Step 13
H A R D WA R E
A
Cam Lock Ø15 mm
Cam Cover Ø17 mm
C
C O M P O N E N T S
4
Right Side Board
6
Drawer Support
7
Rear Board
Step 14
H A R D WA R E
H
Sleeve Nut
Allen Key
I
C O M P O N E N T S
2
Bottom Board
8
Legs
9
Middle Leg
x6
x6
x1
x2
x2
x5
x1
x1
x4
x1
C
A
PAGE 10 OF 17
