EN Installation / User Instructions / Warranty
FR Instructions de montage / Mode d'emploi / Garantie
ES Instrucciones de montaje / Manejo / Garantía
Talis C
14127xx1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Talis C 14127 1 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Hans Grohe Talis C 14127 1 Series

Summary of Contents for Hans Grohe Talis C 14127 1 Series

  • Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Talis C 14127xx1...

  • Page 2: Technical Information

    English Technical Information Recommended water pressure 15 - 75 PSI Max. water pressure 145 PSI Recommended hot water temp. 120° - 140° F* Max. hot water temp 176°F* Flow rate 1.3 GPM Hole size in mounting surface 1⅜" Max. depth of mounting surface 1⅝" 4" *Please know and follow all applicable local plumbing codes when setting the temperature on the water heater. 2⅛" Installation Considerations 1¼" • For best results, Hansgrohe recommends that this unit be installed by a licensed, professional plumber. • Please read over these instructions thoroughly before beginning installation. Make sure that you have all tools and supplies needed to complete the installation.

  • Page 3: Données Techniques

    Français Español Données techniques Datos tecnicos Pression d’eau recommandée 15 - 75 PSI Presión recomendada en servicio 15 - 75 PSI Pression d’eau maximum 145 PSI Presión en servicio max. 145 PSI Température recommandée 120° - 140° F* Temperatura recomendada del 120� - 140� F* d'eau chaude agua caliente Température maximum d'eau chaude 176°F* Temperatura del agua caliente max. 176�F* Capacité nominale 1.3 GPM Caudal máximo 1.3 GPM Dimension du trou dans la surface 1⅜ po Tamaño del orificio en la superficie de montaje 1⅜" de montage Profundidad máxima de la 1⅝" Profondeur maximale de la surface 1⅝ po superficie de montaje de montage * Vous devez connaître et respecter tous les codes de *Debe conocer y cumplir todos los códigos locales plomberie locaux applicables pour le réglage de la aplicables para ajustar la temperatura del calentador température du chauffe-eau.

  • Page 4: Installation

    English Installation Install the pull rod. Place the faucet and sealing ring on the mounting surface. Install the fiber washer, metal washer and mount- ing nut. Tighten the mounting nut by hand.

  • Page 5: Instalación

    Français Español Installation Instalación Installez la tirette. Instale el tirador. Placez le robinet et l’anneau d’étanchéité sur la Coloque el grifo y el aro de sellado sobre la surface de montage. superficie de montaje. Installez la rondelle en fibre, la rondelle métal- Instale la arandela de fibra, la arandela metálica lique et l’écrou de montage. y la tuerca de montaje. Serrez l’écrou de montage à la main. Apriete la tuerca de montaje con la mano.
  • Page 6 English Tighten the tensioning screws using a screwdriver. Install the adapters on the stops. Install the filters. 10 mm 19 mm Failure to install the filters may result in unsatisfactory operation of the faucet. Connect the hot and cold supply hoses to the adapters. Use two wrenches as shown. Do not allow the hoses to twist.
  • Page 7 Français Español Serrez les vis de pression à l’aide d’un tournevis. Apriete los tornillos tensores con un destornillador. Instale los adaptadores sobre los topes. Installez les adaptateurs sur les butées d’arrêt. Instale los filtros. Installez les filtres. Si no se instalan los filtros, el Si ces filtres ne sont pas installés, il grifo puede funcionar en forma est possible que le robinet n’offre insatisfactoria. pas un rendement satisfaisant. Conecte las mangueras de suministro de agua Connectez les tuyaux d’arrivée d’eau chaude et caliente y fría a los adaptadores.

