Introduction WindPro Online is the ultimate IoT solution to enhance operational safety. Users can access site-specific data remotely, set wind speed and wind direction alerts, and integrate with external devices for control and data acquisition via various outputs. The main hardware consists of a long-range wireless wind sensor and a control console. Users can opt-in to Scarlet Web Portal to access live and historical data, received remote safety alerts, and oversee hardware status anytime, anywhere.
Page 7
Sensor WL-21 Wind Cups Wind Speed Sensor Temperature & Atmospheric Pressure Sensor Sensor Body Wind Vane Wireless Connection Each Wind Sensor has a unique wireless address number pre-paired corresponding to the channel 1 of Control Console. Users can add a 2nd wind sensor to the Control Console channel 2 to monitor the wind data, received alerts, and control external devices from both sensors at the same time.
Operation Interface Operation Flow Press the Power button, to turn on WindPro and enter the HOME page (CH1 INFO). Swipe right /left on the touch screen to go to the other pages as shown on diagram below: Home Page CH1 & CH2...
Page 11
Wind Direction Current wind direction of this channel Maximal & Average Wind The channel’s maximum & average wind speed since this WindPro Speed power-on Temperature & Wind Chill Current temperature and wind chill of this channel...
Page 12
14.9 Name Definition Item Channel 1 Wireless Signal Status Wireless signal strength between WindPro & sensor 1 Channel 1 Status Sensor and battery status of channel 1 Channel 1 Mute Status Mute ON or OFF of channel 1 Channel 1 Alarm Threshold and Type Alarm 1, 2 and 3 are wind speed threshold and alarm 4 can be wind speed, wind direction or sensor connection status of channel 1.
Page 13
SETTINGS page SE T T ING S SENSO R PAIRIN G CH AN NEL 1 MEASUREMENTS OFFSE T CH AN NEL 2 MEASUREMENTS OFFSE T AL ARM DATA CONN ECTIVIT Y 4- 20 mA GEN ERAL CALIBRAT IO N Item Name Definition Sensor Pairing...
Page 14
SENSOR PAIRING page C H AN N EL 1 S EN S O R AD DRESS SPEED & DIR ECT ION S EN SO R T Y PE S EN SO R AD D RES S BACK Item Name Definition Sensor Type Speed only (WR-3 Plus Sensor) Speed &...
Page 15
ALARM Page CH A NNEL 1 A L AR M 1 WIND S P EE D (R E L AY 1 ) S P EE D T HRE S HO LD 2 5 .0 O N D EL AY ( RES P ONS E TIME ) 2 S E C C H AN N EL 1 AL AR M O FF D EL AY (RE T RIE VAL TIME )
Page 16
Go to RS232 connectivity setting page for PC utility 2.4G Wireless Broadcasting Go to 2.4G Wireless connectivity setting page for mobile App Connect to Portal Connect or disconnect to WindPro Web Portal Portal Validate Date The last validate date device connected to Web Portal...
Page 17
ETHERNET page E T HER NE T ( TC P /IP ) OBTAIN IP AUTO M ATIC A LLY ( D HC P) 192.168. 100.101 US E B ELO W IP AD D R ES S IP AD D RES S 1 92.168.100.
Page 18
Wi-Fi page W i - F i Wi -Fi TC P/ IP W i - F i C O N N E CT I V IT Y O BTAIN IP AUTO M AT ICALLY ( DH CP) S c a r l e t 1 92.1 68.1 0 0 .1 0 1 US E B ELO W I P ADDR ES S W i - F i N E T W O R K...
Page 19
2.4GHZ WIRELESS BROADCASTING page 2. 4 GHz WIR ELES S B ROA DC A S TIN G 2. 4 GHZ WIR EL ES S B R OAD C AS T I NG D I SP L AY N A ME 22 11 W P 0 1 4 6 B AC K Item...
Page 20
GENERAL page GENERA L DATE ( DD/MM /Y Y Y Y ) 15/02/2022 (UTC +00:00 ) 15:38 TIM E UNIT FACTO RY RESE T DEV ICE INFORM ATIO N BACK Item Name Definition Date Go to data setting page. Time Go to time setting page.
Installation and Setup WindPro Sensor Installation WindPro’s package comes with a Magnetic Sensor Mounting Bracket that supports fast and flexible installation. 1. Loosen the clamp 2. Insert the sensor body from the bottom of the clamp 3. Tighten the clamp 4.
Power Supply The DC power jack of WindPro Console is at the left side. WindPro package contains a receiver power adapter with type A, C, G, I plug converters. Power On ▪Connect Console with a power outlet using adapter. the device will turn on automatically while the electricity is supplied.
2. Tap WIND SPEED > VELOCITY OFFSET, then modify the offset percentage. Alarm WindPro provides four configurable alarms for each channel. ALARM 1 to 3 can be set for wind speed values. ALARM 4 is a user-defined alarm that can be triggered based on wind speed thresholds, wind direction zone, or disconnection of the sensor's wireless signal.
RELAY Power supply for external devices On the right corner of each terminal block of the relay switches, WindPro console provides a DC24V power output for the external device. To connect an external device to the power supply, follow these steps: 1.
1. Go to SETTINGS > DATA 2. Tap LOGGING, then tap CONFIRM to stop the logging function Note: Once Logging is turned off, the WindPro console will no longer record any new data until the function is turned back on or the system is restarted.
Data export To export the logged file from the WindPro console, please install the Data Export Software “ ScarletWind” on Windows PC. 1. Download and unzip “ScarletWind.zip” file from Scarlet’s website. 2. Connect the WindPro console to PC via USB cable 3.
2. Tap the WindSmart icon to launch the app. 3. Tap the dropdown on the top left corner to select a device to pair 4. Select your WindPro console from the list of available devices, and then tap Confirm 4-20mA Output WindPro console provides four 4-20mA current loops for transmitting wind speed and wind direction data to external devices.
2. Enter WindPro serial number and License code to activate Scarlet WindPro Web Portal access. Web Portal Connection Scarlet’s WindPro WebPortal allows you to access the wind data remotely. To upload the wind data to the WebPortal, the WindPro Console must be connected to the Internet through Ethernet or Wi-Fi.
Page 29
4. Tap CONFIRM to save the configuration and return to the previous Wi-Fi configuration page, the SSID will be shown under the Wi-Fi CONNECTIVITY if the connection is successfully established. Monitor WindPro Data WindPro Console can continuously upload all measurement data to the WebPortal once the device is connected to Internet. Liveview The Liveview page displays real-time data uploading by WindPro console, users can choose to view data from a one channel or both channels of a specific WindPro.
Page 30
Historical Data (Chart & Table) The Chart & Table page shows historical data uploaded by the WindPro console. Users can choose to display data in chart or table format at this page. Device Management The Device page provides a list of all authorized WindPro consoles, shows connection status and device information.
Safety, Maintenance, & Warranty Operating Environment The operating temperature of the anemometer system is designed to work in an ambient temperature between 0°C to 50°C (32 °F to 122°F) at 20~80%RH. The storage temperature is between -20°C to 60°C (-4°F to 140°F). The instrument can be damaged if stored and operated outside of these temperature ranges.
Page 32
Warranty Conditions This instrument is guaranteed for a one-year limited warranty against material or production defects, in accordance with our general sales conditions. During the warranty period, Scarlet Tech reserves the right to decide either to repair or replace the product.
