- Page 1 INSTALLATION & USER MANUAL INTEGRATED RANGEHOOD WRI500SB, WRI500DB, WRI700SB...
- Page 2 WELCOME TO WESTINGHOUSE CONTENTS Important safety instructions Thank you for purchasing an Westinghouse appliance. You’ve chosen a product that brings with it decades Installation of professional experience and innovation. Ingenious Operation and maintenance and stylish, it has been designed with you in mind. So...
- Page 3 SAFETY INSTRUCTIONS Please read this manual carefully prior to installing and CAUTION using the rangehood in order to avoid damage or injury. The manufacturer will not accept liability for damage • Accessible parts may become hot when used with caused from not following these instructions. If you cooking appliance.
- Page 4 455 /648 Wooden support Fixing point dimensions – WRI500SB, WRI500DB Fixing the air outlet Flip the non-return valves and fix them with tape or clamp temporarily. Use screws to fix the air outlet to the rangehood then release the non-return valves.
- Page 5 INSTALLATION Installing carbon filters Fixing the rangehood Use screw to fasten the rangehood to the wood Replace the air intake grills with carbon filters. support from botton side. air intake grill carbon filter ST 4 x 32 Fixing the front panel and filter Optional carbon filters diminish cooking odours in the Replace the front cover by replacing the 4x screws, recirculated air.
- Page 6 OPERATION & MAINTENANCE Cleaning the surface IMPORTANT! The Edison Screw lamps may have come loose during Clean the surfaces using non-abrasive cleaning products. transportation. To ensure best results also use an even pressure. Ensure that lamps are tightened firmly into the socket Use of a soft cloth reduces the risk of scratching.
- Page 7 (c) ‘ASC’ means Electrolux’s authorised serviced centres; the Appliance; (d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products In addition, Electrolux is not liable under this warranty if: Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004...
- Page 8 Top Service encompasses the after sales service provided by The Electrolux Group to consumers including delivery, home service and spare parts. and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license. All Rights Reserved. © 2018 Electrolux Home Products Pty Ltd.
