Step 9
H A R D WA R E
A
Cam Lock Ø15 mm
Cam Cover Ø17 mm
C
C O M P O N E N T S
3
Left Side Board
7
Rear Board
Step 10
H A R D WA R E
A
Cam Lock Ø15 mm
Cam Cover Ø17 mm
C
C O M P O N E N T S
3
Left Side Board
6
Drawer Support
x4
x4
x1
x2
x2
x2
x1
x2
C
A
C
A
PAGE 8 OF 17
