 0: CANopen software disconnection 1 (CANopen Guarding Time-out) bit 1: CANopen software disconnection 2 (CANopen Heartbeat Time-out)
Page 98: Speed Feedback Control Parameters
Chapter 6 Descriptions of Parameter Settings 10 Speed Feedback Control Parameters Parameter Name Settings Default Upper Limit of Frequency 10-29 0.00–200.00 Hz 20.00  Deviation 6-1-25...
Page 99 Chapter 6 Descriptions of Parameter Settings 11 Reserved 6.1-26...
Page 100: System Control And Canopen Function Parameters
Chapter 6 Descriptions of Parameter Settings 12 System control and CANopen function parameters Parameter Name Settings Default bit 3: Dead time compensation closed 12-00 System Control bit 7: Save or do not save the frequency 0: Two-phase modulation mode 12-01 Pwm Mode Selection 2: Space vector modulation mode 12-02...
Page 101 Chapter 6 Descriptions of Parameter Settings Parameter Name Settings Default Output Current at 12-56 0.00–655.35 Amps Read only Malfunction 3 IGBT Temperature at 12-57 -3276.7–3276.7 ºC Read only Malfunction 3 Output Frequency at 12-58 0.00–400.00 Hz Read only Malfunction 4 DC Bus Voltage at 12-59 0.0–6553.5 V...
Page 102: Control Mode Parameter Macro Function
Chapter 6 Descriptions of Parameter Settings 13 Control Mode Parameter Macro Function Parameter Name Settings Default 0: No Function 1: by user 13-00 Macro Selection 2: I/O mode control 3: CANopen remote control and monitoring mode 4: I/O control and CANopen remote monitoring mode 6.1-29...
Page 103 Chapter 6 Descriptions of Parameter Settings [This page is intentionally left blank] 6.1-30...
Page 104 Chapter 6 Descriptions of Parameter SettingsEL-C 6-2 Descriptions of Parameter Settings 00 Drive Parameters  You can set this parameter during operation. 00-00 AC Motor Drive Identity Code Default: Read only Settings Read only 00-01 AC Motor Drive Rated Current Display Default: Read only Settings Read only...
Page 105 Chapter 6 Descriptions of Parameter SettingsEL-C  7: Reset the related settings of CANopen slave. Generally, it needs to be reset after setting Pr.12- 07, 09-40, 09-30, etc., otherwise the CANopen network cannot be connected normally.  8: RUN key on the keypad is invalid; the rest of the keys work normally. Set Pr.00-02 to 0 to unlock the setting.
Page 106 Chapter 6 Descriptions of Parameter SettingsEL-C Explanation 1 If MI1 and MI4 are ON, the following table shows the status of the terminals. Normally opened contact (N.O.): (0: OFF, 1: ON) Terminal MI 2 MI 1 Status The value is 0000 0000 0000 0001 in binary. and 0011H in HEX. When Pr.00-04 is set to 16 or ...
Page 107 Chapter 6 Descriptions of Parameter SettingsEL-C 00-05 Coefficient Gain in Actual Output Frequency  Default:1.00 Settings 0.00–160.00  Sets the user-defined unit coefficient gain. Set Pr.00-04 = 31 to display the calculation result on the screen (calculation = output frequency * Pr.00-05). 00-06 Firmware Version Default: #.#...
Page 108 Chapter 6 Descriptions of Parameter SettingsEL-C 00-10 Control Mode Default: 0 Settings 0: Speed mode  Determines the control mode of the AC motor drive: 00-11 Speed control mode selection Default: 0 Settings 0: VF (IM V/F control)  Determines the control mode of the AC motor drive: 0: IM V/F control: you can set the proportion of V/F as required and control multiple motors simultaneously.
Page 109 Chapter 6 Descriptions of Parameter SettingsEL-C 00-16 Load selection Default:1 Settings 1: Heavy load  Heavy duty: overload rated output current 200% in 3 seconds. (150%,1 minute) Refer to Pr.00-17 for the setting for the carrier frequency. Refer to Chapter 9 Specifications or Pr.00-01 for the rated current.
Page 110 Chapter 6 Descriptions of Parameter SettingsEL-C  The default for the frequency source or operation source is for AUTO mode. It returns to AUTO or REMOTE mode whenever you cycle the power. If you use a multi-function input terminal to switch between HAND (LOCAL) and AUTO (REMOTE) mode, the highest priority is the multi-function input terminal.
Page 111 Chapter 6 Descriptions of Parameter SettingsEL-C 00-23 Motor direction control  Default: 0 Settings 0: Enable forward / reverse 1: Disable reverse 2: Disable forward  Enables the motor to run in the forward and reverse direction. You can use it to prevent a motor from running in a direction that would cause injury or damage to the equipment, especially when only one running direction is allowed for the motor load.
Page 112 Chapter 6 Descriptions of Parameter SettingsEL-C  It returns to AUTO or REMOTE mode whenever you cycle the power. If you use a multi-function input terminal to switch between HAND (LOCAL) and AUTO (REMOTE) mode, the highest priority is the multi-function input terminal. 00-31 Operation command source (HAND, LOCAL) Default: 3...
Page 113 Chapter 6 Descriptions of Parameter SettingsEL-C 00-50 Software Version (Date) Default: Read only Settings Read only  Displays the current drive software version by date. 6-2-0010...
Page 114 Chapter 6 Descriptions of Parameter SettingsEL-C Basic Parameters  You can set this parameter during operation. 01-00 Motor 1 Maximum Operation Frequency Default: 60.00 / 50.00 Settings 0.00–400.00 Hz  Determines the AC motor drive’s maximum operation frequency. 01-01 Minimum output frequency of motor 1 Default: 60.00 / 50.00 Settings 0.00–400.00 Hz...
Page 115 Chapter 6 Descriptions of Parameter SettingsEL-C  You usually set the V/F curve according to the motor’s allowable loading characteristics. Pay special attention to the motor’s heat dissipation, dynamic balance, and bearing lubrication when the loading characteristics exceed the loading limit of the motor. There is no limit for the voltage setting, but a high voltage at a low frequency may cause motor damage, overheating, and trigger the stall prevention or the over-current protection.
Page 116 Chapter 6 Descriptions of Parameter SettingsEL-C (3) High starting torque 01-09 Start-up Frequency Default: 0.50 Settings 0.00–400.00 Hz  When the starting frequency (Pr.01-09) is larger than the Minimum Output Frequency of Motor 1 (Pr.01-07), the drive’s frequency output starts from the starting frequency (Pr.01-09) until reaching the F command.
Page 117 Chapter 6 Descriptions of Parameter SettingsEL-C  When Fcmd > Fmin and Fcmd < Fstart: If Flow < Fcmd, the drive runs directly with Fcmd. If Flow ≥ Fcmd, the drive runs with Fcmd, and then rises to Flow according to acceleration time. ...
Page 118 Chapter 6 Descriptions of Parameter SettingsEL-C  If the output frequency lower limit setting is 10 Hz and the minimum output frequency setting (Pr.01-07) is 1.5 Hz, then the drive operates at 10 Hz when the Frequency command is higher than Pr.01-07 but lower than 10 Hz.
Page 119 Chapter 6 Descriptions of Parameter SettingsEL-C 01-22 JOG Frequency  Default: 6.00 Settings 0.00–400.00 Hz  You can use both the external terminal JOG and F1 key on the optional keypad KPC-CC01 (optional) to set the JOG function. When the JOG command is ON, the AC motor drive accelerates from 0 Hz to the JOG frequency (Pr.01-22).
