Step 5
H A R D WA R E
B
Cam Bolt Ø7.5 x 32 mm
D
Plastic Dowel Ø6 x 30 mm
E
Screw M 6 x 8 mm
L
Drawer Rail
Q
Screw M 6 x 9 mm
C O M P O N E N T S
9
Divider Board
Step 6
H A R D WA R E
D
Plastic Dowel Ø6 x 30 mm
C O M P O N E N T S
7
Rear Board
x4
x4
x12
x3
x6
x1
Q
x10
x2
Q
Q
Q
