- Page 1 11.8.1 PRODUCT TECHNICAL AND OPERATIONAL DOCUMENTATION INSTALLATION MANUAL Awnings 11.8 Terrace awning CASABLANCA 11.8.1 Installation manual Documentation no. 11.8.1 – EN...
- Page 2 Product conforms to CE safety requirements This Technical and Operational Documentation: Is valid from: 01 March 2016 Is valid for product versions designated above DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English page 2 / 19...
-
Page 3: Table Of Contents
Installation tools ......................9 Casablanca awning installation – wall brackets ............10 Casablanca awning installation – ceiling brackets ............ 14 Casablanca awning installation – roof rafter brackets ..........14 Electric drive ......................15 3.9.1 Connection to electrical installation ..............15 3.9.2... -
Page 4: Introduction
Threat to human life or health due to electric shock. 1.3 Definitions The terms and definitions used within this documentation shall mean: Product: terrace awning CASABLANCA DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English page 4 / 19... -
Page 5: Subject, Designation And Contents Of The Documentation
SELT SP. Z O.O. with a head office in Opole shall hold the copyrights to this documentation. The documentation cannot be used without permission, either partially or as a whole, for any concurrent business activity nor can it be made available to third parties. -
Page 6: Product Technical Information
Due to technological reasons, slight differences in colour shade are deemed acceptable and they are not a ground for complaint. Motor technical data www.selt.com → PRODUCTS → AUTOMATION → ALL → MOTORS 2.2 Casablanca awning construction DT-E 11.8.1 TERRACE AWNING CASABLANCA... -
Page 7: Bracket Types
2.3 Bracket types Wall bracket Ceiling bracket Roof rafter bracket DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English page 7 / 19... -
Page 8: Product Installation
3 Product installation The following part covers general requirements of the product installation. Proper installation is necessary for efficient operation of the product. SELT SP. Z O.O. recommends to use services of skilled installation crews what guarantees the Purchaser proper installation. -
Page 9: General Guidelines For Installation
Improper installation may cause hazardous situation for the user. 3.5 Installation tools drills, pencil/marker, hammer drill, spirit level, ladder/scaffolding, ring and flat screw-driver, wrenches, hammer, Allen keys, measure tape, anchors. DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English page 9 / 19... -
Page 10: Casablanca Awning Installation - Wall Brackets
3.6 Casablanca awning installation – wall brackets For base – uncracked concrete C20/25 class and no higher than C50/60: Anchors M10x110 A4, embedded on injection mortar (recommended anchors from Fischer FIS A M10x110 A4 on resin FIS V360, embedment depth in concrete shall be 60 mm, or equivalent product from different supplier). - Page 11 (Note – before placing the awning verify the alignment of brackets – wall surface should be of the same thickness at installation spots). DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English page 11 / 19...
- Page 12 11) Secure the construction bar with screws. 12) Open the awning slightly. 13) With spirit level check if the arms close to one plane. DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English page 12 / 19...
- Page 13 M10 Allen screws, which are securing the wall brackets movable part. 16) Loosen (to decrease tilt angle) or tighten (to increase tilt angle ) the regulation hexagonal head screw witch a wrench. DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English...
-
Page 14: Casablanca Awning Installation - Ceiling Brackets
Slide the awning on wall brackets so that the construction is maximally pressed to the back. Secure the construction with screws. 3.8 Casablanca awning installation – roof rafter brackets Roof rafter brackets should be installed to roof rafters the closest to awning edge possible, remaining brackets place in equal intervals. -
Page 15: Electric Drive
They are to be used obligatory at swimming and shower pools, saunas, construction sites, while supplying appliances in open spaces, on agricultural and horticultural farms, on campsites and in camper vans, as well as in rooms where there is fire hazard. DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English... -
Page 16: Remote Operation
When the awning starts working attention should be paid to: Correct rolling down and up of the fabric, Correct activation of limit switches. DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1 English page 16 / 19... -
Page 17: Manual Drive
Do not allow the fabric to be rolled in the opposite direction (from the bottom of roller tube), since it may cause its ripping off the roller tube, fabric damage or incorrect awning functioning. DT-E 11.8.1 TERRACE AWNING CASABLANCA Edition: March 2016 / Issue 1... -
Page 18: Final Remarks
As apparent defects are considered mechanical damages, scratches, cracks, etc. Any discrepancies in quantity or possible replacements of parts being the evident result of Selt SP. Z O.O. fault, the company agrees to supplement or replace in the shortest possible time. -
Page 19: Marking And Labelling The Product With Ce Mark
5 Marking and labelling the product with CE mark 5.1 Product compliance with CE standard Awnings manufactured by SELT company meet the essential requirements of the standard introduced by the Polish Committee for Standardization as PN-EN 13561 what is confirmed by the manufacturer’s declaration of performance and marking the product with the CE mark.
