Cooper Lighting Shaper 600 Specification Sheet

D E S C R I P T I O N
600 Luminous Square Vanity Luminaire. ADA complaint.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Painted or plated cold-rolled
steel, brass, copper or aluminum
end caps and an aluminum body
with a extruded matte white
acrylic diffuser.
F i n i s h
Standard: Natural Aluminum
(NA). [Sustainable Design]
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Satin Stainless Steel
(SSS), Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Polished Brass (PB),
Satin Copper (SCP), Polished
Copper (PCP), Satin Nickel (SN),
Polished Nickel (PN), Lacquered
Satin Chrome (SCL), Lacquered
Satin Nickel (SNL) or Custom
Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
O R D E R I N G I N F O R M AT I O N
Sample Number: 600-24-T5/2/14-277V-PCP
Series Size Lamp
600 Luminous = 24" T5/2/14
Square
36" T5/2/21
Vanity
Notes:
1
Available in 24".
2
Available in 36".
3
Consult the factory for available options.
4
Supplied by others.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
L a m p / S o cke t
24": Two (2) 14W T5 linear
fluorescent lamps.
36": Two (2) 21W T5 linear
fluorescent lamps. Fluorescent
socket injection molded plastic.
Lamps furnished by others.
I n s t a l l a t i o n
Supplied with a universal
mounting back for a standard 3"
plaster ring or switch-box. 36"
Luminaire has additional
mounting holes to ensure secure
attachment. Horizontal or vertical
mount.
O p t i o n s
Dimming Ballast - Contact
factory for ballast options (DM),
Voltage Finish
1
120V
Standard
2
NA Natural Aluminum =
277V
347V
Premium
CC Custom Color =
MW Matte White =
PB Polished Brass =
PC Polished Chrome =
PCP Polished Copper =
PN Polished Nickel =
SAL Lacquered Satin Aluminum =
SB Satin Brass =
SC Satin Chrome =
SCP Satin Copper =
SCL Lacquered Satin Chrome =
SN Satin Nickel =
SNL Lacquered Satin Nickel =
SSS Satin Stainless Steel =
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Remote Emergency Battery -
Supplied by others (REM), Damp
Location (DL): All Painted
Finishes, Lacquered Satin
Chrome (SCL) and Lacquered
Satin Nickel (SNL) finishes only.
Energy Star Rating - Consult
factory.
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
DL Damp Location =
DM CFL Dimming =
3
Ballast
REM Remote =
Emergency
4
Battery
shaperlighting.com
Type
Date
600 SERIES
I n t e r i o r W a l l L u m i n a i r e
L u m i n o u s S q u a r e Va n i t y
AMERICAN DISABILITIES
ACT (ADA)
Shaper offers a large selection of ADA
interior and exterior wall luminaires.
ADA requires all fixtures below 68" to
have a maximum projection of 4".
ENERGY
STAR
Shaper now offers a wide variety of
fixtures that can be provided with an
Energy Star rating.
QUICK
SHIP (QS)
Shaper's Quick Ship program features
over thirty-four fixtures with finish
options such as Satin Chrome, Natural
Aluminum and Satin Brass and a wide
variety of lamp selections. All products
ship in five days from receipt of order.
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
Refer to the Icon Legend
Link on shaperlighting.com.
