FireWire 800 CardBus DV-Kit
Quick Installation Guide
Introducing the FireWire 800 DV-Kit
The FireWire 800 Cardbus DV-Kit is designed to add
FireWire 800 (1394b) and 1394a (6-pin) interfaces to your
notebook computer. For your convenience, one FireWire
(1394a) 6-pin/4-pin DV cable is included for connecting
DV camcorders and other 1394 devices using 4-pin
connector. Ulead VideoStudio video editing software is
also included for producing greeting cards, video
e-mails, or home videos complete with attractive titles,
effects, and background music.
Features and Benefits
Provides 2 FireWire 800 (9-pin) and 1 FireWire 400
•
(6-pin) ports for multiple device connections
Supports data transfer rates of 100, 200, 400 and
•
800Mbps
Supports hot-swapping and Plug-n-Play connection
•
of peripheral devices
Works with FireWire 800 (1394b) and 1394a devices
•
including DV camcorders, CD-RW/DVD-ROM
drives, portable hard disks, digital cameras and
other audio/video devices
System Requirements
Pentium or equivalent notebook PC with an available
•
PC Card slot
Windows 98SE/ME/2000/XP/Server 2003
•
04-0324B
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NN-PC8312-S2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG NN-PC8312-S2

Summary of Contents for SIIG NN-PC8312-S2

  • Page 1 FireWire 800 CardBus DV-Kit Quick Installation Guide Introducing the FireWire 800 DV-Kit The FireWire 800 Cardbus DV-Kit is designed to add FireWire 800 (1394b) and 1394a (6-pin) interfaces to your notebook computer. For your convenience, one FireWire (1394a) 6-pin/4-pin DV cable is included for connecting DV camcorders and other 1394 devices using 4-pin connector.

  • Page 2: Package Contents

    However, non-powered 1394 devices require this optional power adapter to work. The power adapter can be purchased at SIIG's online store. Power Adapter Jack* (optional) FireWire 800 (9-pin) Figure 1.

  • Page 3: Hardware Installation

    Power off your notebook computer and any other connected peripheral devices. Insert the PC Card into the CardBus Type II slot of your notebook computer with its 68-pin connector facing the slot. Make sure it is inserted all the way in for a solid connection.

  • Page 4: Software Installation

    Software Installation This section provides information on how to install the FireWire 800 CardBus DV-Kit software. Windows Driver Installation Windows 98SE At the Add New Hardware Wizard, click Next. Select Search for the best driver for your device (Recommended), then click Next.
  • Page 5 Double click IEEE 1394 Bus host controller, then double click Texas Instruments OHCI Compliant IEEE 1394 Host Controller. Click the Driver tab, then Update driver button. At the Upgrade Device Driver Wizard window, click Next. Select Search for a suitable driver for my device, then click Next.
  • Page 6 Select OHCI IEEE 1394b Host Controller, then click Next. Click Continue Anyway. thoroughly tested in Windows for stability. 10. Click Finish. Restart Windows to complete the installation. To Verify Windows Installation Check Device Manager to verify successful installation. Windows 98SE/ME: From the main desktop, right click My Computer, then click Properties.

  • Page 7: Connecting A Dv Camcorder

    Ulead VideoStudio software installation: The FireWire 800 CardBus DV-Kit includes Ulead VideoStudio digital video editing software for producing home videos complete with attractive titles, transitions and sounds. Insert the Ulead VideoStudio DV software CD. Auto- run should start automatically. If not, click Start, Run, type in X:\Autorun.exe, then click OK.
  • Page 8 To verify successful DV Camcorder setup Check Device Manager to verify successful driver installation. Windows 98SE/ME: From the main desktop, right click My Computer, then click Properties. Click Device Manager tab. Windows 2000/XP/Server 2003: Right click My Computer, Manager. Double click Imaging Device(s), and Microsoft DV Camera and VCR or DV Camcorder should be displayed.

  • Page 9: Technical Support And Warranty

    SIIG will refuse to accept any shipping package, and will not be responsible for a product returned without an RMA number posted on the outside of the shipping carton. You are responsible for the cost of shipping the product to SIIG • at the following address: SIIG, Inc.
  • Page 10 Fremont, CA 94538-3152 FireWire 800 CardBus DV-Kit is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation.
