- THIS WALL MOUNT CABINET IS FOR THE STORAGE OF COMPONENTS
ONLY AND IS NOT INTENDED TO HAVE A TV PLACED/STORED ON IT.
- Please follow these assembly instructions as it will save you time, make
assembly easier and prevent possible damage to your new unit.
- We strongly recommend that the unit is assembled on a soft surface such
as carpet or blanket.
- Correct assembly / installation is your responsibility.
- Depending on your wall construction, Brick or Stud. The installation
method wil vary. Please follow the appropriate instructions for your
Particular circumstance.
- Maximum weight capacity of this unit is 20 kg.
- When moving this furniture item, always carry the unit. Dragging or
sliding the unit could damage the unit and the floor surface.
Assembly Instruction Manual
MODEL NO.: AIR1500 / AIR1800
Advertisement
Table of Contents
Related Manuals for Criterion AIR1500
Summary of Contents for Criterion AIR1500
- Page 1 Assembly Instruction Manual MODEL NO.: AIR1500 / AIR1800 - THIS WALL MOUNT CABINET IS FOR THE STORAGE OF COMPONENTS ONLY AND IS NOT INTENDED TO HAVE A TV PLACED/STORED ON IT. - Please follow these assembly instructions as it will save you time, make assembly easier and prevent possible damage to your new unit.
- Page 2 As all installation environments are different you may not have all the necessary installation hardware provided in the hardware pack supplied with this unit. If you require further fixings please visit your local hardware store and purchase other required fixings. The fixings provided in this pack are for a basic install only.
- Page 3 The following Instructions are provided as a guide for installing this Wall Cabinet WE RECOMMEND THAT A PROFESSIONAL INSTALLS THIS PRODUCT POSITIONING AND MOUNTING YOUR WALL CABINET Decide on the height you would like the top of your new Wall Mount Cabinet to be. Measure 117mm down your wall to mark your first hole location.
- Page 4 OPTON 1 - FOR STUD WALL STUD WALL SAFETY NOTE: The mounting board has fixing holes in place for a standard stud wall. Please usa a stud finder to ensure that you are fixing into the studs. TAKE OFF THE DRAWER Press the runner clip downward at right side and press the runner clip upward at left side to take out the drawer...
- Page 5 LIFTING CABINET ONTO THE WALL SAFETY NOTE: This step must be completed by two persons to ensure the weight of cabinet is evenly distributed across mounting board and eliminate physical injury to individuals. SECURING CABINET TO WALL MOUNT SAFETY NOTE: For the safety of others you must ensure that this cabinet is secured to the wall mount with the provided screws as shown.
- Page 6 Align the runners on both sides of the drawer, push the left drawer into left side of the cabiet, and push the right drawer into right side of the cabinet. Maximum weight capacity of this unit is 20 KGS Maximum weight capacity of this unit is 20 KGS...
- Page 7 SURFACE CARE INSTRUCTIONS A little care and attention will extend the life and good looks of your furniture. Take care when using materials which might spill, or be sharp or abrasive, on the surface of your furniture. Normal Cleaning: For normal cleaning use a soft, dry, clean cloth. Glass Cleaning for Frosted Glass: Do not use glass cleaner or solvent based cleaners on glass that has a frosting effect on it.
- Page 8 2. Subject to Clause 1, the Seller warrants that CRITERION branded products will be free of manufacturing defects and will perform to the Seller’s specifications subject to the following clauses.