Page 120 Chapter 6 Descriptions of Parameter SettingsEL-C 01-24 S-curve acceleration begin time 1  01-25 S-curve acceleration arrival time 2  01-26 S-curve deceleration begin time 1  01-27 S-curve deceleration arrival time 2  Default: 0.20 Settings Pr.01-45 = 0: 0.00–25.00 sec. Pr.01-45 = 1: 0.0–250.0 sec.
Page 121 Chapter 6 Descriptions of Parameter SettingsEL-C  You can set the Frequency command (F) within the range of skip frequencies. Then the output frequency (H) is limited to the lower limit of skip frequency ranges.  During acceleration and deceleration, the output frequency still passes through the skip frequency ranges.
Page 122 Chapter 6 Descriptions of Parameter SettingsEL-C  When you set the V/F curve to high power, it has lower torque at low frequency, and the drive is not suitable for rapid acceleration and deceleration. Do NOT use this parameter for rapid acceleration and deceleration.
Page 123 Chapter 6 Descriptions of Parameter SettingsEL-C 01-45 Time Unit for Acceleration and Deceleration and S-Curve Default: 0 Settings 0: Unit 0.01 sec. 1: Unit 0.1 sec. 01-46 CANopen Quick Stop Time Default: 1.00 Settings Pr.01-45 = 0: 0.00–600.00 sec. Pr.01-45 = 1: 0.0–6000.0 sec. ...
Page 124 Chapter 6 Descriptions of Parameter SettingsEL-C 02 Digital Input / Output Parameters  You can set this parameter during operation. 02-00 Two-wire / Three-wire Operation Control Default: 1 Settings 0: No function 1: Two-wire mode 1, power on for operation control (M1: FWD / STOP, M2: REV / STOP) 2: Two-wire mode 2, power on for operation control (M1: RUN / STOP, M2: REV / FWD)
Page 125 Chapter 6 Descriptions of Parameter SettingsEL-C 02-01 Multi-function Input Command 1 (MI1) 02-02 Multi-function Input Command 2 (MI2) 02-03 Multi-function Input Command 3 (MI3) 02-04 Multi-function Input Command 4 (MI4) 02-05 Multi-function Input Command 5 (MI5) 02-06 Multi-function Input Command 6 (MI6) Default: 0 Settings 0: No function...
Page 126 Chapter 6 Descriptions of Parameter SettingsEL-C  If Pr.02-00 is set to three-wire operation control, terminal MI3 is for the STOP contact. The function set previously for this terminal is automatically invalid. Summary of function settings (Take the normally open contact (N.O.) for example, ON: contact is closed, OFF: contact is open) Settings Functions...
Page 127 Chapter 6 Descriptions of Parameter SettingsEL-C Settings Functions Descriptions You can select the acceleration and deceleration time of the drive with this function, or from the digital status of the terminals; and 2 acceleration / there are four acceleration and deceleration selections. deceleration time selection Accel.
Page 128 Chapter 6 Descriptions of Parameter SettingsEL-C Settings Functions Descriptions ON: the counter value increases by one. Use the function with Input the counter value (MI6) Pr.02-19. This function is valid when the source of the operation command is the external terminal. ON: the drive executes forward JOG.
Page 129 Chapter 6 Descriptions of Parameter SettingsEL-C Settings Functions Descriptions When the drive is enabled, the RUN command is valid. When the drive is disabled, the RUN command is invalid. When the Enable drive drive is operating, the motor coasts to stop. This function varies with MO = 45.
Page 130 Chapter 6 Descriptions of Parameter SettingsEL-C  When Pr.02-09 is set to 1: The increasing or decreasing Frequency command (F) operates according to the setting of Pr.02-10 (0.01–1.000 Hz/ms). 02-11 Multi-function Input Response Time  Default: 0.005 Settings 0.000–30.000 sec. ...
Page 131 Chapter 6 Descriptions of Parameter SettingsEL-C 02-13 Multi-function Output 1 (MO1)  02-14 Multi-function Output 2 (MO2)  02-15 Multi-function Output 3 (MO3)  02-16 Multi-function Output 4 (MO4)  Default: 50 Settings 0: No function 1: Indication during RUN 2: Operation speed reached 3: Desired frequency reached 1 (Pr.02-22) 4: Desired frequency reached 2 (Pr.02-24)
Page 132 Chapter 6 Descriptions of Parameter SettingsEL-C 75: Forward RUN status 76: Reverse RUN status  Use this parameter to set the function of multi-function terminals. Summary of Function Settings (Take the normally open contact (N.O.) for example, closed: contacts are conducted) Setting Functions Descriptions...
Page 133 Chapter 6 Descriptions of Parameter SettingsEL-C Setting Functions Descriptions Over-current stall Activates when the over-current stall prevention is detected. prevention Over-voltage stall Activates when over-voltage stall prevention is detected. prevention Activates when the source of operation command is not controlled Operation source by the digital keypad (Pr.00-21 ≠...
Page 134 4 digits, it’s only for the value less than 999. It is recommended to use a communication method to check the count value when actual use. The mapping site is as follows. Modbus communication check 2109H Canopen (Delta Old Definition) Index 2022H-SUB02 6-2-0211...
Page 135 Chapter 6 Descriptions of Parameter SettingsEL-C  The counting function is enabled when Pr.02-19 ≠ 0.  The counting function is enabled when the setting of Pr.02-19 is greater than Pr.02-20.  When the counter reaches Pr.02-19 or 02-20, the MO is activates according to the parameter settings.
Page 136 Chapter 6 Descriptions of Parameter SettingsEL-C 02-34 Output Frequency Setting for Multi-function Output Terminal  Default: 0.00 Settings 0.00–400.00 Hz 02-35 External Operation Control Selection after Reset and Reboot  Default: 0 Settings 0: Disabled 1: Drive runs if the RUN command remains after reset or reboot. ...
Page 137 Chapter 6 Descriptions of Parameter SettingsEL-C 02-50 Display the Status of Multi-function Input Terminal Default: Read only Settings Monitor the status of the Multi-function Input Terminal 0=OFF 1=ON Note  Example: When Pr.02-50 displays 0014h (hex) (that is, the value is 20 (decimal) and 10100 (binary)), it means that MI3 and MI5 are ON.
Page 138 Chapter 6 Descriptions of Parameter SettingsEL-C 02-54 Display the Frequency Command Executed by External Terminal Default: Read only Settings Read only  When you set the source of the Frequency command as the external terminal, if Lv or Fault occurs, the external terminal Frequency command is saved in this parameter.
Page 139 Chapter 6 Descriptions of Parameter SettingsEL-C [This page intentionally left blank] 6-2-0216...
Page 140 Chapter 6 Descriptions of Parameter SettingsEL-C 04 Multi-Step Speed Parameters  You can set this parameter during operation. 04-00 1st Step Speed  04-01 2nd Step Speed  04-02 3rd Step Speed  04-03 4th Step Speed  04-04 5th Step Speed ...
Page 141 Chapter 6 Descriptions of Parameter SettingsEL-C 6-2-042...
