Bergen 180 High gloss doors
Assembly Instructions
Dimensions
Width - 180cm
Depth - 6.7cm
Height - 195.2cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future reference
1
2
1
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
High gloss doors
1
2
1
413/6633 HIGHGLOSS WHITE
417/7537 HIGHGLOSS CASH
413/6633
417/7537
Dimensions
Issue 1 - 27/05/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Heart of House 413/6633
Summary of Contents for Heart of House 413/6633
- Page 1 Depth - 6.7cm Height - 195.2cm carton(s) it was packed in. 413/6633 HIGHGLOSS WHITE 417/7537 HIGHGLOSS CASH Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on •To reduce the components and tools listed on the product, this could cause likelihood of damaging your pages 2 and 3. - Page 3 Components - Panels If you have damaged or missing parts, call the Customer Helpline: 03456 400 800 Please check you have all the panels listed below Cabinet supplied separately 249/4834 248/6921 226/8730 Segment x4 (91.5 x 65cm) P3355 Segment middle x2 (91.5 x 65cm) P3356...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. FK1309 FK1082 FK1236 Screw x 72 Plug, Nylon x 32 Connecting plate x 8 (4x12.5mm)
- Page 5 Assembly Instructions Step 2 3 Segment slide door left Put 8x nylon plug E into the segment 1. Use a small hammer. Repeat this step. Mount door trim U with 3x screws D on segment Note: there should be no gap between doorsegment 1and door trim U.
- Page 6 Assembly Instructions Step 2 3 Segment slide door left Mount 4x connecting plate O, each with 2x screws D on segment 1 and 2x screws D on middle segment 2. Remove protective film from door handle S. Stick 1x brush T onto door handle S by partially Please remove the protective film!
- Page 7 Assembly Instructions Step 3 Place left slide door 2 People are required for step 3a and 3b. Hook the 2x back guide part j into the plastic guide rail R. Detail. The hook of the back guide part j should be in the front guide of the plastic guide rail R...
- Page 8 Assembly Instructions Step 3 Place left slide door Hook Sliding door connecting platek on metal guide rail Q. Detail. The wheel of the sliding door connecting plate k should be in the front guide of the metal guide rail Q. To lock the door, lock the Sliding door connecting plate k on the guide...
- Page 9 Assembly Instructions Step 4 Step 4 3 Segment slide door right 3 Segment slide door right Put 8x nylo Put 8x nylon plug E the segment 1. into Use a small hammer. the segment 3. Repeat this step. Use a small hammer. Repeat this step.
- Page 10 Assembly Instructions Step 4 Step 4 3 Segment slide door right Mount 4x connecting plate O, each with 2x screws D on segment 3 and 2x screws D on middle segment 4. Please remove Remove protective film the protective film! from door handle S.
- Page 11 Assembly Instructions Step 5 Place right slide door Hook the 2x front guide part i into the plastic guide rail R. Detail. The hook of the rear guide part i should be in the front guide of the plastic guide rail R...
- Page 12 Assembly Instructions Step 5 Place right slide door Hook the sliding door connecting bracketl on metal guide rail Q. Detail. The wheel of the sliding door connecting bracket l should be in the rear guide of the metal guide rail Q. To lock the door, lock the sliding door connecting bracket l on the...
