ASSEMBLY INSTRUCTIONS
Thorncliff 54" Infrared Media Electric Fireplace
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. – 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this electric fireplace/heater. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing StyleWell!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thorncliff HDFP54-58E and is the answer not in the manual?

Questions and answers

Summary of Contents for StyleWell Thorncliff HDFP54-58E

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this electric fireplace/heater. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
  • Page 2: Table Of Contents

    Table of Contents Table of Contents............2 Hardware Included ..............3 Safety Information ............2 Package Contents ..............4 Maximum Recommended Weight Loads .........2 Assembly ..............5 Warranty ..............2 Care and Maintenance..........23 Pre-Assembly .............. 2 Caring for Wood Furniture ............23 Planning Assembly ..............2 Cleaning the Fireplace Trim ...........23 Tools required ................2...
  • Page 3: Hardware Included

    Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Insert screw 10+1 extra Handle Short wood dowel 4+1 extra Handle bolt Long wood dowel 47+2 extra Shelf support 8+1 extra Cam lock 48+2 extra Rubber bumper 4+1 extra...
  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Heater Right skirting Left upright arm Upper front molding Right upright arm Upper side panel Connector strap Upper partition molding Ember bed Upper partition panel Left log Lower side panel Right log Left lower partition panel Firebox wall panel...
  • Page 5: Assembly

    Assembly Preparing media shelf and base assembly NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. □ Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratches.
  • Page 6 Assembly (continued) Attaching middle crossbar NOTE: Refer to the cam lock assembling guide drawings in this step for further clarification on how to properly install cam locks. Apply this method whenever instructed to install cam locks □ Attach the middle crossbar (Z) to the media shelf (L) by engaging three cam locks (DD). Attaching rear skirting □...
  • Page 7 Assembly (continued) Attaching front skirting □ Align and attach the front skirting (O) to both side skirtings (P and Q) using two cam locks (DD). Installing base □ Using the wood dowels (CC) as a guide, align and attach the previous assembly to the bottom panel (M) by engaging eleven cam locks (DD).
  • Page 8 Assembly (continued) Preparing bottom panel assembly □ Securely screw four cam bolts (EE) into the designated small holes on the top of bottom panel (M) using a Phillips screwdriver. Attaching middle trims □ Glue two short wood dowels (BB) into the inner holes on each middle trim (C1). □...
  • Page 9 Assembly (continued) Gluing wood dowels □ Glue the long wood dowels (CC) into the inner holes on both lower side panels (V) and the lower partition panels (W and X) as shown. Attaching side panels □ Align and attach two lower side panels (V) to the bottom panel (M) by engaging four cam locks (DD). HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 10 Assembly (continued) Attaching lower partition panels □ Using the wood dowels as a guide, firmly press the assembled lower partition panels (W and X) to the bottom panel (M) and fasten them in place with four long flat head screws (HH). Attaching media shelf □...
  • Page 11 Assembly (continued) Screwing cam bolts □ Ask for assistance to stand the previous unit upright, securely screw the cam bolts (EE) into the designated small holes on the media shelf (L) using a Phillips screwdriver. Preparing top panel and upper moldings assembly □...
  • Page 12 Assembly (continued) Gluing wood dowels □ Glue the long wood dowels (CC) into the inner holes on the upper front moldings (R), upper side panels (S) and upper partition panel (U) as shown. Combining upper panels with the moldings □ ttach one upper front molding (R) to one upper side panel (S) by engaging two cam locks (DD) as shown.
  • Page 13 Assembly (continued) Attaching upper side panels and partition panel □ Align and attach the assembled upper side panels (S) and upper partition panel (U) to the media shelf (L) by engaging two cam locks (DD) in each panel. Attaching top panel □...
  • Page 14 Assembly (continued) Fastening middle crossbar □ Using the pilot holes as a guide, attach the small L-bracket (JJ) at the joints where the middle crossbar (Z) meets the partition panels (W and X) with two short flat head screws (FF) per bracket. Installing back panels □...
  • Page 15 Assembly (continued) Installing door hinges and handles □ Extend two door hinges (TT) and rest the hinge cups onto the cutouts of each door (Y). Secure the door hinges (TT) in place by using two nickel screws (SS) in each hinge. □...
  • Page 16 Assembly (continued) Attaching adjustable shelves □ Insert four shelf supports (OO) in the holes at the desired height inside each side compartment. Make sure you place the four shelf supports in the same level to make the shelf level. □ Tilt and rest the adjustable shelves (E1) onto the shelf supports and fasten them in place with the short flat head screws (FF).
  • Page 17 Assembly (continued) Attaching upright arms NOTE: . See BILT for video instructions. Use hand screwdriver, not power driver to assemble fireplace insert □ See figure A: Fasten upper 2 screws (AA) through the upright arm (C) into the heater (A) until tight. □...
  • Page 18 Assembly (continued) Positioning ember bed □ Set the ember bed (E) onto the heater (A) as shown. □ Push ember bed forward against the front flange of heater. □ Position the USB cable as shown below. USB cable Attaching wall panel □...
  • Page 19 Assembly (continued) Connecting ember bed cable to heater □ Fully plug the USB connector of the ember bed (E) into the back port of heater (A). Inserting the glass □ Slide the glass (I) into the inner U-channels on both upright arms (B and C) until the glass sits onto the heater (A). If needed, push top of upright arms in or out to accommodate glass.
  • Page 20 Assembly (continued) Positioning connector strap □ Position top connector strap (D) over the glass (I) and upright arms (B and C). Follow orientation shown below. The bevel edge faces inside the unit. Attaching connector strap □ Fasten connector strap (D) to both upright arms (B and C) using two screws (AA) as show below. Holes must be in line for screw to pass through.
  • Page 21 Assembly (continued) Finishing fireplace insert assembly □ The firebox is now ready for the next assemble step. Installing the fireplace insert □ Lift the fireplace insert carefully into the back of the assembled mantel and center it on the bottom panel in the opening. □...
  • Page 22 Assembly (continued) Installing the acrylic stopper □ Remove the paper backing of acrylic stopper (LL), then properly align the acrylic stopper into the cutout on the acrylic stopper template on the front of the top panel (K). Press down on the acrylic stopper to help adhesion. NOTE: To prevent your TV from tipping, you must install the acrylic TV stopper if you place a flat panel television on the top panel.
  • Page 23: Care And Maintenance

    Care and Maintenance A touch-up pen has been provided to minimize the small nicks or scratches that may occur during assembly or shipping. To clean and care for your furniture: □ Use a soft, clean cloth that will not scratch the surface when dusting. □...