Page 142 Chapter 6 Descriptions of Parameter SettingsEL-C 05 Motor Parameters  You can set this parameter during operation. 05-01 Full-load Current for Induction Motor 1 (A) Default: Depending on the model power Settings 10–120% of the drive’s rated current  Set this value according to the rated current of the motor as indicated on the motor nameplate. The default is 90% of the drive’s rated current.
Page 143 Chapter 6 Descriptions of Parameter SettingsEL-C the drive is activated and the record is saved when the drive stops or turns OFF. The amount of consumed watts continues to accumulate when the drive is activated again. To clear the accumulation, set Pr.00-02 to 5 to return the accumulation record to 0. ...
Page 144 Chapter 6 Descriptions of Parameter SettingsEL-C 06 Protection Parameters (1)  You can set this parameter during operation. 06-00 Low voltage level  Default: 180.0 / 360.0 Settings 230V models: 150.0–220.0 V 460V models: 300.0–440.0 V  Sets the Low Voltage (LV) level. When the DC bus voltage is lower than Pr.06-00, a LV fault is triggered, and the drive stops output then the motor coasts to a stop.
Page 145 Chapter 6 Descriptions of Parameter SettingsEL-C 06-02 Selection for Over-voltage Stall Prevention  Default: 0 Settings 0: Traditional over-voltage stall prevention 1: Smart over-voltage stall prevention  Use this function when you are unsure about the load inertia. When stopping under normal load, the over-voltage does not occur during deceleration and meet the deceleration time setting.
Page 146 Chapter 6 Descriptions of Parameter SettingsEL-C  When you enable the over-voltage stall prevention, the drive’s deceleration time is longer than the setting.  If the deceleration time affects your application, it is not recommended to use this function. The solution is to increase the deceleration time appropriately.
Page 147 Chapter 6 Descriptions of Parameter SettingsEL-C 06-04 Over-current Stall Prevention during Operation  Default: 180 Settings 0–200% (100% corresponds to the rated current of the drive)  This is a protection for the drive to decrease output frequency automatically when the motor overloads abruptly during constant motor operation.
Page 148 Chapter 6 Descriptions of Parameter SettingsEL-C 06-08 Over-torque Detection Time (Motor 1)  Default: 0.1 Settings 0.1–60.0 sec. 06-13 Electronic Thermal Relay Selection 1 (Motor 1)  Default: 2 Settings 0: Inverter motor (with external forced cooling) 1: Standard motor (motor with fan on the shaft) 2: Disabled ...
Page 149 Chapter 6 Descriptions of Parameter SettingsEL-C Pr.06-13 or Pr.06-27 is set to 1 (using standard motor): When the output current of the drive is higher than 150% of the motor rated current (refer to the motor rated current % corresponded to the motor rated frequency in the motor cooling curve with shaft-fixed fan), the drive starts to count the time.
Page 150 Chapter 6 Descriptions of Parameter SettingsEL-C 06-17 Fault Record 1 06-18 Fault Record 2 06-19 Fault Record 3 06-20 Fault Record 4 06-21 Fault Record 5 06-22 Fault Record 6 Default: 0 Settings 0: No fault record 1: Over-current during acceleration (ocA) 2: Over-current during deceleration (ocd) 3: Over-current during steady operation (ocn) 6: Over-current at stop (ocS)
Page 151 Chapter 6 Descriptions of Parameter SettingsEL-C 62: Deceleration energy backup error (dEb) 79: U-phase over-current before run (Aoc) 80: V-phase over-current before run (boc) 81: W-phase over-current before run (coc) 82: U-phase output phase loss (oPHL) 83: V-phase output phase loss (oPHL) 84: W-phase output phase loss (oPHL) 87: Low frequency overload protection (oL3) 101: CANopen guarding error (CGdE)
Page 152 Chapter 6 Descriptions of Parameter SettingsEL-C bit0 bit1 bit2 bit3 bit4 bit5 bit6 Fault Code current Volt. ● 6: Over-current at stop (ocS) ● 7: Over-voltage during acceleration (ovA) ● 8: Over-voltage during deceleration (ovd) ● 9: Over-voltage during constant speed (ovn) ●...
Page 153 Chapter 6 Descriptions of Parameter SettingsEL-C bit0 bit1 bit2 bit3 bit4 bit5 bit6 Fault Code current Volt. ● 87: Low frequency overload protection (oL3) ● 101: CANopen guarding error (CGdE) ● 102: CANopen heartbeat error (CHbE) ● 104: CANopen bus off error (CbFE) ●...
Page 154 Chapter 6 Descriptions of Parameter SettingsEL-C  When an error occurs, you can check the output current for the malfunction. If the error happens again, this parameter overwrites the previous record. 06-36 IGBT Temperature at Malfunction Default: Read only Settings -3276.7–3276.7 ºC ...
Page 155 Chapter 6 Descriptions of Parameter SettingsEL-C 06-46 Detection Time for Output Phase Loss  Default: 0.500 Settings 0.000–65.535 sec. 06-47 Current Detection Level for Output Phase Loss  Default: 1.00 Settings 0.00–100.00 % 06-48 DC Brake Time for Output Phase Loss ...
Page 156 Chapter 6 Descriptions of Parameter SettingsEL-C  Status 3: The drive is in STOP; Pr.06-48 ≠ 0; Pr.07-02 ≠ 0 When the drive starts, it executes Pr.06-48 first, and then executes Pr.07-02 (DC brake). The DC brake current level in this state includes two parts: one is 20 times the Pr.06-47 setting value in Pr.06-48 setting time;...
Page 157 Chapter 6 Descriptions of Parameter SettingsEL-C  Status 4: The drive is in STOP; Pr.06-48 ≠ 0; Pr.07-02=0 When the drive starts, it executes Pr.06-48 as the DC brake. The DC brake current level is 20 times the Pr.06-47 setting value. Status 4-1: Pr.06-48 ≠...
Page 158 Chapter 6 Descriptions of Parameter SettingsEL-C 06-53 Input Phase Loss Detection Action (OrP)  Default: 0 Settings 0: Warn and ramp to stop 1: Warn and coast to stop  The drive executes the input phase loss protection according to Pr.06-53. 06-63 Operation Time of Fault Record 1 (Day) 06-65...
Page 159 Chapter 6 Descriptions of Parameter SettingsEL-C fault fault fault fault fault fault Pr.06-66 Pr.06-67 1000 1120 Pr.06-68 Pr.06-69 1000 Pr.06-70 ※ By examining the time record, you can see that the last fault (Pr.06-17) happened after the drive ran for four days and 240 minutes. 06-71 Low Current Setting Level ...
Page 160 Chapter 6 Descriptions of Parameter SettingsEL-C 07 Special Parameters  You can set this parameter during operation. 07-01 DC Brake Current Level  Default: 0 Settings 0–100%  Sets the level of the DC brake current output to the motor at start-up and stop. When setting the DC brake current, the rated current is 100%.
Page 161 Chapter 6 Descriptions of Parameter SettingsEL-C  Use the DC brake before running the motor when the load is movable at stop, such as with fans and pumps. The motor is in free running status and in unknown rotation direction before the drive starts up.
Page 162 Chapter 6 Descriptions of Parameter SettingsEL-C 07-07 Allowed Power Loss Duration  Default: 2.0 Settings 0.0–20.0 sec.  Determines the maximum time of allowable power loss. If the duration of a power loss exceeds this parameter setting, the AC motor drive stops output after the power recovers. ...
