Opengear ACM5504-5-GV-I Quick Start Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Thank you for purchasing the ACM5504-5-GV-I management gateway. This Quick Start
walks you through installation and configuration. More details are available in the
Manual
which can be downloaded from
Step1 Check kit contents

Step 2 Configure the hardware

Attach rubber feet to base. Also attach the desired mounting tab and screw the
3G antenna on to the main
or GPS antenna, screw it on to Cell A
Connect the Ethernet
devices to the
Plug your serial console devices into
Connect your USB devices to the two
Plug in the green screw terminal block and attach external sensors and DIO
Note: Refer to ACM5500-I Addendum for RS422/485 and DIO details
Apply power. The ACM5504-5-GV-I can now be powered externally by either:
connecting the provided external power pack to the
connecting an external 9 to 24 VAC source to the
connecting +9V to 30 VDC to
Note: If you ordered the -SDC option you'll have an external DC-DC
power converter (input voltage +/- 36V DC to 72V DC. The
converter power cable/ connector plugs into the
The ACM5504-5-GV-I is ready for activation when the PWR status LED on the front panel
of the unit is lit steady, and the H/B (heartbeat) LED is flashing.

Step 3 Set up the appliance

The default IP Address is
on any computer that is network connected to the ACM5504-5-G-I:
ACM5504-5-GV-I Quick Start (520040-Rev 1.3)
http://opengear.com/documentation
ACM5504-5-GV-I device.
tabs.
Green connector block and
Straight (319014) & crossover (319015) DB9F-RJ45S.
Straight (319016) DB9M-RJ45. Quick Start. 12VDC power
pack.
Cell (M)
LAN
port to your network. Connect your management LAN
ETHERNET 1-4
ports
DC PWR
192.168.0.1
(subnet mask
ACM5504-5-GV-I
Quick Start Guide
External rack and DIN rail
connector If you have purchased a diversity
SERIAL 1-4
(all Cisco RJ45 pin-out).
USB
ports
12VDC
12VDC
GND
and
on the green terminal block
12VDC
socket
255.255.255.0
User
.
mount
3G antenna. UTP cables.
barrel socket or
barrel socket or
). With a web browser
Page 1
