Step 20
H A R D WA R E
O
Backply Stopper
P
Screw M 4 x 19 mm
C O M P O N E N T S
10
Front Drawer Board
12
Left Drawer Board
13
Right Drawer Board
15
Bottom Drawer Board
Step 21
H A R D WA R E
F
Screw M 6 x 13 mm
L
Drawer Rails
C O M P O N E N T S
12
Left Drawer Board
13
Right Drawer Board
x4
x4
x6
x6
x6
x6
x24
x6
x6
x6