Page 163 Chapter 6 Descriptions of Parameter SettingsEL-C 07-09 Current Limit of Speed Tracking  Default: 100 Settings 20–200%  The AC motor drive executes speed tracking only when the output current is greater than the value set in Pr.07-09.  The maximum current for speed tracking affects the synchronous time. The larger the parameter setting, the faster the synchronization occurs.
Page 164 Chapter 6 Descriptions of Parameter SettingsEL-C 07-10 Restart after Fault Action  Default: 0 Settings 0: Stop operation 1: Speed tracking by current speed 2: Speed tracking by the minimum output frequency  Faults include: bb, oc, ov, occ. To restart after oc, ov, occ, you can NOT set Pr.07-11 to 0. 07-11 Number of Times of Restart after Fault ...
Page 165 Chapter 6 Descriptions of Parameter SettingsEL-C  The B.B. function does not work when executing dEb. The B.B. function is enabled after the dEb function finishes.  Even though the Lv warning does not display during dEb operation, if the DC bus voltage is lower than the Lv level, MO = 10 (Low voltage warning) still operates.
Page 166 Chapter 6 Descriptions of Parameter SettingsEL-C Situation 3: Unexpected power shut down or power loss  Pr.07-13=1 “dEb active, DC bus voltage returns, the output frequency does not return” and the power does not recover. The keypad displays the “dEb” warning and the drive stops after decelerating to the lowest operating frequency.
Page 167 Chapter 6 Descriptions of Parameter SettingsEL-C Situation 4: Pr.07-13=2 “dEb active, DC bus voltage returns, the output frequency returns”  and power does not recover. Same as Situation 3. The drive decelerates to 0 Hz. The DC bus voltage continues to decrease until the voltage is lower than the Lv level, and then the drive disconnects the soft start relay.
Page 168 Chapter 6 Descriptions of Parameter SettingsEL-C  When the load is heavier, use Pr.07-15–Pr.07-18 to avoid OV or OC protection. 07-19 Fan Cooling Control (Only valid for models with fans)  Default: 3 Settings 0: Fan is always ON 1: Fan is OFF after the AC motor drive stops for one minute. 2 (Fan is ON when the AC motor drive runs;...
Page 169 Chapter 6 Descriptions of Parameter SettingsEL-C 07-21 Automatic Energy-saving Setting  Default: 0 Settings 0: Disabled 1: Enable  When energy-saving is enabled, the motor acceleration/deceleration operates with full voltage. During constant speed operation, it automatically calculates the best voltage value according to the load power.
Page 170 Chapter 6 Descriptions of Parameter SettingsEL-C  2: The drive disables the AVR function only during deceleration to stop, and at this time, you can accelerate the braking to achieve the same result.  When the motor ramps to stop, disable the AVR function to shorten the deceleration time. Then, use with the auto-acceleration and auto-deceleration functions to make the motor’s deceleration more stable and quicker.
Page 171 Chapter 6 Descriptions of Parameter SettingsEL-C 07-32 Motor Oscillation Compensation Factor  Default: 1000 Settings 0–10000  The drift current occurs in a specific zone of the motor and it causes serious motor vibration. Adjust this parameter could greatly improve this situation. (When running with high frequency or PG, set this parameter to 0.
Page 172 Chapter 6 Descriptions of Parameter SettingsEL-C 09 Communication Parameters  You can set this parameter during operation. There are two RJ45 interfaces on the control board of the EL-C series, the definitions are as follows: Figure Left RJ45 Rigjt RJ45 CAN_H CAN_H CAN_L...
Page 173 Chapter 6 Descriptions of Parameter SettingsEL-C 09-03 COM1 Time-out Detection  Default: 0.0 Settings 0.0–100.0 sec.  Sets the communication time-out value. 09-04 COM1 Communication Protocol  Default: 1 Settings 1: 7, N, 2 (ASCII) 2: 7, E, 1 (ASCII) 3: 7, O, 1 (ASCII) 4: 7, E, 2 (ASCII) 5: 7, O, 2 (ASCII)
Page 174 Chapter 6 Descriptions of Parameter SettingsEL-C Data Format 10-bit character frame (For ASCII): (7, N, 2) Start Stop Stop 7-data bits 10-bits character frame (7, E, 1) Start Even Stop parity 7-data bits 10-bits character frame (7, O, 1) Start Stop parity 7-data bits...
Page 175 Chapter 6 Descriptions of Parameter SettingsEL-C Communication Protocol Communication Data Frame ASCII mode: Start character = ‘ : ’ (3AH) Address High Communication address: one 8-bit address consists of 2 ASCII codes Address Low Function High Command code: one 8-bit command consists of 2 ASCII codes Function Low DATA (n-1) Contents of data:...
Page 176 Chapter 6 Descriptions of Parameter SettingsEL-C ASCII mode: Command Message Response Message ‘:’ ‘:’ ‘0’ ‘0’ Address Address ‘1’ ‘1’ ‘0’ ‘0’ Function Function ‘3’ ‘3’ ‘2’ ‘0’ Number of register ‘1’ (count by byte) ‘4’ Starting register ‘0’ ‘1’ ‘2’...
Page 177 Chapter 6 Descriptions of Parameter SettingsEL-C ASCII mode: Command Message Response Message ‘:’ ‘:’ ‘0’ ‘0’ Address Address ‘1’ ‘1’ ‘0’ ‘0’ Function Function ‘6’ ‘6’ ‘0’ ‘0’ ‘1’ ‘1’ Target register Target register ‘0’ ‘0’ ‘0’ ‘0’ ‘1’ ‘1’ ‘7’...
Page 178 Chapter 6 Descriptions of Parameter SettingsEL-C Command Message Response Message CMD 0 ‘0’ CMD 0 ‘0’ ‘0’ ‘0’ Target register Target register ‘5’ ‘5’ ‘0’ ‘0’ Target register Target register ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ Number of register Number of register (count by word) (count by word) ‘0’...
Page 179 Chapter 6 Descriptions of Parameter SettingsEL-C ASCII mode (LRC Check): LRC (Longitudinal Redundancy Check) is calculated by summing up the values of the bytes from Address to the end of Data Content Take the above 3.3.1 Command Message for example: 01H + 03H + 21H + 02H + 00H + 02H = 29H, take complementary number of 2 = RTU mode (CRC Check): CRC (Cyclical Redundancy Check) starts from Address to the end at Data Content.
Page 180 Chapter 6 Descriptions of Parameter SettingsEL-C Address list AC motor drive parameters Modbus Function address GG is the parameter group, nn is the parameter number. For example, the address GGnnH of Pr.04-10 is 040AH. Control command (20xx) Modbus Attribute Function Description address 00B: No function 01B: Stop...
Page 181 Chapter 6 Descriptions of Parameter SettingsEL-C Modbus Attribute Function Description address 01B: Operation command by the digital keypad 10B: Operation command by Pr.00-21 setting 11B: Switch the operation command source bit15 Reserved 2001H Frequency command (XXX.XX Hz) bit0 1: E.F. (External Fault) ON bit1 1: Reset command 2002H...
Page 182 Chapter 6 Descriptions of Parameter SettingsEL-C Modbus Attribute Function Description address 2106H Output voltage (XXX.X V) 2107H Current step for the multi-step speed operation 2108H Reserved 2109H Counter value 210AH Output power factor angle (XXX.X) 210BH Output torque (XXX.X %) 210CH Actual motor speed (XXXXX rpm) 210FH...
