- Page 1 11.13 DT-E TECHNICAL AND OPERATIONAL DOCUMENTATION INSTALLATION MANUAL, OPERATING MANUAL AND INSTRUCTIONS FOR SAFE USE (Translated from the original manual) Awnings 11.13 Side awning BORA...
- Page 2 THIS TECHNICAL AND OPERATIONAL DOCUMENTATION: Is valid from: 19 March 2021 Is applicable to the above listed product versions. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 2 / 29...
-
Page 3: Table Of Contents
PREPARATION FOR INSTALLATION ........................11 GENERAL REQUIREMENTS FOR SAFE INSTALLATION .................... 11 INSTALLATION TOOLS ............................11 BORA AWNING INSTALLATION – WALL BRACKETS AND PERMANENT BRACKETS ..........11 GUIDELINES FOR INSTALLATION – CASSETTE BRACKET AND CASSETTE HANGER ..........14 BORA AWNING INSTALLATION ..........................15 4.7.1... -
Page 4: Introduction
Health or life hazard. Risk: danger of serious injury or death. Unsafe operation that may cause injury or damage to the product. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN... -
Page 5: Terms And Definitions
SELT SP. Z O.O. with a head office in Opole shall hold the copyrights to this documentation. The documentation cannot be used without permission, either partially or as a whole, for any concurrent business activity nor can it be made available to third parties. -
Page 6: Product Technical Information
Due to technological reasons, slight differences in colour shade are deemed acceptable and they are not a ground for complaint. PRODUCT SPECIFICATION Products manufactured by SELT Sp. z o. o. have appropriate technical and operational parameters. They have the following features: ... -
Page 7: Side Awning Elements
Left drive natural ground side) Wall bracket elements 1) Windbreaker Bora Pole L=150 mm - 1 pc. 2) Handle bracket set- 1 pc. 3) Fixed wall bracket - 1 pc. 4) Screw M6x45 (DIN 912) - 1 pc. 5) Screw M6x16 (DIN 912) - 4 pcs. -
Page 8: Dimensions Of Side Awning Elements
DIMENSIONS OF SIDE AWNING ELEMENTS Cassette hanger Fixed wall bracket Wall bracket Fixed footplate Cassette Mounting for natural ground DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 8 / 29... -
Page 9: Transport And Storage Of The Product
COMPLETENESS AND QUALITY CONDITION OF THE DELIVERY SELT Sp. z o. o. makes every effort to ensure that the goods comply with the order. However, checking the completeness of the product is the responsibility of the Buyer and should take place at the time of its receipt Any discrepancies should be immediately reported to the driver/warehouseman/assembly team and marked in the acceptance report or on the WZ document under pain of loss of claims in this respect. -
Page 10: Product Installation
This chapter contains general requirements concerning the product installation. Correct assembly is a necessary condition for smooth operation of the product. SELT Sp. o.o. recommends using only professional assembly crews, which guarantee the Purchaser that the conducted installation will be correct. -
Page 11: Preparation For Installation
Allen keys, anchors BORA AWNING INSTALLATION – WALL BRACKETS AND PERMANENT BRACKETS The side awning Bora can be installed in three configurations, according to the manner of fixing the bracket responsible for fastening to the front bar: Front post – mounting to hard ground (e.g. concrete) eith use of elements: front psot + fixed footplate. - Page 12 Exemplary manner of installation – concrete/foundation DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 12 / 29...
- Page 13 Exemplary manner of installation – soft ground Exemplary manner of installation - wall DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 13 / 29...
-
Page 14: Guidelines For Installation - Cassette Bracket And Cassette Hanger
‘Z’ (see picture below). Pay attention also to the proper distance from the ground. Scheme of the cassette hangers positioning DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 14 / 29... -
Page 15: Bora Awning Installation
Use a spirit level to mark the vertical line on the wall, then apply montażowe zgodnie z the hanger and mark the mounting holes. wykazem. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 15 / 29... - Page 16 9) After setting up the cassette on the hangers secure it with set screws, which are located in the cassette bracket. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN...
-
Page 17: Fixed Bracket Installation
The fixed bracket is installed in the same manner as described in point 4.7.2. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN... -
Page 18: Wall Bracket Installation
NECESSARY to adjust the position of the handle on the front bar. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 18 / 29... -
Page 19: Manual Drive
MANUAL DRIVE The Bora awning has a side cover pull system. The awning is opened and closed manually thanks to the torsion spring used inside the awning, while maintaining the tension of the fabric. The awning is opened with a handle, which is then locked in the handle bracket. -
Page 20: System Operation And Product Safety
It is forbidden to use the product inconsistent with the requirements of fire safety. It is forbidden to exceed the operating parameters of the product specified in the technical and operational documentation. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 20 / 29... -
Page 21: Control Of Safe Use Of The Product
It is absolutely forbidden to unroll the product during strong wind. SELT Sp. z o. o. is not responsible for damage caused by improper use. Operating the system out of sight can cause serious injury as well as damage to the system... -
Page 22: System Use And Maintenance
Possible adjustment and improvement of fastening of the mentioned components. Products manufactured by SELT Sp. z o. o. do not require any special maintenance. Using the product in accordance with the manufacturer's instructions ensures long-term and trouble-free operation for the system user. -
Page 23: Use Of Awning Fabrics
Due to the use of an impregnating agent, the fabric is sensitive to all kinds of scratches that are difficult to avoid even with a very precise and careful production process (8). This effect applies primarily to monochromatic materials. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 23 / 29... - Page 24 If the damp fabric is rolled up, unroll it immediately after the rain stops and let it dry. DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN...
- Page 25 DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 25 / 29...
-
Page 26: General Warranty Terms
GENERAL WARRANTY TERMS General warranty terms are available on www.selt.com If the SELT Sp. z o.o. website is inaccessible then warranty terms and conditions can be obtained from the sales representative of SELT Sp. z o.o. WARRANTY EXCLUSIONS The warranty will not cover: ... -
Page 27: Complaint / Technical Defects
Photo or video documentation in the event of the inability to deliver the claimed goods to SELT. Goods without an invoice number, order number or contract number will be considered as post-warranty goods. -
Page 28: Product Disassembly / Utilisation / Disposal
Regulation (EC) No. 2150/2002 of the European (Dz. U. [Journal of Laws] 2014, item 1923) Parliament and of the Council on waste statistics DT-E 11.13 SUN PROTECTION SYSTEM – SIDE AWNING BORA Eddition 7 / March 2021 / EN page 28 / 29... -
Page 29: Marking And Labelling Of The Product With Ce Mark
10.1 PRODUCT COMPLIANCE WITH THE CE STANDARD Products manufactured by SELT company meet the essential requirements of the standard introduced by the Polish Committee for Standardization as PN-EN 13561 what is confirmed by the manufacturer’s declaration of performance and marking the product with the CE mark.
