- Page 1 Avington / Mia / Hayes Single Door Wall Cabinet Model # AXCBSAVN03-WH...
- Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Activate your 1-year warranty ü...
- Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards.
- Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order information and issue. Submit form.
-
Page 5: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information This furniture is designed for indoor use. Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. - Page 6 Pre-Assembly Information Model # AXCBSAVN03-WH Part Description LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF BACK PANEL DOOR QTY 1 QTY 1 QTY 1 SHELF FRONT BAR BACK BAR QTY 1 QTY 1 QTY 1 WALL MOUNT BAR QTY 1...
- Page 7 Pre-Assembly Information Model # AXCBSAVN03-WH Hardware Description CAM LOCK PIN WOOD DOWEL CAM LOCK HINGE Ø8 X 30mm QTY 4 SETS QTY 2 QTY 14 PHILLIPS SCREW PHILLIPS SCREW MAGNET AND PLATE M4 X 50mm M3 X 15mm QTY 1 SET QTY 7 QTY 12 HANDLE...
- Page 8 Components - Key Diagram Model # AXCBSAVN03-WH...
- Page 9 Assembly Model # AXCBSAVN03-WH Step 1 1. Insert four Dowels 2 into guide holes on each part G , H . 2. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of Dowels should be exposed. Step 2 1.
- Page 10 Assembly Model # AXCBSAVN03-WH Step 3 1. Repeat Step 2 for the Right Side BR . Step 4 1. Insert two Dowels 2 into guide holes on each Side BL , BR . 2. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 11 Assembly Model # AXCBSAVN03-WH Step 5 1. Align Wood Dowels with guide holes and attach Side BL , BR to Bottom Shelf C . 2. Use four Phillips Screws 5 to attach Bottom Shelf C through guide holes from Bottom Shelf C to pre-drilled holes of Sides BL , BR . 3.
- Page 12 Assembly Model # AXCBSAVN03-WH Step 6 Warning Label...
- Page 13 Assembly Model # AXCBSAVN03-WH Step 7 1. Attach four Cam Lock Pins 1 into pre-drilled holes on Top A . 2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten. Step 8 1. Insert two Dowels 2 into guide holes on each Side BL , BR . 2.
- Page 14 Assembly Model # AXCBSAVN03-WH Step 9 1. Align Cam Lock Pin and Wood Dowels with guide holes on Sides BL , BR and Top A and attach Top A to Sides BL , BR . 2. Insert two Cam Locks 1 into guide holes on each Side BL , BR . 3.
- Page 15 Assembly Model # AXCBSAVN03-WH Step 10...
- Page 16 Assembly Model # AXCBSAVN03-WH Step 11 Step 12...
- Page 17 Assembly Model # AXCBSAVN03-WH Step 13 - Positioning 1. Determine the location for the unit on the wall. The Top A should be approximately 1 ¼” above the top of the Wall Mount Bar I when mounted. 2. Place the Wall Mount Bar I at the predetermined height. Use a level to ensure that it is straight.
- Page 18 Assembly Model # AXCBSAVN03-WH Step 15 1. Align the top of the Wall Mount Bar I with the bottom of the angled bracket on the back of the Cabinet. 2. Gently slide the Cabinet down on to the Wall Mount Bar I .