Page 183 Chapter 6 Descriptions of Parameter SettingsEL-C Modbus Attribute Function Description address The digital output status (ON / OFF), refer to Pr.02-18 2211H (see Explanation 4 in Pr.00-04) 2212H Current step for the multi-step speed operation The corresponding CPU digital input pin status (d.) 2213H (see Explanation 3 in Pr.00-04) The corresponding CPU digital output pin status (O.)
Page 184 Chapter 6 Descriptions of Parameter SettingsEL-C Modbus Attribute Function Description address 222AH Reserved 222BH Reserved 222CH Motor actual position low character 222DH Motor actual position high character 222EH Reserved 222FH Reserved 2230H Reserved 2231H Reserved Remote IO (26xx) Modbus Attribute Function Description Address bit0...
Page 185 Chapter 6 Descriptions of Parameter SettingsEL-C Exception response: When the drive is using the communication connection, if an error occurs, the drive responds to the error code and sets the highest bit (bit 7) of the command code to 1 (function code AND 80H) then responds to the control system to signal that an error occurred.
Page 186 Chapter 6 Descriptions of Parameter SettingsEL-C 09-10 Communication Main Frequency Default: 60.00 Settings 0.00–400.00 Hz  When Pr.00-20 is set to 1 (RS-485 serial communication input) The AC motor drive saves the last Frequency command into Pr.09-10 when there is abnormal power off or momentary power loss. When power is restored, the AC motor drive operates with the frequency in Pr.09-10 if there is no new Frequency command input.
Page 187 CANopen Speed Default: 0 Settings 0: 1 Mbps 1: 500 Kbps 2: 250 Kbps 3: 125 Kbps 4: 100 Mbps (Delta Only) 5: 50 Kbps 09-39 CANopen Warning Record Default: 0 Settings bit 0: CANopen Guarding Time-out bit 1: CANopen Heartbeat Time-out...
Page 188 Chapter 6 Descriptions of Parameter SettingsEL-C 10 Speed Feedback Control Parameters  You can set this parameter during operation. 10-29 Upper Limit of Frequency Deviation  Default: 20.00 Settings 0.00–200.00 Hz  Limits the maximum frequency deviation.  If you set this parameter too high, an abnormal feedback malfunction occurs. 6-2-101...
Page 189 Chapter 6 Descriptions of Parameter SettingsEL-C [This page intentionally left blank] 6-2-102...
Page 190 Chapter 6 Descriptions of Parameter SettingsEL-C 12 System control and CANopen function parameters  You can set this parameter during operation. 12-00 System control Default: 0 Settings bit 3: Dead time compensation closed bit 7: Save or do not save the frequency 12-01 PWM mode selection Default: 2...
Page 191 Chapter 6 Descriptions of Parameter SettingsEL-C 12-07 CANopen Protocol Selection Default: 0 Settings 0: Standard CiA402 Protocol 1: Customization  When Pr.12-07 = 0, the CANopen decoding method needs to be selected with Pr. 09-30 and 09-  When Pr.12-07 = 1, the settings of Pr.09-30 and 09-40 are invalid. 12-08 CANopen MO1 Disconnection Disposal Default: 2...
Page 192 Chapter 6 Descriptions of Parameter SettingsEL-C 12-50 Output Frequency at Malfunction 2 12-54 Output Frequency at Malfunction 3 12-58 Output Frequency at Malfunction 4 12-62 Output Frequency at Malfunction 5 12-66 Output Frequency at Malfunction 6 Default: Read only Settings 0.00–400.00 Hz ...
Page 193 Chapter 6 Descriptions of Parameter SettingsEL-C 12-70 Fault Record 7 12-71 Fault Record 8 12-72 Fault Record 9 12-73 Fault Record 10 Default: 0 Settings 0: No fault record 1: Over-current during acceleration (ocA) 2: Over-current during deceleration (ocd) 3: Over-current during steady operation (ocn) 6: Over-current at stop (ocS) 7: Over-voltage during acceleration (ovA) 8: Over-voltage during deceleration (ovd)
Page 194 Chapter 6 Descriptions of Parameter SettingsEL-C 80: V-phase over-current before run (boc) 81: W-phase over-current before run (coc) 82: U-phase output phase loss (oPHL) 83: V-phase output phase loss (oPHL) 84: W-phase output phase loss (oPHL) 87: Low frequency overload protection (oL3) 101: CANopen guarding error (CGdE) 102: CANopen heartbeat error (CHbE) 104: CANopen bus off error (CbFE)
Page 195 Chapter 6 Descriptions of Parameter SettingsEL-C [This page intentionally left blank] 6-2-126...
Page 196 Chapter 6 Descriptions of Parameter SettingsEL-C 13 Control Mode Parameter Macro Function  You can set this parameter during operation. 13-00 Macro Selection Default: 0 Settings 0: No function 1: By user 2: I/O mode control 3: CANopen remote control and monitoring mode 4: I/O control and CANopen remote monitoring mode ...
Page 197 Chapter 6 Descriptions of Parameter SettingsEL-C Parameter Name Note Multi-function Output 4 No function 02-16 (MO4)  Setting 3: CANopen remote control and monitoring mode Parameter Name Note 00-11 Selections of control Default setting 0 (IM V/F) 00-16 Load selection Default setting 1 (Heavy load) Master frequency...
Page 198 Chapter 6 Descriptions of Parameter SettingsEL-C  Setting 4: I/O control and CANopen remote monitoring mode Parameter Name Note 00-11 Selections of control Default setting 0 (IM V/F) 00-16 Load selection Default setting 1 (Heavy load) Master frequency 00-20 0 (Digital keypad) command source Operation command 00-21...
Page 199 Chapter 6 Descriptions of Parameter SettingsEL-C [This page intentionally left blank] 6-2-134...
Page 200: Chapter 7 Warning Codes
Chapter 7 Warning CodesEL-C Chapter 7 Warning Codes Summary of Warning Codes Warning Name Warning Name Communication error 1 (CE1) CANopen heartbeat error (CHbn) Communication error 2 (CE2) CANopen bus off error (CbFE) Communication error 3 (CE3) CANopen index error (CidE) Communication error 4 (CE4) CANopen station address error (CAdE) Communication error 10 (CE10)
Page 201 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions Communication error 1 RS-485 Modbus illegal function code (CE1) Action and Reset Action level When the function code is not 03, 06, 10, or 63. Action time Immediately act Warning setting parameter “Warning”...
Page 202 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions Communication error 2 RS-485 Modbus illegal data address (00–254 H) (CE2) Action and Reset Action level When the data address is incorrect. Action time Immediately act Warning setting parameter “Warning”...
Page 203 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions Communication error 3 RS-485 Modbus illegal data value (CE3) Action and Reset Action level When the data length is too long Action time Immediately act Warning setting parameter “Warning”...
Page 204 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions Communication error 4 RS-485 Modbus data is written to read-only address (CE4) Action and Reset Action level Data is written to read-only address Action time Immediately act Warning setting parameter “Warning”...
Page 205 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions Communication error RS-485 Modbus transmission time-out 10 (CE10) Action and Reset When the communication time exceeds the detection time of Pr.09-03 Action level communication time-out Action time Pr.09-03 Warning setting parameter “Warning”...
