Step 1
H A R D WA R E
B
Cam Bolt Ø7.5 x 32 mm
C O M P O N E N T S
1
Top Board
Step 2
H A R D WA R E
B
Cam Bolt Ø7.5 x 32 mm
E
Screw M 6 x 8 mm
J
Push To Open
C O M P O N E N T S
2
Bottom Board
x8
x1
x2
x4
x2
x1
PAGE 4 OF 17
