- Page 1 11.2 DT-E TECHNICAL AND OPERATIONAL DOCUMENTATION INSTALLATION MANUAL, OPERATING MANUAL AND INSTRUCTIONS FOR SAFE USE (Translated from the original manual) Awnings 11.2 Terrace awning SILVER PLUS...
- Page 2 PRODUCT NAME: TERRACE AWNING SILVER PLUS PRODUCT MANUFACTURER’S MARKING: Manufacturer’s name: SELT Sp. z o. o. Manufacturer’s registered office: 45- 449 Opole, ul. Wschodnia 23A Contact details: Tel: +48 77 553 21 00 (secretariat) Fax: +48 77 553 22 00 ...
-
Page 3: Table Of Contents
SILVER PLUS AWNING INSTALLATION –WALL BRACKETS ................11 4.5.2 SILVER PLUS AWNING INSTALLATION – CEILING BRACKETS ................ 16 4.5.3 SILVER PLUS AWNING INSTALLATION - ROOF RAFTER BRACKETS ............... 16 ELECTRIC DRIVE ..............................17 4.6.1 CONNECTION TO ELECTRICAL INSTALLATION ..................... 17 4.6.2... -
Page 4: Introduction
INTRODUCTION SAFETY GUIDELINES FOR THE PRODUCT The product has been manufactured in accordance with the latest technical knowledge in the field of construction and manufacturing and meets the safety requirements in accordance with the following standards. The safe construction of the product was achieved thanks to: Subject European legal basis Polish legal basis... -
Page 5: Terms And Definitions
SELT SP. Z O.O. with a head office in Opole shall hold the copyrights to this documentation. The documentation cannot be used without permission, either partially or as a whole, for any concurrent business activity nor can it be made available to third parties. -
Page 6: Product Technical Information
The optional use of weather automation additionally protects the product against changing weather conditions. PRODUCT SPECIFICATION Products manufactured by SELT Sp. z o. o. have appropriate technical and operational parameters. They have the following features: They provide excellent sun protection for surfaces such as terraces and balconies. -
Page 7: Silver Plus Awning Construction
SILVER PLUS AWNING CONSTRUCTION BRACKET TYPES Wall bracket Ceiling bracket Roof rafter bracket Option with hood DT-E 11.2 SUN PROTECTION SYSTEM – TERRACE AWNING PLUS Edition 8/ March 2022 / EN page 7 / 31... -
Page 8: Transport And Storage Of The Product
COMPLETENESS AND QUALITY CONDITION OF DELIVERY SELT Sp. z o. o. makes every effort to ensure that the goods comply with the order. However, checking the completeness of the product is the responsibility of the Buyer and should take place at the time of its receipt. -
Page 9: Product Installation
This chapter contains general requirements concerning the product installation. Correct assembly is a necessary condition for smooth operation of the product. SELT Sp. o.o. recommends using only professional assembly crews, which guarantee the Purchaser that the conducted installation will be correct. -
Page 10: Preparation For Installation
Allen keys, hammer anchors. INSTALLATION Instructions for assembly, operation and safe use are available after logging in on website www.selt.com DT-E 11.2 SUN PROTECTION SYSTEM – TERRACE AWNING PLUS Edition 8/ March 2022 / EN page 10 / 31... -
Page 11: Silver Plus Awning Installation -Wall Brackets
4.5.1 SILVER PLUS AWNING INSTALLATION –WALL BRACKETS SELT recommends the use of Fischer fixing products - selected depending on the type of substrate. Suggested recommendations for selected substrates: for non-cracked concrete class C20/25 and not higher than C50/60: M10x110 A4 anchors set on injection mortar (Fischer FIS A M10x110 A4 anchors on FIS V resin or an equivalent ... - Page 12 5) Screw the wall bracket in the position as shown in the drawing in the available variants using: the upper and lower holes. Follow the anchor manufacturer's instructions regarding required anchor spacing, preparation and installation method. 6) Based on the first installed bracket 7) Drill holes in marked places.
- Page 13 11) Secure square bar with M8x65 screws and put PVC cover on them. 12) Open the awning slightly. 13) If necessary adjust the arm level by loosening or tightening the internal screw in arm brackets. 14) With spirit level check if the arms close 14) Open the awning completely.
- Page 14 15) To change the tilt angle of the awning use an Allen wrench to loosen 16) With spirit level check if front bar is (increase the tilt angle) or tighten (decrease the tilt angle) adjusting screws (with levelled horizontally. button-heads) of the arm brackets 18) After changing the tilt angle, remember to modify the position of the roller tube support.
- Page 15 19) VERSION WITH HOOD (ONLY WALL MOUNTING OPTION) In order to attach the hood to the awning, please carry out the following steps (in sequence as shown on the drawings below). DT-E 11.2 SUN PROTECTION SYSTEM – TERRACE AWNING PLUS Edition 8/ March 2022 / EN page 15 / 31...
