Cooper Lighting Recessed Direct T5HO Specification

DESCRIPTION
A return to simplicity, elegance and minimalism ... Slender lines of
unbroken light set in an architectural environment are the essence of
Straight and Narrow. This series accommodates most architectural lighting
design applications.
Features:
- Straight and Narrow embodies Neo-Ray's critical attention to architectural
detail as well as lighting performance.
- Continuous and unbroken light
- Extruded aluminum housing offers precise in-line appearance
- Runs are provided to nearest foot
SPECIFICATION FEATURES
Construction
Extruded aluminum housing.
Nominal 3', 4', 6' or 8' illuminated
sections.
Shielding
Trimless, snap-in, white, high
transmission, acrylic diffuser.
Snap-in high performance semi-
specular or white parabolic louver.
4"
4-5/8"
ORDERING INFORMATION
S A M P L E N U M B E R : S 2 3 D R - 1 T 5 - E T G 4 D - 1 E B - S I - E M - G L R - S 2 2 R - 2 M R 1 6 W 2 0 F 1
23 D
Series Light Mounting
Output R =Recessed
23 = Straight &
D =Direct RDL =Recessed
Narrow
with Downlight
Number of Lamps
(not included)
1=1 Lamp
2=2 Lamps
1 Required voltage information.
• For some electronic, dimming and EM battery pack ballast combinations,
fixture has space limitation (consult factory).
• Due to various constraints, some options may not be combined with others.
Please consult your Cooper Lighting representative for availability.
Electrical
120, 277, 347 or Universal Voltage
electronic ballast. Fixtures and
electrical components certified to
UL and CUL standards.
FIXTURE HUNG BY RODS,
RODS NOT BY NEO-RAY
4"
Lamp Type
Length
T5
3=3 ft
T5HO
4=4 ft
6=6 ft
8=8 ft
XX =Continuous Runs
Ceiling Type
ETG=15/16" exposed T-grid
STG=Screw Slot T-grid
SR=Sheet Rock
FSR=Sheet Rock Flangeless
FTG=9/16" exposed T-grid
Specifications and Dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Finish
Durable, low gloss, white, powder
coated acrylic. Optional custom
finish.
Mounting
Recessed:
(ETF) Exposed T-grid 15/16"
(STG) Screw Slot Grid 9/16"
(SR) Sheet Rock
4"
4-5/8"
Section
Switching
D =Individual
Options
I =Intermediate
SI=Single
B =Beginning of Run
Switching
E = End of Run
DU=Dual
Switching
Voltage
1=120V
2=277V
3=347V
U =Universal
1
Ballast
EB =Electronic
Ballast (standard)
DB =Dimming
Ballast
NEO-RAY
FIXTURE HUNG BY RODS,
RODS NOT BY NEO-RAY
4"
Fusing
Emergency
GLR
EM= Emergency
Downlight Options
Pack (consult GMF
2MR16W20=
factory) 1
Halogen MR16 lamp
20W (fixed)
2MR16W20A=
Louver Options Halogen MR16 lamp
S22R=Regressed white 20W (adjustable)
acrylic diffuser
S90=High performance
Optional Accessory
louver
(Downlight only)
S90W=White louver
F1=Hex Cell Louver
S90P=High performance
F2=Prismatic Spread Lens
louver with acrylic overlay
F3=Linear Spread Lens
S90WP=White louver with
F4=Milk White Lens
acrylic overlay
F5=Red Color Filter
S93=Satin white lens
F6=Blue Color Filter
05/24/2007 4:11:37 PM
Type
Date
Straight &
Narrow
23-DR
T5 OR T5HO
RECESSED
DIRECT
2
ADN070413