Page 206 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions The AC motor drive detects over-heating of IGBT, and over the protection level of oH1 warning. IGBT over-heating (When Pr.06-15 is higher than the IGBT over-heating warning (oH1) level, the drive shows oH1 error without displaying oH1 warning.)
Page 207 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions Over-torque 1 Over-torque 1 warning (ot1) Action and Reset Action level Pr.06-07 Action time Pr.06-08 Pr.06-06 Over-torque Detection Selection (Motor 1) =1 or 3 0: No detection 1: Continue operation after over-torque detection during constant speed Warning setting parameter operation...
Page 208 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions Over slip warning. By using the maximum slip (Pr.10-29) as the base, Over slip error when the drive outputs at constant speed, and the F>H (oSL) or F<H exceeds Pr.07-29 level and Pr.07-30 setting time, 100% Pr.07-29 = Pr.10-29.
Page 209 Chapter 7 Warning CodesEL-C ID No. Display on LED Keypad Warning Name Fault Descriptions Output phase loss Output phase loss of the drive (oPHL) Action and Reset Action level Pr.06-47 Action time Pr.06-45 0: Warn and continue operation Warning setting parameter 1: Warn and ramp to stop 2: Warn and coast to stop 3: No warning...
Page 210 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen guarding CANopen guarding error time-out (CGdn) Action and Reset When CANopen Node Guarding detects that one of the slaves does not respond, Action level the CGdE fault occurs. The upper unit sets the factor and time during configuration.
Page 211 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen heartbeat CANopen heartbeat error error (CHbn) Action and Reset When CANopen Heartbeat detects that one of the slaves does not respond, the CHbE fault occurs. Action level The upper unit sets the confirming time of producer and consumer during configuration.
Page 212 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen bus off error CANopen BUS off error (CbFE) Action and Reset Hardwar When CANopen card is not installed, the CbFn warning occurs. When the master receives wrong communication package, the CbFn Action level warning occurs.
Page 213 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen index error CANopen index error (CidE) Action and Reset Action level CANopen index error Action time Immediately act when the fault is detected Warning setting parameter Reset method Manual reset Reset condition...
Page 214 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen station CANopen station address error (only supports 1–127) address error (CAdE) Action and Reset Action level CANopen station address error Action time Immediately act when the fault is detected Warning setting parameter Reset method Manual reset...
Page 215 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen index setting CANopen memory error exceed limit (CFrE) Action and Reset When you update the firmware version of the control board, the FRAM internal Action level data does not change, then CFrn warning occurs.
Page 216 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen SDO SDO transmission time-out time-out (CSdn) (only shows on master station) Action and Reset When the CANopen master transmits a SDO command, and the slave Action level response “times-out”, CSdn warning occurs.
Page 217 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen SDO receives register CANopen SDO receives register overflow overflow (CSbn) Action and Reset Action level The upper unit sends too much SDO at one time and causes buffer overflow Action time Immediately act when the fault is detected Warning setting parameter...
Page 218 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen start-up CANopen start-up error warning error warning (Cbtn) Action and Reset Action level When the amount of sent error messages reach 255 Action time Warning setting parameter Index 6007 Reset method Disable CANopen, and cycle the power after power-off...
Page 219 Chapter 7 Warning CodesEL-C ID No. Display on LCD Keypad Warning Name Fault Descriptions CANopen format error CANopen protocol format error (CPtn) Action and Reset The slave detects that communication data from the upper unit cannot be Action level recognized, and then CPtn warning occurs. Action time Immediately act when the fault is detected Warning setting parameter...
Page 220: Chapter 8 Fault Codes
Chapter 8 Fault CodesEL-C Chapter 8 Fault Codes Summary of Fault Codes Fault Name Fault Name Over-current during acceleration (ocA) Password is locked (Pcod) Over-current during deceleration (ocd) Illegal command (CE1) Over-current during steady operation (ocn) Illegal data address (CE2) Over-current at stop (ocS) Illegal data value (CE3) Over-voltage during acceleration (ovA)
Page 221 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Output current exceeds three times of the rated current during acceleration. Over-current during When ocA occurs, the drive closes the gate of the acceleration (ocA) output immediately, the motor runs freely, and the display shows an ocA error.
Page 222 Chapter 8 Fault CodesEL-C Cause Corrective Actions Improper parameter settings for the speed tracking function Correct the parameter settings for speed tracking. (including restart after 1. Start the speed tracking function. momentary power loss and 2. Adjust the maximum current for Pr.07-09 speed tracking. restart after fault) The length of motor cable is too Increase the AC motor drive’s capacity.
Page 223 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Output current exceeds 2.5 times of the rated current Over-current during during deceleration. When ocd occurs, the drive closes deceleration (ocd) the gate of the output immediately, the motor runs freely, and the display shows an ocd error.
Page 224 Chapter 8 Fault CodesEL-C The ocA occurs due to the short circuit or ground fault at the output side of the drive. Hardware failure Check for possible short circuits between terminals with the electric meter: B1 corresponds to U, V and W; DC- corresponds to U, V and W; corresponds to U, V and W.
Page 225 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Output current exceeds three times of the rated current Over-current during during acceleration. When ocn occurs, the drive closes steady operation (ocn) the gate of the output immediately, the motor runs freely, and the display shows an ocn error.
Page 226 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Over-current or hardware failure in current detection at Over-current at stop stop. (ocS) Cycle the power after ocS occurs. If the hardware failure occurs, the display shows cd1, cd2 or cd3. Action and Reset Action level 240% of the rated current...
Page 227 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions DC bus over-voltage during acceleration. When ovA Over-voltage during occurs, the drive closes the gate of the output, the acceleration (ovA) motor runs freely, and the display shows an ovA error. Action and Reset 230V models: 410 V Action level...
Page 228 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions DC bus over-voltage during deceleration. When ovd Over-voltage during occurs, the drive closes the gate of the output deceleration (ovd) immediately, the motor runs freely, and the display shows an ovd error.
Page 229 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions DC bus over-voltage at constant speed. When ovn Over-voltage during occurs, the drive closes the gate of the output constant speed (ovn) immediately, the motor runs freely, and the display shows an ovn error.
Page 230 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Over-voltage at stop Over-voltage at stop (ovS) Action and Reset 230V models: 410 V Action level 460V models: 820 V Action time Immediately act when the DC bus voltage is higher than the level Fault treatment parameter Reset method Manual reset...
Page 231 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Low-voltage during DC bus voltage is lower than Pr.06-00 setting value acceleration (LvA) during acceleration Action and Reset Action level Pr.06-00 (Default = depending on the model) Action time Immediately act when the DC bus voltage is lower than Pr.06-00 Fault treatment parameter Reset method...
Page 232 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Low-voltage during DC bus voltage is lower than Pr.06-00 setting value deceleration (Lvd) during deceleration Action and Reset Action level Pr.06-00 (Default = depending on the model) Action time Immediately act when the DC bus voltage is lower than Pr.06-00 Fault treatment parameter Reset method...
Page 233 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Low-voltage at DC bus voltage is lower than Pr.06-00 setting value at constant speed (Lvn) constant speed Action and Reset Action level Pr.06-00 (Default = depending on the model) Action time Immediately act when the DC bus voltage is lower than Pr.06-00 Fault treatment parameter...
Page 234 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions 1. DC bus voltage is lower than Pr.06-00 setting value Low-voltage at stop at stop (LvS) 2. Hardware failure in voltage detection Action and Reset Action level Pr.06-00 (Default = depending on the model) Action time Immediately act when the DC bus voltage is lower than Pr.06-00 Fault treatment parameter...
