JOG AND SWITCH UNIT CIRCUIT
: IF NOT SPECIFIED 0.01µF / 25V
: IF NOT SPECIFIED 1/10W ± 5%
IC1-6(P73)
R68 15 k
IC1-7(P72)
R69 15 k
IC1-8(P71)
R70 15 k
IC1-9(P70)
R71 15 k
VC
GND
IC1-77(AN4)
R52 15 k
IC1-18(P47)
R50 4.7 k
IC1-22(INT1)
R51 4.7 k
Figure S-5(a). Jog and Switch Circuit
J-13
J-12
J-11
J-10
J - 9
J - 8
J - 7
J - 4
J - 3
J - 6
J - 5
J - 2
J - 1
CN - J
Figure S-5(b). Jog and Switch Unit Circuit
J - 6 J - 5
CN - J
AUTO
COOK
AUTO
REHEAT
3
2
VR
1
C
B
A
A
B
C
1
2
3
SW1 SW2
AUTO
COOK
SW5 SW6
EXPRESS
COOK
SW9 SW10
WATT
SW11 SW12
41
J - 2 J - 1
WATT
STOP
RSW1
RSW1 ROTARY ENCODER
VR1 POTENTIOMETERS
SW3 SW4
SW7 SW8
EXPRESS
AUTO
REHEAT DEFROST
SW13
STOP