  • Page 8: Installation / Installation / Instalación

    Installation / Installation / Instalación Petroleum-based plumbers Le mastic de pétrole-basé peut Masilla de petróleo-basó puede dañar la superficie de putty may damage some sink endommager la surface de materials. Please refer to the quelque baignoires. S'il vous algún bañeras. Consulte por plaît consulter le fabricant du favor al fabricante del bañera instructions included with the con respecto a selladores sink regarding acceptable baignoire quant aux enduits d'étanchéité acceptables. aceptables. sealants.
  • Page 9 Set the High Temperature Limit Stop (optional) / Réglage de la butée limite d’eau chaude (en option) / Ajuste el tope de límite de alta temperatura (opcional) 60° C 10° C 3 Bar 140° F 50° F 44 PSI...
  • Page 10 Replacement Parts / Pièces détachées / Repuestos 14191xx0 98863xx0 96338000 98864000 95140000 97685000 98865000 98866000 96657xx0 88509000 13961000 95141000 xx = Colors / Couleurs / Acabados 00 = Chrome 62 = Oil Rub Bronze 82 = Brushed Nickel 83 = Polished Nickel...
  • Page 11 User Instructions / Instructions de service / Manejo ouvert fermé abierto cerrar cold chaud froid caliente frío 10 mm 19 mm If the flow of water diminishes over Si le débit d’eau diminue avec le Si el caudal de agua disminuye time, remove the hose filters. temps, retirez les filtres de tuyau. con el tiempo, retire los filtros de la manguera. Flush the filters with clear water. Rincez les filtres à l’eau claire. Lave los filtros con agua limpia. Install the filters. Installez les filtres. Instale los filtros.
  • Page 12 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it. For best results: • Prevent the buildup of mineral scale and /or soap residue by cleaning your Hansgrohe product(s) when needed. • Select a cleaning agent specifically intended for the type of product. • Do not use these types of cleaners as they will cause damage to your Hansgrohe product: Any cleaning agent containing hydrochloric acid, formic acid, lye, or acetic acid.  Abrasive cleaning powders, pads, or brushes.  Steam cleaners.  “No rinse” cleaning agents.  • Always follow the instructions provided by the manufacturer of the cleaning agent. • Do not mix cleaning agents, unless directed by the manufacturer. • Do not spray cleaners directly onto the product as drops could enter openings and gaps and cause damage. When using spray cleaners, spray the cleaner onto a soft cloth or sponge. • Always rinse your Hansgrohe product thoroughly with clear water and polish dry with a soft cloth after cleaning. Important • Residue from soaps and shampoos can cause damage. Rinse the product with clean water after each use.

  • Page 13: Indications Importantes

    • Après le nettoyage rincez avec suffisamment d’eau claire pour éliminer les restes de produits attachés. • L’utilisation d’appareil de nettoyage à vapeur n’est pas autorisée, car les températures importantes peuvent détériorer les produits. Indications importantes • Les produits pour le corps comme les savons liquides, les shampooings ou les gels de douche peuvent causer des détériorations. • Ici aussi on doit: Après l’utilisation rincer soigneusement les restes avec de l’eau. Conseil de nettoyage • Les deteriorations imputables à un mauvais entretien ne peuvent être pris en considération par notre garantie. • Par l’action d’un nettoyant sur les revêtements déjà endommagé il se produit une aggravation des dégâts. Recomendación de limpieza para los productos de Hansgrohe Hoy en día, las griferías de baño y de cocina así como duchas modernas se componen de materiales muy distintos para satisfacer las exigencias del mercado respecto al diseño y la funcionalidad. Para evitar daños y reclamaciones hay que tener en cuenta ciertos aspectos tanto en el uso como en su limpieza.

  • Page 14: Limited Consumer Warranty

    Limited Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products that are purchased by a consumer in the United States or Canada after March 1, 1996, and installed in either the United States or in Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original purchaser only. This warranty is non-transferable. WHAT IS COVERED BY THE WARRANTY The warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product against defects in material or workmanship as follows: Hansgrohe will replace at no charge for parts only or, at its option, replace any product or part of the product that proves defective because of improper workmanship and/or material, under normal installation, use, service and maintenance. If Hansgrohe is unable to provide a replacement and repair is not practical or cannot be made in timely fashion, Hansgrohe may elect to refund the purchase price in exchange for the return of the product. LENGTH OF WARRANTY Replacement or repaired parts of products will be covered for the term of this warranty, as stated in the following two sentences. If you are a consumer who purchased the product for use primarily for personal, family or household purposes, this warranty extends for as long as you own the product and the home in which the product is originally installed. If you purchased the product for use primarily for any other purpose, including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect to Hansgrohe & Commercial products, and (ii) for 5 years, with respect to Axor products. THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship.

  • Page 15: Exclusions And Limitations

    Exclusions and Limitations REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES,REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER.HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
  • Page 16 Hansgrohe, Inc. • 1490 Bluegrass Lakes Parkway • Alpharetta, GA 30004 Tel. 800-334-0455 • Fax 770-360-9887 www.hansgrohe-usa.com...