Page 235 The input cable of three-phase Wire correctly. power is cut off Replace the cut off cable. Unbalanced three-phase of input Check the power three-phase status. power Use Open Delta Connection Install reactors or use drives with higher power. system 8-16...
Page 236 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions IGBT overheating IGBT temperature exceeds the protection level. (oH1) (Refer to Pr.06-15) Action and Reset (When Pr.06-15 is higher than the IGBT overheating protection level, the drive Action level shows oH1 error without displaying oH1 warning.) IGBT temperature exceeds the protection level for more than 100 ms, oH1 error Action time...
Page 237 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions IGBT temperature IGBT hardware failure in temperature detection detection failure (tH1o) Action and Reset Action level NTC broken or wiring failure When the IGBT temperature is higher than the protection level, and detection Action time time exceeds 100 ms, the tH1o protection activates.
Page 238 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions The AC motor drive detects excessive drive output current. Normal duty: Sustains for one minute when the drive outputs 120% of the drive’s rated output current. Over load Sustains for three seconds when the drive outputs 150% (oL) of the drive’s rated output current.
Page 239 Chapter 8 Fault CodesEL-C Improper parameter settings for Correct the parameter settings for speed tracking. the speed tracking function Start the speed tracking function. (including restart after momentary Adjust the maximum current for Pr.07-09 speed tracking. power loss and restart after fault) 8-20...
Page 240 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Electronics thermal Electronic thermal relay 1 protection. The drive coasts relay 1 protection to stop once it activates. (EoL1) Action and Reset Action level Start counting when the output current > 150% of the motor 1 rated current Pr.06-14 (If the output current is larger than 105% of the motor 1 rated current Action time again within 60 sec., the counting time reduces and is less than Pr.06-14)
Page 241 Chapter 8 Fault CodesEL-C Unbalanced three-phase Replace the motor. impedance of the motor 8-22...
Page 242 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions When the output current exceeds the over-torque Over torque 1 detection level (Pr.06-07) and exceeds over-torque (ot1) detection time (Pr.06-08), and when Pr.06-06 or Pr.06- 09 is set to 2 or 4, the ot1 error displays. Action and Reset Action level Pr.06-07...
Page 243 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Under current Low current detection (uC) Action and Reset Action level Pr.06-71 Action time Pr.06-72 Pr.06-73 0: Normal deceleration Fault treatment parameter 1: Fault and coast to stop 2: Fault and ramp to stop by the 2nd deceleration time 3: Warn and continue operation When Pr.06-73=3, uC is a “Warning”.
Page 244 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions EEPROM read error Internal EEPROM cannot be read (cF2) Action and Reset Action level Firmware internal detection Action time cF2 acts immediately when the drive detects the fault Fault treatment parameter Reset method Manual reset...
Page 245 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions U-phase error U-phase current detection error when power is ON (cd1) Action and Reset Action level Hardware detection Action time cd1 acts immediately when the drive detects the fault Fault treatment parameter Reset method Power-off...
Page 246 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions V-phase error V-phase current detection error when power ON (cd2) Action and Reset Action level Hardware detection Action time cd2 acts immediately when the drive detects the fault Fault treatment parameter Reset method Power-off...
Page 247 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions W-phase error W-phase current detection error when power ON (cd3) Action and Reset Action level Hardware detection Action time cd3 acts immediately when the drive detects the fault Fault treatment parameter Reset method Power-off...
Page 248 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions cc hardware error cc (current clamp) hardware protection error when (Hd0) power is ON Action and Reset Action level Hardware detection Action time Hd0 acts immediately when the drive detects the fault Fault treatment parameter Reset method Power-off...
Page 249 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions oc hardware error oc hardware protection error when power is ON (Hd1) Action and Reset Action level Hardware detection Action time Hd1 acts immediately when the drive detects the fault Fault treatment parameter Reset method Power-off...
Page 250 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions External fault External fault. When the drive decelerates based on the (EF) setting of Pr.07-20, the EF fault displays on the keypad. Action and Reset Action level MIx=EF and the MI terminal is ON Action time Immediately act Pr.07-20...
Page 251 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions When the contact of MI = EF1 is ON, the output stops Emergency stop immediately and displays EF1 on the keypad. The motor (EF1) is in free running. Action and Reset Action level MIx=EF1 and the MI terminal is ON...
Page 252 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions When the contact of MI = bb is ON, the output stops External base block immediately and displays bb on the keypad. The motor (bb) is in free running. Action and Reset Action level MIx=bb and the MI terminal is ON...
Page 253 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Password is locked Entering the wrong password three consecutive times (Pcod) Action and Reset Action level Entering the wrong password three consecutive times Action time Immediately act Fault treatment parameter Reset method Manual reset Reset condition...
Page 254 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Illegal command Communication command is illegal (CE1) Action and Reset Action level When the function code is not 03, 06, 10, or 63. Action time Immediately act Fault treatment parameter Reset method Manual reset Reset condition...
Page 255 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Illegal data address Data address is illegal (CE2) Action and Reset Action level When the data address is incorrect. Action time Immediately act Fault treatment parameter Reset method Manual reset Reset condition Immediately reset...
Page 256 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Illegal data value Data value is illegal (CE3) Action and Reset Action level When the data length is too long Action time Immediately act Fault treatment parameter Reset method Manual reset Reset condition Immediately reset...
Page 257 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Data is written to read-only address Data is written to read-only address (CE4) Action and Reset Action level Data is written to read-only address Action time Immediately act Fault treatment parameter Reset method Manual reset...
Page 258 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Modbus transmission Modbus transmission time-out occurs time-out (CE10) Action and Reset When the communication time exceeds the detection time for Pr.09-03 Action level communication time-out. Action time Pr.09-03 Pr.09-02 0: Warn and continue operation Fault treatment parameter...
Page 259 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions When Pr.07-13 is not 0, and the power is suddenly off, Deceleration energy causing the DC bus voltage lower than the dEb action backup error (dEb) level, the dEb function acts and the motor ramps to stop.
Page 260 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions U-phase over-current U-phase short circuit detected when the output wiring before run (Aoc) detection is performed before the drive runs. Action and Reset Action level 240% of the rated current Action time Immediately act Fault treatment parameter...
Page 261 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions V-phase over-current V-phase short circuit detected when the output wiring before run (boc) detection is performed before the drive runs. Action and Reset Action level 240% of the rated current Action time Immediately act Fault treatment parameter...
Page 262 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions W-phase over-current W-phase short circuit detected when the output wiring before run (coc) detection is performed before the drive runs. Action and Reset Action level 240% of the rated current Action time Immediately act Fault treatment parameter...
Page 263 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Output phase loss U U phase output phase loss phase (oPL1) Action and Reset Action level Pr.06-47 Pr.06-46 Action time Pr.06-48: Use the setting value of Pr.06-48 first. If DC braking function activates, use that of Pr.06-46.
Page 264 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Output phase loss V V phase output phase loss phase (oPL2) Action and Reset Action level Pr.06-47 Pr.06-46 Action time Pr.06-48: Use the setting value of Pr.06-48 first. If DC braking function activates, use that of Pr.06-46.
