Opengear ACM7004-5 Quick Start Manual

Remote site gateway
Hide thumbs
1
2
3

Advertisement

Table of Contents

ACM7004-5 remote site gateway quick start guide
The ACM7004-5 quick start guide documents installation, configuration and local operation.
01. Check the kit's contents are complete
#
item
1
ACM7004-5
1
DB9F-to-RJ45 crossover serial adapter
1
12V switching DC power supply
4
Country-specific power socket adapters
Rack kit (1 tab, 1 ear, 2 rack screws, 2 nuts,
1
4 screws)
4
Adhesive-backed rubber feet
1
Digital I/O converter (terminal block)

02. Assemble the hardware

01. If free-standing: attach the adhesive-backed rubber feet to the ACM7004-5's base.
02. If rack-mounted: attach the rack kit to the side of the ACM7004-5 which will be fixed to the rack.
03. Connect the ACM7004-5 to your primary network via either NET1(C) or NET1(S). NET1(C) is an
RJ45 port. NET1(S) takes an SFP (Small Form-factor Pluggable transceiver) module for connecting
to either copper or fibre.
04. For Out-of-Band (OOB) management: connect a NET2 RJ45 port to a management network.
05. Connect other devices to the ACM7004-5's free serial ports; USB ports; and NET2 ethernet
ports.
06. If you have external sensors: plug in the terminal block and attach sensors and DIO devices.
07. Plug in the 12V DC power supply and turn on power to the ACM7004-5.

03. Connect to the ACM7004-5

The ACM7004-5 is addressable at either of two IP addresses:
01. its built-in address of 192.168.0.1/24.
02. the address its on-by-default DHCP client accepts from a DHCP server on your network.
Using a browser on the same network as the ACM7004-5's NET1 ports with an IP address in one of
the ACM7004-5's network ranges (ie 192.168.0.x/24 or the range used by your DHCP server):
03. enter https:/ /192.168.0.1/ or https:/ /[DHCP-supplied address]/ in the address bar and press Enter.
Note: the ACM7004-5 has a self-signed SSL certificate. 'Untrusted connection' errors will present.
ACM7004-5 Remote Site Gateway Quick Start Guide (520086 — revision 1.0.0)
part #
links to Opengear stores
acm7004-5
319015
US
UK
450031
US
UK
n/a
Part of the power supply.
590003
Not available separately.
n/a
Not available separately.
n/a
Not available separately.
EU
AU
INT
EU
AU
INT
page 1 of 3
