F9D
Packing List
After opening the package, please confirm whether the driving recorder is in
good condition and the accessories are complete.
1) Dash Cam Main Unit*1
3) Power Cable*1
5) Tie*8
7) Wire Controller*1
9) Memory Card x 1(Optional)
"Optional" mean it is not a standard configuration. Please refer to the product description on the
platform you purchased!
Product Appearance Diagram
Type-C Interface
(Can be connected to a computer
and used as a USB flash drive)
TF Card Slot
Screw Holes
Dash Cam
UserManual V1.9
2) Camera *2
4) USB Test Cable*1
6) Bracket*1
8)GPS Module*1(Optional)
10)Tire Pressure Sensors x 2 (Optional)
Bracket Hole
Display Screen
-1-
Power Cable Interface
Wire Controller Interface
Camera1 Interface
Camera2 Interface
Advertisement
Related Manuals for VSYSTO F9D
Summary of Contents for VSYSTO F9D
- Page 1 Dash Cam UserManual V1.9 Packing List After opening the package, please confirm whether the driving recorder is in good condition and the accessories are complete. 1) Dash Cam Main Unit*1 2) Camera *2 3) Power Cable*1 4) USB Test Cable*1 5) Tie*8 6) Bracket*1 8)GPS Module*1(Optional)
-
Page 2: How To Use
How to use 1.Quick Test and Installation Please refer to the "Quick Installation Guide". 2.Insert the Memory Card Insert the memory card into the card slot until you hear "Da". If you want to take out the card, gently press the memory card and slowly release it after hearing "Da". Tips：... - Page 3 Method 1: Scan the corresponding QR code to download the latest APP from software download link of your browser. Method 2: You can search "VSYSTO" on Google Play or APP Store to download and install it. DVR WiFi Default Name: F9_XXXX Default password: 1234567890 Connection Steps:①Turn on the recorder...
-
Page 4: Function Operation
W5T Wire Controller Operating Instructions ◆Function operation UpButton： ①In the front and rear camera split screen mode of the video recording interface, short press the up button to switch to a single full front camera screen.Short press the up button again to switch to a single full rear camera screen.Then Short press the up button again to return to the left and right split screens.camera video long press the up button to switch to the rear camera video file. - Page 5 Images Information and Menu Description 1.After selecting, press [OK] to enter 1. Character description on the display in recording mode: Video Mode. Microphone SupportParkingMonitoring 2.The icon becomes larger to indicate that the function is selected. Recording Atmospheric Pressure Altitude 605HPA Front/Rear Camera Tire pressure...
- Page 6 Auxiliary Display Mode Speed Tire Pressure Display Current speed while driving km/h Tire Pressure TRIP:0 Km °C °C and Temperature 1.Long press the down button of the wire controller 2.Short press the up button again to enter the auxiliary display mode, and the to enter the tire pressure monitoring driving speed is displayed on the first interface interface(optional)
-
Page 7: Camera Bracket
Installation Guide 1.Quick Test 1) Connect the front and rear cameras to the host of the recorder. 2) Find the USB test cable from the accessories and connect the recorder with a 5V 2A power bank or USB charger. After the recorder is turned on, test the function of the recorder. 3) After the test shows that the recorder is normal, you can install it. - Page 8 2.Install Power Cable ACC Power Cable Connection Method: The red wire is connected to the positive pole of the motorcycle battery, the black wire is connected to the negative pole, and the yellow wire is connected to the positive pole of motorcycle key control (12V ACC power source). Tips：...