Page 265 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions Output phase loss W W phase output phase loss phase (oPL3) Action and Reset Action level Pr.06-47 Pr.06-46 Action time Pr.06-48: Use the setting value of Pr.06-48 first. If DC braking function activates, use that of Pr.06-46.
Page 266 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions 87: Low frequency overload protection Low frequency and high current protection (oL3) Action and Reset Action level Software detection Action time Immediately act Fault treatment parameter Reset method Manual reset Reset condition Immediately reset...
Page 267 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions CANopen guarding CANopen guarding error 1 error (CGdE) Action and Reset When CANopen Node Guarding detects that one of the slaves does not respond, Action level the CGdE fault occurs. The upper unit sets the factor and time during configuration.
Page 268 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions CANopen heartbeat CANopen heartbeat error 2 error (CHbE) Action and Reset When CANopen Heartbeat detects that one of the slaves does not respond, the CHbE fault occurs. Action level The upper unit sets the confirming time of producer and consumer during configuration.
Page 269 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions CANopen bus off error CANopen bus off error (CbFE) Action and Reset Hardware When CANopen card is not installed, the CbFn warning occurs. When the master receives wrong communication package, the CbFE fault occurs.
Page 270 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions CANopen index error CANopen index error (CidE) Action and Reset Action level Software detection Action time Immediately act Fault treatment parameter Reset method Manual reset Reset condition The upper unit sends a reset package to clear this fault. Record Cause Corrective Actions...
Page 271 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions CANopen station CANopen station address error (only supports 1–127) address error (CAdE) Action and Reset Action level Software detection Action time Immediately act Fault treatment parameter Reset method Manual reset (Pr.00-02=7) Reset condition Record...
Page 272 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions CANopen index setting CANopen memory error exceed limit (CFrE) Action and Reset When you update the firmware version of the control board, the FRAM internal Action level data does not change, then CFrE fault occurs. Action time Immediately act Fault treatment parameter...
Page 273 Chapter 8 Fault CodesEL-C Display on LED Keypad Fault Name Fault Descriptions InrCOM time-out error Internal communication time-out (ictE) Action and Reset Pr.09-31 = -1~ -10 (there is no -9), when the internal communication between Action level Slave and Master is abnormal, IctE fault occurs. Action time Immediately act Fault treatment parameter...
Page 274 Fault Name Fault Descriptions Internal communication Internal communication time-out error (CP20) Action and Reset Action level Software detection Action time Immediately act Fault treatment parameter Reset method Record Cause Corrective Actions Internal communication error Contact local agent or Delta 8-55...
Page 275 Fault Name Fault Descriptions Internal communication Abnormal internal communication error (CP22) Action and Reset Action level Software detection Action time Immediately act Fault treatment parameter Reset method Record Cause Corrective Actions Internal communication error Contact local agent or Delta 8-56...
Page 276 Fault Name Fault Descriptions Internal communication Internal communication time-out error (CP30) Action and Reset Action level Software detection Action time Immediately act Fault treatment parameter Reset method Record Cause Corrective Actions Internal communication error Contact local agent or Delta 8-57...
Page 277 Fault Name Fault Descriptions Internal communication Abnormal internal communication error (CP32) Action and Reset Action level Software detection Action time Immediately act Fault treatment parameter Reset method Record Cause Corrective Actions Internal communication error Contact local agent or Delta 8-58...
Page 278 Fault Name Fault Descriptions Internal communication Abnormal internal communication error (CP33) Action and Reset Action level Software detection Action time Immediately act Fault treatment parameter Reset method Record Cause Corrective Actions Internal communication error Contact local agent or Delta 8-59...
Page 279 Short-circuit at motor output due to Check the motor cable and remove causes of the short circuits, or replace the poor insulation wiring cable before turning on the power. The internal circuit of the drive is Contact your local distributor or Delta. abnormal 8-60...
Page 280: Circuit Breaker
Appendix A. Optional Accessories | EL-C Appendix A. Optional Accessories A-1 Circuit Breaker A-2 Reactors A-3 Remote Operation Keypad A-4 The Assembly of Fan Kit A-5 CANopen Accessories...
Page 281 The accessories produced by Delta are only suitable for the motor drive produced by  Delta. Do not use other accessories to with the motor drive, which may cause failure easily.
Page 282 Appendix A. Optional Accessories | EL-C A-1 Circuit Breaker The rated current of the breaker shall be 2–4 times of the maximum rated input current of the AC motor drive. Single-phase Three-phase Model Suggested current [A] Model Suggested current [A] VFD002EL21C VFD004EL43C VFD004EL21C...
Page 283 Appendix A. Optional Accessories | EL-C A-2 AC Reactor A-2-1 AC Reactor AC Input Reactor 230V, 50 / 60 Hz, Single-phase Basic Amps Maximum continuous Amps Inductance (mH) 3–5% Impedance 0.25 0.75 1.25 460V, 50 / 60 Hz, Three-phase Inductance (mH) Basic Amps Maximum continuous Amps 3% Impedance...
Page 284 Appendix A. Optional Accessories | EL-C AC reactor application Connected in input circuit Application–1 The same power supply is connected to multiple drives and the drive is running, a certain drive power supply is turned on. Causes / problems: In the same power system, when the solenoid valve of the drive is turned on, the charging current of the capacitor will cause voltage ripples, and the DC side voltage of other drives will fluctuate too much at the same time.
Page 285 Appendix A. Optional Accessories | EL-C A-2-2 Zero phase reactor RF220X00A UNIT: mm [inch] Figure A Recommended Each line needs four turns when passing Wire Size (mm Wiring through the zero-phase reactor. Cable type Qty. Note Method Nominal This reactor should be as close as possible to *AWG the drive.
Page 286: Remote Operation Keypad
Appendix A. Optional Accessories | EL-C A-3 Remote Operation Keypad A-3-1 VFD-PU08V Keypad A-3-2 VFD-PU08V status, key and digital dial function Status Descriptions Status displayed Note RUN: VFD is running FWD: VFD is running forwardly REV: VFD is running reversely STOP: VFD is stopped STOP Flashing: VFD is stopping VR light on: VFD potentiometer function is enabled...
Page 287 Appendix A. Optional Accessories | EL-C B. If the power is turned off and on again, the default function is enabled (2) Function enable When the power supply of VFD-PU08V is normal, and the drive matches the communication protocol and model setting of VFD-PU08V, the preset will affect. (3) Function switch A.
Page 288 Appendix A. Optional Accessories | EL-C A-3-4 VFD-PU08V Dimensions...
Page 289: The Assembly Of Fan Kit
Appendix A. Optional Accessories | EL-C A-4 The Assembly of Fan Kit After the VFD007EL21C is installed with a cooling fan, the upper limit of the ambient operating temperature is increased to 50°C without derating. If the fan is not installed, the upper limit of the ambient operating temperature is 40°C without derating.
Page 290 Appendix A. Optional Accessories | EL-C A-5 CANopen Acessories A-5-1 CANopen junction box Model Description TAP-CN01 1 point 2, built-in 121Ω terminal resistance TAP-CN02 1 point 4, built-in 121Ω terminal resistance TAP-CN03 1 point 4, RJ45 connector, built-in 121Ω terminal resistance Unit: mm [inch] A-5-2 TAP-TR01 terminal resistor A-5-3 Standard extension cable...
Page 291 Appendix A. Optional Accessories | EL-C [This page is intentionally left blank] A-12...
