Configuration Options

Configurable parameters have a dialog box or a drop-down list. Once a
configuration change has been made on a page, be sure to click on the
Apply button to confirm the new setting. The following table summarizes
the web page configuration buttons.
Button
Apply
Cancel
Help
Notes:

Panel Display

The web agent displays an image of the switch's ports. The port will turn
green when the corresponding front-panel port is in connection with
another device. To show the port number, place mouse pointer onto the
intended port.
N

Table 5-1 Web Page Configuration Buttons

Action
Sets specified values to the system.
Discards all changes and restores current values.
Links directly to web help.
To ensure proper screen refresh, be sure that Internet Explorer
is configured as follows: Under the menu "Tools / Internet
Options / General / Temporary Internet Files / Settings," the
setting for item "Check for newer versions of stored pages"
should be "Every visit to the page."

Figure 5-2 Front Panel Indicators

AVIGATING THE
W B
EB ROWSER
I
NTERFACE
5-3
