osaka
abingdon
23465758
4124566
dimensions
width: 40,0 cm
width: 101.2 cm
depth: 40,0 cm
depth: 40.0 cm
height 59,6 cm
height: 76.0 cm
assembly instructions -
if you need help or have damaged or missing parts, call the argos customer helpline: 03456 400 800
350812-01
please keep for future reference
issue 1 - 08-06-2015
Advertisement
Related Manuals for Heart of House abingdon 4124566
Summary of Contents for Heart of House abingdon 4124566
- Page 1 osaka abingdon 23465758 4124566 dimensions width: 40,0 cm width: 101.2 cm depth: 40,0 cm depth: 40.0 cm height 59,6 cm height: 76.0 cm assembly instructions - please keep for future reference if you need help or have damaged or missing parts, call the argos customer helpline: 03456 400 800 issue 1 - 08-06-2015 350812-01...
- Page 2 ! safety and care advice important - please read these instructions fully before starting assembly • assembly should be carried • make sure you have enough out by a competent adult space to layout the parts only. before starting. • check you have all the •...
- Page 3 components - panels if you have damaged or missing components, call the argos customer helpline: 03456 400 800 please check you have all the panels listed below (101,2 cm x 40 cm) divider (11,9 cm x 30,4 cm) side, right (15 cm x 30,6 cm) side, left (15 cm x 30,6 cm)
-
Page 4: Tools Required
components - fittings please check you have all the panels listed below note: the quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. ø7.8 x 40mm wooden dowel x ø3.5 x 35mm screw x ø3.5 x 15mm screw x ø3 x 12mm screw x... - Page 5 assembly instructions step 1 assembly of the dressing table. step 1.1 knock the dowels ø7.8 x 40mm wooden dowel x into the holes indicated on the sides and the dividers using a small hammer. step 1.2 screw the bolts into ø5 x 11, cc34mm bolt x 8 the holes indicated on the posts...
- Page 6 assembly instructions step 1.4 screw the bolts into ø5 x 11, cc34mm bolt x 6 the holes indicated on the sides step 1.5 fix the drawer runners 300mm drawer runner, left, side x 300mm drawer runner, right, side x to the sides using screws through the holes ø5.8 x 19mm Screw x...
- Page 7 assembly instructions step 1.7 screw the bolts into ø5 x 11, cc34mm bolt x 8 the holes indicated on the step 1.8 place the dividers ø15 x 10.5mm cam x 4 onto the top push cams into the holes indicated on the dividers , arrows pointing towards the...
- Page 8 assembly instructions step 1.11 place the sides ø15 x 10.5mm cam x 4 onto the top push cams into the holes indicated on the sides , arrows pointing towards the top turn the cams to the right to fix the top step 1.12 fix the back rail ø5 x 38mm screw x...
- Page 9 assembly instructions step 2 assembly of the drawers. step 2.1 fix the drawer sides ø3.5 x 35mm screw x to the drawer back as shown, using screws step 2.2 knock the dowels ø7.8 x 40mm wooden dowel x into the holes indicated on the drawer sides using a smal hammer.
- Page 10 assembly instructions step 2.5 push the drawer fronts ø15 x 10.5mm cam x 6 onto the drawer sides place cams into the holes indicated, arrow pointing towards the fronts. turn the cams to the right to fix the fronts. step 2.6 important! back fitting w.
- Page 11 assembly instructions step 2.8 fix the metal handles 54mm handle x m4 x 20mm screw x to the drawer front using screws step 2.9 slide the drawers onto the runners and into the dressing table. 350812-11...
- Page 12 assembly instructions step 3 assembly of the stool. step 3.1 knock the dowels ø7.8 x 40mm wooden dowel x ø3.5 x 15mm screw x into the holes indicated on the rails using a small hammer. angle 23 x 23 x 24mm x 4 fix the angles to the rails...
- Page 13 assembly instructions step 3.4 place the posts ø35mm bracket x 4 m6 x 10mm nut x 4 onto the rail push the brackets , the washers and the nuts ø6 / ø11mm washer x 4 10/13mm wrench x 1 into the holes indicated on the rails and onto the threaded rods...
- Page 14 A Guide to Wall Mounting & Fixings IMPORTANT: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualified tradesperson if you are unsure. HINTS: 1) General Rule Always use a larger screw and wall plug if you are not sure.
