Bergen 180
Assembly Instructions
Dimensions
249/4834 OAK
Width - 180cm
248/6921 WAL
226/8730 WHT
Depth - 59.5cm
248/7937 OAK doors
247/1651 WAL doors
Height - 199.8cm
248/8015 WAL FOIL MIRROR
248/3591 OAK FOIL MIRROR
249/6265 MIRROR
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928
For any other queries please contact the Customer Helpline on: 0345 640 2020
- Please keep for future reference
Doors foil/foil
Doors foil/mirror
Mirror doors
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
249/4834
248/6921
226/8730
Cabinet
248/7937
247/1651
248/3591
248/8015
249/6265
Issue 1 - 03/06/15
Advertisement
Related Manuals for Heart of House Bergen 180
Summary of Contents for Heart of House Bergen 180
- Page 1 Bergen 180 Assembly Instructions 249/4834 - Please keep for future reference 248/6921 226/8730 Cabinet 248/7937 247/1651 Doors foil/foil 248/3591 248/8015 Doors foil/mirror 249/6265 Mirror doors Dimensions Tip : To prevent damage, 249/4834 OAK Width - 180cm 248/6921 WAL we recommend that you 226/8730 WHT Depth - 59.5cm...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on •To reduce the components and tools listed on the product, this could cause likelihood of damaging your pages 2 and 3. - Page 3 Components - Panels For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the panels listed below Cabinet Right side Upright Foldy back x2 Left side (199.8 x 52.9cm) (199.8 x 55.8cm) (190.3 x 49cm) (193 x 89cm) P2883 P2882...
- Page 4 Components - Fittings For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
-
Page 5: Tools Required
Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. ZF9997I ZF9997K ZF9997L Not used until door assembly Screw x 2 Screw x 9... - Page 6 Assembly Instructions Step 1 Cabinet assembly Screw 9 locking screws B into the holes on back of the left side 1. Mount hanger rail support K, fasten with 1 screw D. Screw D into the board between two predrilled holes. Mount tapping block for Finished guide rail f with two...
- Page 7 Assembly Instructions Step 1 Cabinet assembly Insert 6x small locking nuts I into the top 5. Make sure the ‘arrow’ on I is pointing towards the Finished hole in the edge of the top front edge Insert 6x small locking nuts I into the bottom 6.
- Page 8 Assembly Instructions Step 1 Cabinet assembly Attach top 5 with 2x confirmat screws A to the upright 3. Use allenkey Attach bottom 6 with 2x confirmat srews A to the Finished upright 3 front edge Plain chipboard Attach 2x the shelf 8 to the upright 3 with 3x double locking screws G.
- Page 9 Assembly Instructions Step 1 Cabinet assembly Attach 2x the plinth 7 between the left site 1 and the right side 2. Note: that the finished side is properly placed. Attach the right side 2 with 9x double locking screws G on the top 5, shelf 8 and the bottom 6.
- Page 10 Assembly Instructions Step 1 Cabinet assembly Position L-Bracket M onto top 5 , by using 1x screw C. Position metal guide rail Q onto top 5 , fix with 7x screws C. Attach 2x end stop g on the end of the guide rail Q with 2x screws d.
- Page 11 Assembly Instructions Step 1 Place cabinet Use to 1x wall plug W to mount L-Bracket M on the wall, please see last page for more information. Before adjusting the doors, use a spirit level to check if the base of this unitis level front-to-back and side-to-side in the three positions shown.
-
Page 12: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit. - Page 13 Bergen 180 Foil doors Assembly Instructions 248/7937 - Please keep for future reference 247/1651 413/1487 Foil doors Dimensions Dimensions Tip : To prevent damage, we recommend that you Width - 180cm build your unit on the Depth - 6.7cm 413/1487 WHI FOIL Height - 195.2cm...
- Page 14 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on •To reduce the components and tools listed on the product, this could cause likelihood of damaging your pages 2 and 3.
- Page 15 Components - Panels For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the panels listed below Cabinet supplied separately 249/4834 248/6921 226/8730 Segment x4 (91.5 x 65cm) P3334 Segment middle x2 (91.5 x 65cm) P3270...
- Page 16 Components - Fittings For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 17 Assembly Instructions Step 2 3 Segment slide door left Put 8x nylon plug E into the segment 1. Use a small hammer. Repeat this step. Mount door trim U with 3x screws D on segment Note: there should be no gap between doorsegment 1and door trim U.
- Page 18 Assembly Instructions Step 2 3 Segment slide door left Mount 4x connecting plate O, each with 2x screws D on segment 1 and 2x screws D on middle segment 2. Remove protective film from door handle S. Stick 1x brush T onto door handle S by partially Please remove the protective film!
- Page 19 Assembly Instructions Step 3 Place left slide door 2 People are required for step 3a and 3b. Hook the 2x back guide part j into the plastic guide rail R. Detail. The hook of the back guide part j should be in the front guide of the plastic guide rail R...
- Page 20 Assembly Instructions Step 3 Place left slide door Hook Sliding door connecting platek on metal guide rail Q. Detail. The wheel of the sliding door connecting plate k should be in the front guide of the metal guide rail Q. To lock the door, lock the Sliding door connecting plate k on the guide...
- Page 21 Assembly Instructions Step 4 Step 4 3 Segment slide door right 3 Segment slide door right Put 8x nylo Put 8x nylon plug E the segment 1. into Use a small hammer. the segment 3. Repeat this step. Use a small hammer. Repeat this step.
- Page 22 Assembly Instructions Step 4 Step 4 3 Segment slide door right Mount 4x connecting plate O, each with 2x screws D on segment 3 and 2x screws D on middle segment 4. Please remove Remove protective film the protective film! from door handle S.
- Page 23 Assembly Instructions Step 5 Place right slide door Hook the 2x front guide part i into the plastic guide rail R. Detail. The hook of the rear guide part i should be in the front guide of the plastic guide rail R...
- Page 24 Assembly Instructions Step 5 Place right slide door Hook the sliding door connecting bracketl on metal guide rail Q. Detail. The wheel of the sliding door connecting bracket l should be in the rear guide of the metal guide rail Q. To lock the door, lock the sliding door connecting bracket l on the...