-
Page 16: Silver Plus Awning Installation - Ceiling Brackets
Secure square bar with M8x65 screws and put PVC cover on them. 4.5.3 SILVER PLUS AWNING INSTALLATION - ROOF RAFTER BRACKETS Roof rafter brackets should be installed to roof rafters the closest to awning edge possible (it is recommended to install them at a distance of 20 to 45 cm from the ends of the awning), remaining brackets place in equal intervals. -
Page 17: Electric Drive
The instructions are attached to the product and are also available on the websites of motor manufacturers and on the website: www.selt.com → OUR OFFER → MOTOR, ELECTRIC, EQUIPMENT Environmental conditions with increased risk: environments with increased risk include bathrooms and showers, kitchens, garages, cellars, saunas, rooms for pets, operating blocks of hospitals, hydrophores, heat exchangers, spaces limited by conductive surfaces, campsites, open areas, etc. -
Page 18: Remote Operation
pay attention to the correct position of the power cable at the entrance to the product so that the water may be drained and flow down the cable. Incorrect connection of the motor can lead to product damage or create a hazardous situation. The motors have thermal switches that turn off the drive after a few minutes of continuous operation to protect against overheating. - Page 19 Gears 11:1 are not equipped with overturn protection (so called mechanical end stop). During operation of awning with manual drive the force working on the crank is multiplied by gear mechanism and putting too much force can lead to fabric damage, especially when closing the awning. Do not allow the fabric to be rolled in the opposite direction (from the bottom of roller tube), since it may cause its ripping off the roller tube, fabric damage or incorrect awning functioning.
-
Page 20: System Operation And Product Safety
- otherwise it will lead to permanent damage It is recommended that the change of equipment configuration be consulted with SELT. SAFETY REQUIREMENTS RELATED TO SPECIAL CONDITIONS AND PLACES OF PRODUCT USE Specific safety requirements relate to children up to 42 months. Essential requirements for use are applicable in all locations, to which children have access or where they could be present. - Page 21 Automatically controlled products may start up on their own. Make sure that no dangerous situation arises. SELT Sp. z o. o. is not responsible for damage caused by improper use. Operating the system out of sight can cause serious injury as well as damage to the system...
-
Page 22: Control Of Safe Use Of The Product
CONTROL OF SAFE USE OF THE PRODUCT The Buyer should: where the safe use of the product depends on the conditions in which it is installed, submit the product to: initial inspection (after its installation and before it is put into operation for the first time), ... -
Page 23: System Use And Maintenance
Possible adjustment and improvement of fastening of the mentioned components. Products manufactured by SELT Sp. z o. o. do not require any special maintenance. Using the product in accordance with the manufacturer's instructions ensures long-term and trouble-free operation for the system user. Ongoing maintenance work should be carried out on a fully developed system. -
Page 24: Use Of Awning Fabrics
Basic activities including product maintenance: Checking the correct unrolling and rolling of the awning fabric, Checking the condition of the fabric, Cleaning the fabric, Checking the correct operation of the limit switches, Cleaning visible, accessible elements of the product. Cleaning of metal / aluminium elements: ... - Page 25 All of the above described changes cannot be the basis for complaints, because they are typical for awning fabrics and do not influence the comfort of use. Do not unroll the awning during heavy rainfall and expose the fabric to long-term moisture, even if the attached fabric has the features of a fabric with increased water resistance or is made of PVC material.
-
Page 26: General Warranty Terms
GENERAL WARRANTY TERMS General warranty terms are available on www.selt.com If the SELT Sp. z o.o. website is inaccessible then warranty terms and conditions can be obtained from the sales representative of SELT Sp. z o.o. WARRANTY EXCLUSIONS The warranty will not cover: ... - Page 27 Selection of electric motors: DT-E 11.2 SUN PROTECTION SYSTEM – TERRACE AWNING PLUS Edition 8/ March 2022 / EN page 27 / 31...
-
Page 28: Complaint / Technical Defects
Photo or video documentation in the event of the inability to deliver the claimed goods to SELT. Goods without an invoice number, order number or contract number will be considered as post-warranty goods. -
Page 29: Product Disassembly / Utilisation / Disposal
PRODUCT DISASSEMBLY / UTILISATION / DISPOSAL Improper disassembly of the system can cause serious personal injury and damage the system. Disassembly of the system should be entrusted to a properly specialized assembly team or a person with appropriate health and safety training and knowledge in the field of recovery. Disposal of waste electrical and electronic equipment After the end of the product's life, in order to dispose of it, it is necessary to dismantle it and segregate individual materials and elements in accordance with the Regulation of the Minister of Climate of December 9... -
Page 30: Marking And Labelling Of The Product With Ce Mark
10.1 PRODUCT COMPLIANCE WITH THE CE STANDARD Products manufactured by SELT company meet the essential requirements of the standard introduced by the Polish Committee for Standardization as PN-EN 13561 what is confirmed by the manufacturer’s declaration of performance and marking the product with the CE mark. - Page 31 SELT Sp. z o. o. Opole, ul. Wschodnia 23A POLAND Awning with falding arms SILVER PLUS 230V/ 50 Hz Power 198 to 250 W 01 / DZ/2017 DT-E 11.2 SUN PROTECTION SYSTEM – TERRACE AWNING PLUS Edition 8/ March 2022 / EN...
