R-Tech TIG160FPP Operation Instructions Manual page 4

The R-Tech TIG160FPP is a member of our field acclaimed family of welding products.
1. Inverter power source – more efficient to operate, provides smoother weld characteristics.
2. Full Featured Pulse welding in DC TIG welding mode
3. HF Arc start – Easy arc striking and prolonged tungsten life
4. Slope up / slope down
5. Remote foot pedal option
6. Easy adjustment of welding parameters
7. Industrial 35% Duty cycle at 160 Amps @ 40C
Recommended Processes
The R-Tech TIG160FPP is recommended for the TIG welding processes within its output
capacity of 160 Amps
Welding Capability – Duty Cycle
The R-Tech TIG160FPP is rated at 160 Amps at 35% duty cycle on a ten-minute basis. If the
duty cycle is exceeded a thermal protector will shut machine off until the machine cools.
Technical Specifications
Model No. R-Tech TIG160FPP
Input
MMA No-load Voltage
Current Range
Rated Output Current
Arc Force
DC TIG No-load Voltage
Current Range
Rated Output Current
Duty Cycle TIG
Up-Slope Time
Down-Slope Time
Pulse Frequency Range
Pulse Width Range
Pulse Amperage Range
Gas Post Flow Time
Gas Pre-Flow Time
Arc Starting Mode
Gross Weight 16KG
Insulation IP23S
4
Introduction
Premium features include: -
220V / 240V AC 50/60Hz 13A
60V – 80V
10A – 130A
130A @ 35%
1 - 100%
60V – 80V
5A – 160A
160A
35% @160A
0-25 Seconds
0-10 Seconds
0.2Hz – 250Hz
10% - 90%
5% - 95% of base amps
0 - 25 Seconds
0 - 5 Seconds
High Frequency / Lift
425 x 195 x 310mm
